- Page 1 REMOTE CONTROLS AND INTERFACES Digital wall control USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT WARNING ................. 3 IMPORTANT SAFETY INSTRUCTIONS .............. 4 IMPORTANT NOTE ..................5 INTRODUCTION ..................... 5 INSTALLATION ....................6 OPERATING THE UNIT ..................8 6.1 Controls ......................8 6.2 Equalization screen ..................9 6.3 Information messages .................. 10 NOTES ......................12 FRONT PANEL .................... -
Page 3: Important Warning
1. IMPORTANT WARNING The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying... -
Page 4: Important Safety Instructions
2. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 5: Important Note
3. IMPORTANT NOTE Thank you for choosing our eMCONTROL1 digital wall control. It is VERY IMPORTANT to carefully read this manual and to fully understand its contents before any connection to maximize your use and get the best performance. To guarantee the optimum operation of this device, we strongly recommend that it be maintained by our Authorized Technical Services. -
Page 6: Installation
3. Screw the device to the surface mount box or flush mount box. 4. Put the front panel back in place and secure the rotary encoder knob. Installation of an eMCONTROL1 unit next to a WPaMIX-T wall panel, recessed or surface mounted: Note: a WPa2FMBOX double installation box is required to flush mount the two devices side by side. - Page 7 105 meters 130 meters If the cable is too long, eMCONTROL1 may work properly but noise will be superimposed on the signal entering the WPaMIX-T. The solution to this possible problem is to supply the eMCONTROL1 digital control with an external 24VDC power supply.
-
Page 8: Operating The Unit
6. OPERATING THE UNIT 6.1 Controls eMCONTROL1 has 2 controls on its front panel: Rotating Encoder Selection key Figure 2: Front panel controls The main screen displays the label or name of the controlled zone, the source selection in that zone, and its volume control. -
Page 9: Equalization Screen
Using the selection key (short press), you can navigate between the source selection and the volume control. The editable option is displayed on a white background. On the other hand, the VOL or SEL indicator will be framed and blinking when this option is selected. ... -
Page 10: Information Messages
INFORMATION: press and hold the 2 control keys for a few seconds to access the information screen. It shows the name or label of eMCONTROL1 (it can be different from the name or label of the main screen area – it is programmed using the eMIMO1616 web application) and the firmware version*. - Page 11 DISABLED CONTROL: displayed when trying to use a control (volume, source selection or equalization) that is disabled for that eMCONTROL1 panel. Figure 8: Disabled Control screen PANEL LOCKED: displayed when the temporary lock is activated for the user. To activate/deactivate this lock, press and hold selection key and rotary encoder for approx.
-
Page 12: Notes
Figure 11: Panic Active screen (PANIC button activated) 7. NOTES When connecting an eMCONTROL1 unit to an eMIMO1616 matrix, the eMCONTROL1 unit will check whether its firmware needs to be updated, and if so, automatically performs update, without external manual intervention. -
Page 13: Front Panel
8. FRONT PANEL 1. Front panel faceplate 2. LCD screen 3. Selection button 4. Rotary encoder 9. BACK PANEL 1. External power supply connector 24VDC 2. Connector for WPaMIX-T interconnection 3. RJ-45 connector... -
Page 14: Block Diagram
10. BLOCK DIAGRAM 11. TECHNICAL SPECIFICATIONS Digital characteristics Control keys Encoder, SELECTION key Indicators LCD display – 128x128 pixels Communication standard RS485 Supply characteristics Nominal power supply From RJ45 remote input: 12VDC From External Input: 24VDC Minimum external power From RJ45 remote input without WPaMIX-T: 9.5V supply From RJ45 remote input with WPaMIX-T: 11V From External Input: 18VDC... -
Page 15: Mounting Drawings
12. MOUNTING DRAWINGS... -
Page 16: Package Contents
13. PACKAGE CONTENTS eMCONTROL1 Frame for mounting a mechanism in a system Screws for fixing to surface or flush mounting box Magnet for cover removal Surface mounting box Cable for direct connection to WPaMIX-T ... - Page 17 All product characteristics are subject to variation due to production tolerances. NEEC AUDIO BARCELONA S.L. reserves the right to make design or manufacturing changes that may affect these product specifications. Motors, 166‐168 08038 Barcelona ‐ Spain ‐ (+34) 932238403 information@ecler.es www.ecler.com...
