Eaton EBPLED7W Instructions

IB505009EN
Instructions for Surelites LED Emergency Battery Packs
Includes the following model numbers: EBPLED7W, EBPLED14W
WARNING
Risk of Fire/Electric Shock
If not qualified, consult an electrician.
EBPLED Class 2 Output
Important Safeguards
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE OBSERVED INCLUDING
THE FOLLOWING.
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS
2. Do not use outdoors.
3. Do not mount near gas or electric heaters
4. Equipment should be mounted in locations and at adequate
heights to prevent tampering by unauthorized personnel.
5. The use of accessory equipment not recommended by
Eaton may cause an unsafe condition and will void the
warranty.
6. Do not use this equipment for other than its intended
purpose.
7. Not for use with sealed and gasketed fixtures
8. SAVE THESE INSTRUCTIONS
NOTES
1. To prevent voltage from being present on the output wires
(Red/White & Blue/White), do not connect the test button
assembly to the EBP or insure the EZ key is securely in
place.
2. This product is for use with LED fixtures that have LED
loads capable of the output wattage and that have LED
forward voltage within the ranges below.
Risk of Electric Shock
Disconnect power at fuse or circuit breaker before
installing or servicing.
For use in
temperature rating
0°C to 55°C
3. Make sure all of the connections are in accordance with
4. To reduce the risk of electrical shock, disconnect both
5. These emergency ballasts can be field or factory installed
6. This product is for use in indoor fixtures only. Do NOT
7. An un-switched AC power source is required. (120 - 277
8. Do not attempt to service the battery. The sealed,
9. All maintenance should be performed by qualified service
FEATURES
This emergency battery pack (EBP) includes extra features
which enhance its operation and maintainability.
1. Patented EZ key battery disconnect: When the EZ key is
2. Patent pending Test Button / Indicator Light / Laser Input:
WARNING
CONTAINS NICKEL-CADMIUM
RECHARGEABLE BATTERY.
MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Output Power (W)
All 7 Watt
7
Versions
All 14 Watt
14
Versions
the National Electrical Code and any local regulations.
normal and emergency power supplies and the test button
indicator light (which disconnects the battery) before
servicing. Insuring the battery disconnect is securely in
place also prevents battery powered operation.
depending on version. See mounting section for details.
use near heated air handling outlets, wet locations or
hazardous locations.
volts 50/60 HZ) for proper operation.
no-maintenance battery is not field replaceable. Contact
the manufacturer for information on service.
personnel.
inserted into the test button, the battery is disconnected.
This feature prevents unnecessary cycling of the battery
during the construction process. It can also be used if the
room is decommissioned for an extended period of time to
prevent the batteries from being over discharged.
The test button houses the EZ key, powers the indicator
light, contains the laser input for testing and functions as
the mechanical test button. Integration of these functions
improves performance and fixture aesthetics.
Sure-Lites
Ni - Cd
Min Vf (V) Max Vf (V)
8 55
16 55
