GAS TILTING BRAISING PANS
MODELS BGLT-24 BGLT-30 & BGLT-40
These instructions should be read thoroughly before attempting installation. Set up,
installation and Performance Check should be performed by a qualified service
technician. The Manufacturer, Southbend (1100 Old Honeycutt Rd.,Fuquay-Varina,
North Carolina 27526), informs you that unless the installation instructions for the
above described Southbend product are followed and performed by a qualified
service technician, (a person experienced in and knowledgeable concerning the
installation of commercial gas and/or electrical cooking equipment) then the terms
and conditions of the Manufacturer's Limited Warranty will be rendered void and no
warranty of any kind shall apply.
If the equipment has been changed, altered, modified or repaired by other than a
qualified service technician during or after the 12-month limited warranty period,
then the manufacturer shall not be liable for any incidental or consequential
damages to any person or to any property which may result from the use of the
equipment thereafter. Some States do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion thereto
may not apply to you.
In the event you have any question concerning the installation, use, care. or service
of the product, write Customer Service Department, Southbend Corporation. 1100 Old
Honeycutt Rd.. Fuquay-Varina, North Carolina 27526.
OWNER'S MANUAL
INSTALLATION
USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGLT-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Southbend BGLT-24

  • Page 1 The Manufacturer, Southbend (1100 Old Honeycutt Rd.,Fuquay-Varina, North Carolina 27526), informs you that unless the installation instructions for the above described Southbend product are followed and performed by a qualified service technician, (a person experienced in and knowledgeable concerning the...
  • Page 2 IMPORTANT NOTES FOR INSTALLATION AND OPERATION WARNING FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPOURS AND LIQUIDS IN THE VICINITY OF THIS OR OTHER APPLIANCE. INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THAT THE OPERATOR OF THIS APPLIANCE SMELLS GAS MUST BE POSTED IN A PROMINENT LOCATION.
  • Page 3 Installation and Operation of Gas Skillets It is recommended that this manual be read thoroughly and that all instructions be followed carefully. This manual should be retained lor future reference. INDEX DESCRIPTION PAGE IMPORTANT NOTES INDEX INSTALLATION AND SERVICE CONNECTIONS INSTALLATION INSTRUCTIONS OPERATION INSTRUCTIONS PERIODIC MAINTENANCE...
  • Page 4 SERVICE CONNECTIONS Supply gas through ½ pipe with pressure of apporx. T W.C. For propane use 11” W.C. pressure. A gas shut- Off valve must be installed in supply piping convenient and adjacent to appliance. Unless otherwise specified. Field Wire Electrical Connection to be 120 Volts, 60 Hertz single phase with grounding wire.
  • Page 5 SERVICE CONNECTIONS Gas installation to conform to local codes or in absence of local codes to national fuet gas code — ANSI 2223.1 — latest edition. In Canada, installation to be in accordance wilh 8149.1 (NAT) or B149.2 (LP) installation codes and/or local codes.
  • Page 6 OPERATION INSTRUCTION 1. Open manual gas shut off valve located near back under left hand console facing front of unit. 2. Ensure skillet pan is in the down position. 3. Turn power switch ON, set thermostat dial to desired setting. RED pilot light will come ON.
  • Page 7 PERIODIC MAINTENANCE Notice: As a safety precaution, disconnect the power supply during cleaning or servicing. CLEANING The gas fired tilting skillet should be cleaned after each use. 1. Keep exposed cleanable areas of unit dean at all times. 2. Thoroughly wash pan and lid. If necessary soak pan to remove product that is stuck to pan surface. Use mild detergent and water.
