FlexLogix Controller System
Catalog number: 1794-L33, 1794-L34 & 1794-FLA
Before You Begin
Use this document as a guide for installing and powering-up your FlexLogix
controller system. This guide provides installation instructions for both the
FlexLogix controller (1794-L33, -L34) and the FlexLogix extended-local I/O adapter
(1794-FLA). You should already be familiar with the FlexLogix system components.
See the documentation references for additional information.
You must FLASH upgrade the firmware on your FlexLogix controller before you
can use it. The controller ships with firmware revision 1.x but must be upgraded to
match the version of RSLogix 5000 that you are using (e.g. if you are using
RSLogix 5000 V11, you must upgrade your FlexLogix controller firmware to revision
11.x before using it. For more information on upgrading your controller's firmware,
see page 19.
Tools That You Need
· slotted screwdriver
· phillips screwdriver
· mounting hardware (for mounting a DIN rail)
· drill (for mounting a DIN rail)
· needle-nose pliers
IMPORTANT
Installation instructions ship with each FlexLogix component. If
you want the FlexLogix System User Manual, publication
1794-UM001, you can obtain it as follows:
· download an electronic version or place an order over the
Internet: www.theautomationbookstore.com
· contact your local distributor or Rockwell Automation
representative
For information about other publications that may be needed
with the FlexLogix Controller system, see page 27.
Installation Instructions
Publication 1794-IN002F-EN-P - October 2002
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allen-Bradley FlexLogix 1794-L33
Summary of Contents for Allen-Bradley FlexLogix 1794-L33
- Page 1 Installation Instructions FlexLogix Controller System Catalog number: 1794-L33, 1794-L34 & 1794-FLA Before You Begin ™ Use this document as a guide for installing and powering-up your FlexLogix controller system. This guide provides installation instructions for both the FlexLogix controller (1794-L33, -L34) and the FlexLogix extended-local I/O adapter (1794-FLA).
-
Page 2: Important User Information
Allen-Bradley publication SGI-1.1, Safety Guidelines for the Application, Installation and Maintenance of Solid-State Control (available from your local Rockwell Automation office), describes some important differences between solid-state equipment and electromechanical devices that should be taken into consideration when applying products such as those described in this publication. -
Page 3: Handling The Flexlogix System Components
Also, see the appropriate sections in this publication, as well as the Allen-Bradley publication 1770-4.1 ("Industrial Automation Wiring and Grounding Guidelines"), for additional installation requirements pertaining to this equipment. -
Page 4: Removal And Insertion Under Power
FlexLogix Controller System Take these precautions to guard against ESD damage: Preventing Electrostatic Discharge ATTENTION This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: · Touch a grounded object to discharge potential static. ·... -
Page 5: What You Need To Do
FlexLogix Controller System What You Need to Do Before you can install a FlexLogix controller or extended-local adapter, you must: Install steel, 35 x 7.55mm DIN rails (A-B part number 199-DR1; 46277-3) where you want to place the FlexLogix system components. The DIN rails for all FlexLogix system components, including all local and extended-local I/O modules, must be mounted on a common, conductive surface to ensure proper electromagnetic interference (EMI) performance. - Page 6 FlexLogix Controller System Step 1: Verify That You Have All the Components These components ship with the FlexLogix controller: · 1756-BA1 battery and label · key · one spring-clip connector plug for 24V power connection · one screw-terminal connector plug for 24V power connection ·...
-
Page 7: Step 2: Install The Battery
FlexLogix Controller System Step 2: Install the Battery Only install a 1756-BA1 battery. If you install a different battery, ATTENTION you may damage the controller. For safety information on the handling of lithium batteries, WARNING including the handling and disposal of leaking batteries, see Guidelines for Handling Lithium Batteries, publication AG-5.4. - Page 8 FlexLogix Controller System Step 3: Install Communication Daughtercards (optional) For specific information about configuring the communication IMPORTANT card (such as setting a node address), see the installation instructions for the communication card. 1. Turn off power to the controller. 2. If necessary, remove the blank cover from the communication slot. 3.
-
Page 9: Step 4: Install The Controller
FlexLogix Controller System Step 4: Install the Controller 1. Position the FlexLogix controller on the DIN rail at a 5° angle and rotate the controller onto the DIN rail. locking tabs You can mount the FlexLogix controller either vertically or IMPORTANT horizontally (as shown). - Page 10 FlexLogix Controller System 4. Make sure power is not applied to the power supply. Connect the power supply to the controller. This diagram and its related instructions describe a 1794-PS13 power supply. a. Connect +24V dc input to the top of the controller connector, terminal A, to the bottom, left power connector, terminal G.
-
Page 11: Removing The Controller
FlexLogix Controller System 5. Mount the I/O terminal bases on the DIN rail. 31036-M For information about I/O terminal bases, see the FLEX I/O Terminal Base Installation Instructions, publication 1794-5.16. 6. Install the I/O modules. To install an I/O module, see the installation instructions for that module. Removing the controller If you need to remove the controller, follow these steps: 1. - Page 12 FlexLogix Controller System Step 5: Install the Extended-Local Adapter (optional) 1. Position the 1794-FLA extended-local I/O adapter on the DIN rail at a 30° angle and rotate the adapter onto the DIN rail. 2. Press the adapter down onto the DIN rail until flush. The locking tab will snap into position and lock the adapter onto the DIN rail.
- Page 13 FlexLogix Controller System 4. Make sure power is not applied to the power supply. Connect the power supply to the adapter. This diagram and its related instructions describe a 1794-PS13 power supply. a. Connect +24V dc input to the left adapter connector, terminal A, to the bottom, left power connector, terminal G.
- Page 14 FlexLogix Controller System 7. Connect the adapter to the controller. LOCAL rail 1794-CE1 or 1794-CE3 cable LOCAL2 rail 31039-M The following diagram shows how you can also use the 1794-CE1, -CE3 cable to split a rail of I/O. You can split each rail only once. You can split a rail right after the controller (or adapter) or after any I/O module.
-
Page 15: Make An Rs-232 Connection To The Controller
FlexLogix Controller System Make an RS-232 Connection to the Controller The RS-232 port is a non-isolated serial port built-in to the front of the controller. serial port To connect to the serial port: 1. Determine whether you need an optical isolator. If you connect the controller to a device outside of the system’s enclosure, consider installing an isolator between the controller and device. - Page 16 FlexLogix Controller System 2. Select the appropriate cable. Are you using Use this cable: an isolator? The 1756-CP3 cable attaches the controller directly to the controller. 1 CD 1 CD 2 RDX 2 RDX 3 TXD 3 TXD 4 DTR 4 DTR COMMON COMMON...
- Page 17 FlexLogix Controller System 3. Connect the appropriate cable to the serial port on the controller. If you connect or disconnect the serial cable with power WARNING applied to this module or the serial device on the other end of the cable, an electrical arc can occur. This could cause an explosion in hazardous location installations.
-
Page 18: Select The Operating Mode Of The Controller
FlexLogix Controller System Select the Operating Mode of the Controller 1. Use this table to determine the operating mode of the controller: If you want to: Select one of these modes: Program Remote Program Test turn outputs to the state commanded by the logic of the project turn outputs to their configured state for Program mode... -
Page 19: Monitor The Controller Leds
FlexLogix Controller System Monitor the Controller LEDs Indicator: Color: Description: · no task(s) running · controller in Program mode · one or more tasks are running green · controller is in Run mode no power applied red flashing after initially installing the controller - the controller requires a FLASH upgrade to the proper firmware revision;... -
Page 20: Update The Controller
FlexLogix Controller System Update the Controller RSLogix 5000 software, revision 10.0 or later, lets you update controller firmware as part of the download sequence. To update the controller, download your project and follow the prompts of the software. 1. Connect the controller to the same network as your workstation. 2. -
Page 21: Specifications
FlexLogix Controller System Specifications Category: FlexLogix controller FlexLogix extended-local I/O (1794-L33, -L34) adapter (1794-FLA) user memory 1794-L33 64 KBytes 1794-L34 512 KBytes input voltage rating (nominal) 24V dc range 19.2V to 31.2V dc (includes 5% ac ripple) isolation voltage 30V dc (continuous-voltage Qualification tested to withstand 850V dc for 60 seconds withstand rating) - Page 22 FlexLogix Controller System Category: FlexLogix controller FlexLogix extended-local I/O (1794-L33, -L34) adapter (1794-FLA) conducted RF immunity IEC 61000-4-6: 10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz enclosure type rating none (open-style) weight 1794-L33 .71 kg (1.56 lbs oz.) .28 kg (.62 lbs.) 1794-L34 .75 g (1.66 lbs.) (no communication cards installed) power supply...
-
Page 23: Flexlogix Controller Approximate Mounting Dimensions
FlexLogix Controller System FlexLogix Controller Approximate Mounting Dimensions 104.57mm (4.12in) 199.49mm (7.85in) 185.3mm (7.30in) 6.4mm 6.0mm 8.85mm 50.43mm (0.25in) (0.24in) 84.9mm (3.34in) (0.35in) (1.99in) 121.97mm 101.49mm (4.81in) 88.57mm (3.99in) (3.49in) 101.6mm 105.96mm (4.00in) (4.17in) 8.25mm 182.96mm (7.203in) 13.5mm (0.33in) (0.53in) 87.24mm (3.43in) centerline of MTG Hole... -
Page 24: Flexlogix Extended-Local I/O Adapter Approximate Mounting Dimensions
FlexLogix Controller System FlexLogix Extended-Local I/O Adapter Approximate Mounting Dimensions 94mm (3.7in) 117.12mm (4.61in) 69mm (2.72in) 81.06mm 88.94mm (3.19in) (3.5in) Approximate Mounting Clearance 25.4 mm (1 in) 25.4 mm (1 in) 25.4 mm (1 in) 25.4 mm (1 in) 25.4 mm (1 in) 25.4 mm (1 in) 25.4 mm (1 in) Publication 1794-IN002F-EN-P - October 2002... -
Page 25: Operating In Hazardous Locations
IP54 protection when applied in Class I, Zone 2 environments. This equipment shall be used within its specified ratings defined by Allen-Bradley. Provision shall be made to prevent the rated voltage from being exceeded by transient disturbances of more than 40% when applied in Class I, Zone 2 environments. - Page 26 FlexLogix Controller System The following information applies when Informations sur l’utilisation de cet équipement operating this equipment in hazardous en environnements dangereux: locations: Products marked “CL I, DIV 2, GP A, B, C, D” are Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne suitable for use in Class I Division 2 Groups A, B, C, conviennent qu’à...
-
Page 27: Other Publications
FlexLogix Controller System Other Publications This product has the following additional manuals: This document: Publication number: Documents required for installation details: Industrial Automation Wiring and Grounding Guidelines 1770-4.1 Flex 1794-PS3 Power Supply Installation Instructions 1794-5.71 Flex 1794-PS13 Power Supply Installation Instructions 1794-5.69 Flex I/O Terminal Base Installation Instructions 1794-5.16... - Page 28 Publication 1794-IN002F-EN-P - October 2002 PN 957689-50 Supersedes Publication 1794-IN002E-EN-P - November 2001 Copyright © 2002 Rockwell Automation. All rights reserved. Printed in the U.S.A.
