Product Overview
To the Installer
ControlNet-to-F
Linking Device
Catalog No. 1788-CN2FF
The ControlNet-to-Fieldbus linking device connects a ControlNet™
network with one or more F
Each H1 network consists of multiple Fieldbus devices. Each field device
has one or more function blocks. Each function block performs an
elementary control function such as analog input, analog output, discrete
input, or discrete output. The ControlNet network consists of controllers,
such as PLC® processors, HMIs, drives, I/O devices, and so on.
The linking device has two broad functions, supporting the following:
• closed-loop control
• configuration and monitoring
Refer to the ControlNet-to-F
Manual, publication 1788-6.5.1, for detailed information about these
functions.
Use this document as a guide when you install the ControlNet-to-Fieldbus
linking device.
Topic
AB Drives
Installation Instructions
Fieldbus H1
OUNDATION
Fieldbus H1 (Fieldbus) networks.
OUNDATION
Fieldbus H1 Linking Device User
OUNDATION
Page
2
3
4
5
6
7
7
8
9
10
12
14
1788-5.1 - April 2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ControlNet-to-FOUNDATION Fieldbus H1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allen-Bradley ControlNet-to-FOUNDATION Fieldbus H1

Summary of Contents for Allen-Bradley ControlNet-to-FOUNDATION Fieldbus H1

  • Page 1: Table Of Contents

    Installation Instructions ControlNet-to-F Fieldbus H1 OUNDATION Linking Device Catalog No. 1788-CN2FF Product Overview The ControlNet-to-Fieldbus linking device connects a ControlNet™ network with one or more F Fieldbus H1 (Fieldbus) networks. OUNDATION Each H1 network consists of multiple Fieldbus devices. Each field device has one or more function blocks.

  • Page 2: System Requirements

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Handling the Linking Device We recommend that you adhere to this precautionary information. ATTENTION: This module contains ESD (Electrostatic Discharge) sensitive parts and assemblies. Static control precautions are required when installing or testing this assembly. Component damage may result if these procedures are not followed.

  • Page 3: Compliance To European Union Directives

    EN 61131-2 Programmable Controllers, Part 2 - Equipment Requirements and Tests. For specific information required by EN 61131-2, see the appropriate sections in this publication, as well as the following Allen-Bradley publications: • Industrial Automation Wiring and Grounding Guidelines for Noise Immunity, publication 1770-4.1...

  • Page 4: Linking Device Hardware Description

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Linking Device Figure 1 shows the components of the linking device. Hardware Description Figure 1 ControlNet-to-FOUNDATION Fieldbus Linking Device Case/Enclosure ControlNet Network Status Fieldbus Connectors DIN Rail Clip LEDs 10 Power Supply Connector Network Address...

  • Page 5: Ni-Fbus Configurator Software Description

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device NI-FBUS Configurator Use the NI-FBUS Fieldbus Configurator to configure a Fieldbus network and keep track of your configurations. The Configurator is an easy-to-use Software Description graphical environment for creating Fieldbus linkages, loops, and schedules. Figure 2 shows the Configurator Main window. For more information, refer to the NI-FBUS Configurator User Manual, publication 1788-6.5.2.

  • Page 6: Installing The Linking Device

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Installing the Linking Device The linking device has a rugged, simple clip for mounting reliably on a standard 35 mm DIN rail. Follow these steps to mount the linking device onto a DIN rail. 1. Use a flat-bladed screwdriver to open the DIN rail clip to the unlocked position.

  • Page 7: Removing The Linking Device

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Removing the Linking Device To remove a linking device, unlock it from the DIN rail by placing a screwdriver in the slot on the rail snap and opening the rail snap to the unlocked position as shown in step 1 on page 6. Then lift the device off of the rail.

  • Page 8: Connecting To The Controlnet Network

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Connecting to There are two types of ControlNet connectors on the linking device. The BNC connectors are for direct connection to a ControlNet network through the ControlNet Network a tap. The BNC connectors must be used to connect the linking device to the ControlNet network.

  • Page 9: Connecting To The Fieldbus Network

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Connecting to The location of the Fieldbus connectors is shown in Figure 5. the Fieldbus Network Figure 5 Fieldbus Connectors on the Linking Device Fieldbus Connectors If you want to make your own Fieldbus cable, make sure that it uses pins 6 and 7 for the Fieldbus signals, as specified in the Fieldbus Standard for Use in Industrial Control Systems, Part 2, ISA-S50.02.1992.

  • Page 10: Setting The Controlnet Network Address

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Setting the Valid ControlNet network addresses are 1-99. Network address zero is reserved. Switch 1 controls the most significant decimal digit (the tens). ControlNet Network Address Switch 2 controls the least significant decimal digit (the ones). Figure 7 shows the location of the network address switches and an example of switch settings for a network address of 15.
  • Page 11 ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Follow these steps to set the ControlNet network address for the linking device. For optimum throughput, assign network addresses to your ControlNet nodes in a sequential order starting with 01 for the PC running the configuration software.

  • Page 12: Interpreting The Leds

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Interpreting the LEDs Module STATUS LED The STATUS LED is located on the front of the linking device, between the two Fieldbus connectors, as shown in Figure 1. It indicates whether the linking device is powered, configured, and operating properly. Table A shows how to interpret the STATUS LED states.
  • Page 13 ControlNet-to-FOUNDATION Fieldbus H1 Linking Device ControlNet Network Status LEDs The ControlNet network status LEDs are located on the front of the linking device, beside the ControlNet BNC connectors, as shown in Figure 1. They indicate the state of the ControlNet connected to the BNC connectors.

  • Page 14: Specifications

    ControlNet-to-FOUNDATION Fieldbus H1 Linking Device Specifications Type Specifications Environmental Operating Temperature: 0 to 60° C (32 to 140° F) Storage Temperature: -40 to 85° C (-40 to 185° F) Relative Humidity: 5 to 90% (non-condensing) Vibration Operating - 2Gs each axis...
  • Page 15 ControlNet-to-FOUNDATION Fieldbus H1 Linking Device ControlNet is a trademark of ControlNet International. PLC is a trademark of Rockwell Automation. AB Drives 1788-5.1 - April 2000...
  • Page 16 Publication 1788-5.1 - April 2000 PN 957293-77 Supersedes Publication 1788-5.1 - January 1999 Copyright 2000 of Rockwell International Corporation. Printed in the U.S.A.
