- Page 1 GIADA213HPA OPERATIVE MANUAL Please follow the instructions in this manual to get the best results from this product. We also recommend that keep this manual handy for future reference. GIADA213HPA OPERATIVE MANUAL A84-03/16...
-
Page 2: Mechanical Installation
+24Vdc= Positive power supply; -24Vdc= Negative power supply; R= Right channel; Gnd= Shield audio cable; L= Left channel; The 2x0,75 mm cable, already connected, the SPK terminal must be connected to the speaker respecting the polarity. FIG. 1 GIADA213HPA OPERATIVE MANUAL A84-03/16... -
Page 3: Technical Information
Audio power RMS: 50W Built in speaker with 3 way. Speaker: 2x13 cm woofer in Kevlar. 1x8 cm middle in Kevlar. 2x2,5cm adjustable Tweeter. Speaker dimension (LxHxP)= 357x255x84 mm Built in hole (LxH)= 330x225 mm Peso 5Kg. GIADA213HPA OPERATIVE MANUAL A84-03/16...
