Input Wiring Functions for Network Junction Box
Input (Wire Color)
Green/Black
White/Black
Red/Black
Orange/Black
Yellow
Purple
Grey
Brown
Blue/Black
Pink
Green
Blue
Orange
Any of the wires above not used to control the lightbar should be capped or otherwise insulated from
accidental contact with power sources.
920-0505-00 Rev. B
36 Inch and Shorter Pursuit Lightbars
Function Description
Level 1 Level 1 Emergency Mode.
Level 2 Level 2 Emergency Mode.
Level 3 Level 3 Emergency Mode.
Takedown Forward facing lower light heads steady burn.
Left Alley Left facing lower light heads steady burn.
Right Alley Right facing lower light heads steady burn.
TD/Alley
Forward, Left, and Right lower light heads flash.
Flash
Driver Side Triggers Driver Side Corners and Alley Positions to turn off for
Cut 8 seconds.
Rear Cut Triggers all rear facing and rear corners to turn off.
Front Cut Triggers all front facing and front corners to turn off.
All upper corner light heads will steady burn in a dimmed
Cruise
state.
Dim can be applied to any feature and pattern except for TD
Dim
and Alley.
Arrowstik
Rear lower light heads flash.
Flash
Additional functions not included as part of default configuration
Alley Flash Left and Right lower light heads flash.
TD Flash Forward lower light heads flash.
Aux Customer Defined
Left Arrow Rear facing lower light heads illuminate in the left direction.
Right Arrow Rear facing lower light heads illuminate in the right direction. Building Fast
Rear facing lower light heads illuminate from the center then
Center Out
outward direction.
California
Light head steady burns for California T13 Compliance.
Steady
Flash Pattern/Rate
Sweep Rev
Dual End Rotate
Pursuit
Steady
Steady
Steady
Single 150
Not Available
Not Available
Not Available
Cruise Low
Dim Low
Single 150
Single 150
Single 150
Building Fast
Building Fast
CA Steady
