Operating Instructions
Boiler controller Lambdatronic S 3200 - Touch
Version 50.04 - Build 05.09 | Version 60.01 - Build 01.23
Translation of the original German operating instructions for technicians and operators
Read and follow the instructions and safety information!
Technical changes, typographical errors and omissions reserved!
B0840314_en | Edition 21/07/2014
Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
Advertisement
Table of Contents
Related Manuals for Froling Lambdatronic S 3200
Summary of Contents for Froling Lambdatronic S 3200
- Page 1 Version 50.04 - Build 05.09 | Version 60.01 - Build 01.23 Translation of the original German operating instructions for technicians and operators Read and follow the instructions and safety information! Technical changes, typographical errors and omissions reserved! B0840314_en | Edition 21/07/2014 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com...
-
Page 2: Table Of Contents
Controller check 4.1.2 Check on the connected units 4.1.3 System Check Navigation within the info menu Navigation within the system menu 4.3.1 Navigating the menus Adjusting parameters Setting times Setting the date/time Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 3 Temperature settings for the boiler 5.5.3 Service parameters of the boiler 5.5.4 General Settings Operator data Menu - Boiler 2 5.6.1 Status displays for the backup boiler 5.6.2 Temperature settings for the backup boiler Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
- Page 4 Menu - Display settings 5.14.1 General Network settings 5.14.2 Date / Time 5.14.3 Software update / Service 5.15 PWM / 0 - 10V settings Troubleshooting Procedure for fault messages Setting protocol Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com...
-
Page 5: General
Please read and follow the operating instructions, in particular the safety information contained therein. Keep them available next to the boiler. These operating instructions contain important information about operation, electrical connection and troubleshooting for the Lambdatronic S 3200 control. NOTICE The values given in the parameter lists are examples, and should not be used as standard values! The constant further development of our products means that there may be minor dif‐... -
Page 6: Electrical Connection And Wiring
Electrical connection and wiring Core module and connection options 2 Electrical connection and wiring 2.1 Core module and connection options 2.1.1 Board view Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 7: Connection Instructions
Boiler sensor BS (25) PDM / 0-10V Pump 1 (26) Induced draught (27) Connection cable 3 x 1.5 mm , power supply Connection cable 3 x 0.75 mm , analysis of current speed Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 8: Mains Connection
❒ The power supply line (mains connection) must be fitted with a 16A fuse by the customer. If a safety overload switch is used it should be a type with 16A. 2.1.3 Connecting the flue gas sensor green-yellow Core module red + blue - Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 9: Combination With Oil Burner
Connecting a HCP 0 up to max. 5 Ampere: Connection as burner relays: To oil boiler control: floating contact for burner Core module release 2.1.5 Valve for flue gas condenser connection Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 10: Connecting The Remote Control
Setback mode Ignores the heating phases Override circuit Ignores the setback Handwheel… Allows you to adjust the temperature by +/- 3°C IMPORTANT! See assembly instructions/functional description for room temperature sensor FRA Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 11: Connecting A High Efficiency Pump To The Core Module
➥ Make sure that the cables are configured correctly (polarity) in accordance with the connection diagram of the pump! Important! When using a Froling pump assembly: ⇨ See "Connection diagrams according to pump types" [page 20] Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 12: Expansion Modules
, max. 2.5A / 230V / 500W pump 1/2 (5) Mixing valve 1/2 (6) Connection cable 4 x 0.75mm , max. 0.15A / 230V 1. YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 13: Hydraulic Module
3 x 1.5mm , fuse 10A Pump 1/2 (10/11) Connection cable 3 x 1.5mm , max. 1.5A / 230V / 280W 1. YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5 Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 14: Connecting An Isolating Valve
Connection example: The outer cable L(bn) should be connected to the outer cable of the respective mains supply of the module or to the core module, HCP0/burner relay output at pin “LV”. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 15: Connecting A High Efficiency Pump To The Hydraulic Module
➥ Make sure that the cables are configured correctly (polarity) in accordance with the connection diagram of the pump! IMPORTANT! When using a Froling pump assembly: ⇨ See "Connection diagrams according to pump types" [page 20] Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 16: Return Mixer Module
Connection cable 3 x 1.5mm Return mixer (3) Connection cable 4 x 0.75mm , max. 0.15A / 230V 1. YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5 Connection example Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 17 Connect return mixer module and hydraulic module with bus cable Use delivered mains cable for connection to terminal block. Return sensor Core module (FRKEM 22) Hydraulic module (FRHYU 14) Mains Plug Main switch Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 18: Ignition Expansion
LIYCY paired 2x2x0.5 should be used. The connection to the 5-pin plugs should be carried out according to the following diagram: Braided shield Braided shield White White CAN L CAN L Green Green CAN H CAN H Yellow Yellow Brown Brown Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 19: Connect The Patch Cable To The Bus Plug
“not set". In this case there is no bus termination. If the contacts are closed (im‐ age right), the end jumper is set and the bus connection is terminated. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 20: Setting The Module Address
4.1 – 4.6 4.1 – 4.2 13 – 14 5.1 – 5.6 5.1 – 5.2 15 – 16 6.1 – 6.6 6.1 – 6.2 17 - 18 7.1 – 7.7 7.1 – 7.2 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 21 - brown wire to earth - white wire to plus Do not use the other two wires (blue, black) and insu‐ late if necessary Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 22: Overview Of The Basic Functions
The status LED shows the operating status of the system: ▪ GREEN flashing (interval: 5 sec OFF, 1 sec ON): Off ▪ GREEN constant: BOILER SWITCHED ON ▪ ORANGE flashing: WARNING ▪ RED flashing: FAULT Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 23: Control Icons
Back icon Takes you back up one menu level of the system menu. Can be used to return to the basic display. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 24: Display Icons
Remote control (switching the boiler on and off) by external operators via froeling-con‐ nect.com is permitted. Remote control (switching the boiler on and off) by external operators via froeling-con‐ nect.com is not permitted. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 25: Operating Statuses
(with autom. igni‐ criteria for heating status within a specified time. tion) Heating The Lambdatronic S 3200 controls combustion according to the boiler setpoints. Slumber Very low power consumption. When the boiler temperature setpoint is exceeded by a specified value, the boiler goes to "Slumber"... -
Page 26: Updating The Software Of The Touch Control
❒ Insert the USB stick with the necessary data (linux.bin; rootfs.img; update) into the USB port ❒ “Display settings” menu → “Software update / Service” ❒ Set “Restart control / Update” parameter to “Yes” ➥ Update will begin Display during the update: Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 27 NOTICE Inaccurate calibration If you do not tap the indicated points accurately, the control may stop working properly and a software update may be required. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 28: Calibrating The Touchscreen
❒ Scroll down with the down arrow until the “Software update / Service" submenu appears and open the submenu ❒ In the “Software update / Service" menu open the “Recalibrate touch con- trol” parameter Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 29 The control will restart after calibration. NOTICE Inaccurate calibration If you do not tap the indicated points accurately, the control may stop working properly and a software update may be required. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 30: Operation
❒ Check that the main fuse for the boiler has a sufficient rated amperage (16A ) ➥ If a safety overload switch is used, it should be a type with 16A. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 31: Navigation Within The Info Menu
The next time you open the system menu, the last page viewed will be dis‐ played. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 32: Navigating The Menus
The parameter list shows three parameters. The up and down arrows can be used to scroll through longer lists of parameters. If you have reached the start or end of the parameter list, the relevant arrow symbol will become inactive. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 33 Operation Navigation within the system menu Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 34: Adjusting Parameters
A parameter can only be adjusted if there is a pen icon beside it. Depending on the type of parameter, either the numeric keypad..or a list box will appear. In both cases you need to tap the confirm icon to save the entry. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 35: Setting Times
❒ The time window will open for editing ❒ Set the start and end time for the time window using the up and down arrows ❒ Save the time window setting by tapping on the confirm icon Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... - Page 36 To delete a time window, set the times so that the hour and minute displays are re‐ placed by two dashes. If you want to apply the time window setting to another day in addition, you can do this by activating the relevant day. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com...
-
Page 37: Setting The Date/Time
❒ A menu will then appear allowing you to adjust the date and time. To apply the new values you need to confirm the date and time by tapping the “confirm” icon. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 38: Quick Menu
4.7.8 "Touch cleaning” function For cleaning the touchscreen surface. The screen is disabled for 10 seconds to allow you to clean it without opening a menu or inadvertently adjusting a parameter. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 39: Initial Startup
Standard level for normal operation of the touch display. All cus‐ (Code 1) tomer-specific parameters are displayed and can be changed. Installer / Service Releases parameters to adjust the controller to the system com‐ ponents (if configured). Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 40: Setting The System Selection
Initial startup 4.8.2 Setting the system selection Open the system selection menu ❒ In the system menu open “System” ❒ Then navigate to “System selection” in the menu and open the menu Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 41: Selecting The Boiler Type
❒ In the boiler type menu select the “S4 Turbo” firewood boiler ❒ Then set the boiler output entered on the identification plate and confirm. ❒ Activate any other relevant parameters ➥ Active parameters are identifiable by the confirm icon Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... - Page 42 Adopt boiler standard val‐ If this parameter is set to "YES", the current parameters for the selected boiler are set. After the values have been adopted the parameter jumps to "NO" Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com...
-
Page 43: System Selection
For description see “ Lambdatronic S 3200 Energy Systems” brochure Variant 1 Variants 2 and 5 Multiple house diagrams Variant 3 Variant 4 Slave boiler for boiler sequence control Only for systems in the cascade! Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 44: Dhw Tank System
Otherwise, the selection table below shows the hydraulic system to be set for the spe‐ cific system: DHW tank system DHW tank 01 installed ❒ DHW tank 02 installed ❒ Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 45: Heating System
❒ The “remote control XX installed” parameter should be checked if any of the the three remote controls shown is used for the respective heating circuit. Solar system Solar collector 01 installed ❒ A second pump is used instead of the isolating valve ❒ Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 46: Boiler Remote Control
⇨ See "Digital inputs" [page 84] Drives ❒ Check that drives and actuators are working and turning in the right direction ⇨ See "Analogue outputs" [page 83] ⇨ See "Digital outputs" [page 83] Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 47: Menu Overview And Parameters
Menu overview and parameters Menu - Heating 5 Menu overview and parameters Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 48: Status Displays For The Heating Circuits
(Setback) = setback mode; the heating phases are ignored (Auto) = automatic mode; heating phases according to setback program (Off) = switched off; heating circuit deactivated, only frost protection! External temperature 2°C Shows the current external temperature Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 49: Temperature Settings For The Heating Circuits
External temperature below which 7°C If the external temperature falls below this value in setback mode, the the heating circuit pump switches on heating circuit pumps and mixing valve are activated. in setback mode Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 50: Heating Times Of The Heating Circuits
If a flow temperature setpoint is calculated below the value set here, the when flow setpoint is lower than heating circuit pump switches off and the mixing valve closes (just without remote control). Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 51: Service Parameters For Heating Up Program
YES. NOTE: Parameters for heating circuit 2 only! ⇨ See "Digital outputs" [page 83] 5.1.5 Service parameters for heating up program Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... - Page 52 Outfeed setpoint for all days in pro‐ 35°C If heating up program 7 is active, the selected heating circuit is adjusted to gram 7 the specified flow temperature. ⇨ See "Heating up programs" [page 53] Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com...
-
Page 53: Heating Up Programs
The heating up programs listed are non-binding rec‐ ommendations. If the heating up program is to be used for floor screed drying, you must consult the manufacturer of the floor finish and/or the installer Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 54: General Settings
1 on relevant module) (0 = core module) Use room temperature sensor input If room thermostats are used instead of room temperature sensors, this for room thermostat parameter must be set to YES. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 55: Menu - Water
When this DHW tank temperature is reached the DHW tank loading pump switches off. Reload if DHW tank temperature is 45°C Reloading of the DHW tank is authorised when the DHW tank temperature below is below this level. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 56: Heating Times Of The Dhw Tank
Legionella heating activated The DHW tank is heated to at least 65°C once a week. Which day for legionella heating Day of the week on which the Legionella heating is carried out. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 57: Menu - Solar
Maximum DHW tank pump speed 100% If you need to limit the maximum speed of the DHW tank pump for system‐ ic reasons, you can do so by adjusting this parameter. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 58: Status Displays For The Solar System
Specifies the speed of the collector pump as a percentage of maximum speed. Pump between heat exchanger and 100% Current speed of the pump between heat exchanger and storage tank (on‐ storage tank ly for systems 12, 13) Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 59: Temperature Settings For The Solar System
Storage tank bottom plus the set value produces the desired temperature tom differential of the collector return. If the collector return is too high, the storage tank pump speed is reduced. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 60: Service Parameters Of The Solar System
This function is active from 10:00am - 7:00pm and the threshold value of the collector temperature, from which this function is active, is dynamically adjusted. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 61 Invert isolating valve For DHW tank loading through the collector, the isolating valve is activated with 230V. If the valve switches incorrectly, the way it is controlled can be adjusted using this parameter. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 62: Solar Heat Meter
[0.5 – 5 pulses/L] Which sensor is used for the collec‐ Bus addresses of the sensors used, depending on the system tor return ⇨ See "Setting the module address" [page 20] Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 63: Menu - Storage Tank
⇨ See "Setting the module address" [page 20] Is an external flow through counter If an external volume flow sensor is used in the collector return, set this used parameter to “YES”. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 64: Status Displays Of The Storage Tank
5.4.2 Temperature settings for the storage tank Parameter Description Heating circuit release from follow‐ 30°C Minimum value of storage tank top temperature for heating circuit release ing storage tank temperature in combinations with a storage tank Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 65: Service Parameters Of The Storage Tank
If No the sensor is only a display Middle storage tank temperature sensor is used to display the temp. Middle storage tank temperature sensor is used for the border layer load‐ ing function. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 66: Menu - Boiler
Invert pump outlet for store relief If the valve switches incorrectly, the way it is controlled can be adjusted valve using this parameter. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 67: Status Displays For The Boiler
ID fan speed 2350U Primary air Position of primary air flap Secondary air Position of secondary air flap Sensor 1 66°C Return feed sensor 58°C 5.5.2 Temperature settings for the boiler Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 68: Service Parameters Of The Boiler
❒ Recommendation to reduce mixer vibration Do not set to < 150 s Output fire off message using HKP0 If the boiler changes to "Off" status, the HKP0 output is closed. 5.5.4 General Settings Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 69: Operator Data
Customer no. 263586 If both the customer and the boiler number are set, they are automatically transferred into the commissioning report when it is saved. Boiler number Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 70: Menu - Boiler
Standby boiler start, if storage tank 20°C Temperature at the top of the storage tank, which the temperature must top temperature is below fall below for the standby boiler to be activated Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 71: Service Parameters Of The Backup Boiler
Invert backup boiler isolating valve For DHW tank loading through the backup boiler, the isolating valve is ac‐ tivated with 230V. If the valve switches incorrectly, this parameter can be adjusted. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 72: Menu - Ignition
Menu overview and parameters Menu - Ignition Parameter Description Which second boiler is installed? Oil boil‐ Standby boiler type: - - OIL BOILER - MANUALLY FED - AUT. FED - GAS BOILER Burner relays Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 73 ▪ Ext. release: If the boiler release contact is closed at the core module, ignition starts ▪ Buffer tank min: see parameter "Ignition time" ▪ Storage tank < outfeed max: see parameter "Ignition time" Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 74: Menu - Network Pump
Maximum ign. duration 15 m Specifies how long the ignition procedure should last. "Heating" status must be reached within this time. ⇨ See "Temperature settings for the storage tank" [page 64] Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 75: Network Pump Status Displays
Return temperature setpoint 50°C Note the information on multiple house diagrams in the “Lambdatronic S at feeder 1 3200 energy systems" documents. Return temperature setpoint 50°C at feeder 2 Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 76: Service Parameters For The Network Pump
1 ⇨ See "Setting the module address" [page 20] Observe the information on hydraulic systems in the "Lambdatronic S Which pump is used for 3200 energy systems" documents. feeder 1 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 77: Menu - Difference Regulator
Maximum speed for feeder pump 1 100% If you need to limit the maximum speed of the storage tank pump for sys‐ temic reasons, you can do so by adjusting this parameter. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 78: Status Displays For The Difference Regulator
Temperature settings for regulating range of the differential temperature source regulating output. Maximum temperature for 100°C The standard settings of 10°C or 100°C are selected so that the values in heat sink normal operation stay outside a limit. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 79: Service Parameters For The Difference Regulator
Which sensor is used for the heat sink 3200 energy systems" documents. Sensor monitoring If relatively low temperatures (< 5°C) occur when using the diff. controller, setting the parameter to “NO” suppresses the error message Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 80: Status Displays For The Circulation Pump
0 ... No flow at the valve 1 ... Valve registers flow Speed of the 100% Current circulation pump speed circulation pump 5.10.2 Temperature settings for the circulation pump Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 81: Time Settings For The Circulation Pump
If the flow valve does not register any more flow, the circulation pump car‐ ries on running for the time set. 5.10.3 Time settings for the circulation pump ⇨ See "Setting times" [page 35] 5.10.4 Service parameters of the circulation pump Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 82: Menu - Manual
Maximum speed of the circulation 100% If you need to limit the maximum speed of the circulation pump for system‐ pump ic reasons, you can do so by adjusting this parameter. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 83: Digital Outputs
Lambda probe heating -A 0 … automatic, OFF Heating circuit pump 0 -A 1 … automatic, ON 0 … MANUAL, OFF 1 … MANUAL, ON Valve for condenser 5.11.2 Analogue outputs Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 84: Digital Inputs
The parameters displayed vary depending on the configuration. Hi-limit stat input E-stop input A … Automatic Boiler enable -A 0 … Automatic, OFF -A 1 … Automatic, ON 0... Manual, OFF 1 ... Manual, ON Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 85: Menu - System
Minimum boiler temperature to re‐ 65°C The pumps are activated at this boiler temperature. (Hysteresis 2°C) lease all pumps Minimum return temperature 60°C The minimum temperature required of the return to the boiler. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 86: Adjustable Parameters: Flue Gas
If the flue gas temperature is below this value for the duration of the maxi‐ boiler switches to OFF status mum heating up time, the boiler switches to "Off" status. Desired work point of flue gas tem‐ 180°C perature Calorific value HE Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 87: Adjustable Parameters - Ignition
▪ Ext. release: If the boiler release contact is closed at the core module, ignition starts ▪ Buffer tank min: see parameter "Ignition time" ▪ Storage tank < outfeed max: see parameter "Ignition time" Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 88: Adjustable Parameters: Air Settings
Adjusts the minimum speed of the fan used ID fan min Base point for setting the ID fan characteristic curve ID fan max End point for setting the ID fan characteristic curve Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 89: Adjustable Parameters: Lambda Values
If the residual oxygen content at "Heating" status rises above this value, which it switches to SHUTDOWN after the maximum heating up time has elapsed the control switches to status "Off" status. Adjustable parameters: Lambda values - LSM11 Lambda probe Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 90: Adjustable Parameters: Lambda Values - Broadband Probe
0.00A Display of the current values for the relevant broadband probe parameter Broadband probe heating voltage 0.00V Broadband probe Nernst 0.000V voltage Broadband probe pump current 0.000m Broadband probe internal resistance Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 91 ❒ Set parameter to "YES" and press the enter key ➥ Automatic calibration of the broadband probe begins ➥ Once calibration is complete the parameter is automatically set to "NO" and the broadband probe is ready for use Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 92: Adjustable Parameters: General Settings
Set hours since last maintenance to To reset the counter “Hours since last maintenance”, this parame‐ ter must be set to "YES”. After the has been reset, the parameter jumps to "NO”. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 93: Current Values
Service hours in slumber Ignition service hours Ignition starts Software version Version: 50.04 Build: 05.09 Cust. no.: 263586 System operator data Boiler no.: 560 Service hours of boiler 2 (burner contact) Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 94: Sensors And Pumps
The display of the parameters varies depending on the system set. Which sensor is used for bottom storage tank Note the information on hydraulic systems in the "Lambdatronic S 3200 energy systems" documents. Which pump is used for the storage tank... -
Page 95: Display Operating Rights
Allocate access rights for changing solar system parameters to the individ‐ ual controls. Tap Solar 01 to activate the access rights of the solar system for the con‐ trol. This is indicated when the “Confirm” icon appears. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 96: Froeling Connect
Deviation of room sensor from touch 0°C display with address 7 Deviation of room sensor from but‐ 0°C ton display with address 1 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 97: System Selection
DHW tank: Button display with address 7 is al‐ None located to the following DHW tank: 5.12.6 System selection ⇨ See "Setting the system selection" [page 40] Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 98: Menu - Diagnostics
Menu - Diagnostics 5.13 Menu - Diagnostics ⇨ See "Navigation within the system menu" [page 31] 5.13.1 Error display ⇨ See "Troubleshooting" [page 104] 5.13.2 Error history ⇨ See "Troubleshooting" [page 104] Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 99: Clear Error History
This is the time the error occurred. This is the time the error was acknowledged. This is the time the error was rectified. 5.13.3 Clear error history Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 100: Menu - Display Settings
Module address 0: Boiler console Module address 1-7: respective RBG Touch Once you have changed the module address, you will need to restart the boiler controller (switch main switch on boiler off and on). Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 101: Network Settings
192.168.0.10 If the parameter “Use DHCP” is set to “NO”, the adjacent settings are re‐ leased for editing. Subnet mask 255.255.255.0 Default gateway: 0.0.0.0 DNS server 0.0.0.0 5.14.2 Date / Time ⇨ See "Setting the date/time" [page 37] Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 102: Software Update / Service
Menu overview and parameters Menu - Display settings 5.14.3 Software update / Service ⇨ See "Updating the software of the touch control" [page 26] Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... -
Page 103: Pwm / 0 - 10V Settings
The same functions that apply with PDM apply to the parameter values with 0-10V. The only difference is that instead of pulse duration modulation, a 0-10V signal is used to control the pump. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en... -
Page 104: Troubleshooting
The “Error display” button will now appear in the quick menu. 6.1 Procedure for fault messages If you open the window with the respective fault text, the right arrow will take you to possible causes of the fault. Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 105 Tapping “Solution” will also display action to be taken to resolve the problem. If there are several options available, these will be listed one below the other. Once the fault has been resolved, tap the Cancel icon to return to the basic display. Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
-
Page 106: Setting Protocol
Below the heating circuit number it notes the heating area, for which this heating cir‐ cuit is used. The relevant connected unit should be noted next to the pumps or sen‐ sors. Example: Module address = 2; Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com... - Page 107 Sensor 2.4 Heating circuit module Sensor 2.5 Sensor 2.6 Bus cable correctly connected (see “Connecting the bus cable”)) Final check Addressing correctly carried out and recorded Jumper placed at the last module Operating Instructions Lambdatronic S 3200 - Touch | B0840314_en...
