  • Page 1 B-Box H Installation B-Box H Installation V1.0 2017-10-28...

  • Page 2: Table Of Contents

    B-Box H Installation Contents Before Installation Unpacking Bracket Installation Base Installation B-Plus-H Installation Cables Connection Update firmware & Enter User information...

  • Page 3: Before Installation

    B-Box H Installation Before Installation Prepare tools for installation Impact drill Inner hexagon spanner Cross screwdriver level M3~M10 Crimping pliers Crimping modular plier Adjustable wrench Cable stripping clamp...

  • Page 4: Unpacking

    B-Box H Installation Unpacking...
  • Page 5 B-Box H Installation Unpacking Pearl cotton Battery (B-Plus-H) Pearl cotton Carton...

  • Page 6: Bracket Installation

    B-Box H Installation Bracket Installation If you receive a different Bracket from this one. Please do not use it B-Plus-H Quantity Bottom hole height(mm) H 1028 1148 1268...

  • Page 7: Base Installation

    B-Box H Installation Base Installation  Put the base under Bracket,  Adjust the balance of the base...

  • Page 8: Plus-H Installation

    B-Box H Installation B-Plus-H & BCU Installation...
  • Page 9 B-Box H Installation B-Plus-H & BCU Installation...
  • Page 10 B-Box H Installation B-Plus-H & BCU Installation...
  • Page 11 B-Box H Installation Cables Connection Open the cover of the BCU...
  • Page 12 B-Box H Installation Cables Connection...
  • Page 13 B-Box H Installation Cables Connection 6.1 RJ-45 plugs Connection internet Route the network cable through the terminals and Connect RJ-45 plugs...
  • Page 14 B-Box H Installation Cables Connection 6.2 Communication Cable Connection...
  • Page 15 B-Box H Installation Cables Connection 6.3 Ground Connection...

  • Page 16: Cables Connection

    B-Box H Installation Cables Connection 6.4 Power Cables Connection...
  • Page 17 B-Box H Installation Cables Connection 6.5 Cover & Bracket Installation...
  • Page 18 B-Box H Installation Cables Connection 6.6 BCU Installation B-Plus-H Base...

  • Page 19: Update Firmware & Enter User Information

    B-Box H Installation Update firmware & Enter User information 7.1 Download firmware Log in to the following website to download the latest firmware. https://pan.baidu.com/s/1eR3JD6M...
  • Page 20 B-Box H Installation Update firmware & Enter User information 7.2 Turn on the Switch ( with the inverter off)
  • Page 21 B-Box H Installation Update firmware & Enter User information 7.3 WIFI Connection Name: BYD********-00001 Password: 123456789...
  • Page 22 B-Box H Installation Update firmware & Enter User information 7.4 Log in to the installation page. (URL: 192.168.5.1 Username: installer Password: byd@12345) Upgrade After the Update firmware, B-Box H will restart. Please re-connect WIFI and continue to the next step.
  • Page 23 B-Box H Installation Update firmware & Enter User information ☆The user information is very important. 7.5 Enter the user information. User Information Apply...
  • Page 24 B-Box H Installation Update firmware & Enter User information ☆The user information is very important. 7.5 Enter the user information. bboxhserver.byd.com.cn Server Ip Address： Address postion (We recommend using the Iphone compass to obtain latitude and longitude) Latitude:( If in the southern hemisphere, please add...
  • Page 25 B-Box H Installation Update firmware & Enter User information ☆The user information is very important. 7.5 Enter the user information. ☆If this number is different from the actual number of batteries, the system will not work. Series Battery Count...
  • Page 26 B-Box H Installation Update firmware & Enter User information ☆The user information is very important. 7.5 Enter the user information. ☆If this number is different from the actual number of batteries, the system will not work.
  • Page 27 B-Box H Installation After installation Make sure the cable Installation is right Make sure the B-Box H firmware is new Make sure the inverter firmware is new Please connect B-Box H to the Internet, otherwise it may shorten the warranty date.
