Elsema PentaFOB series User Manual

FOB4 3 3 0 3 W P
®
433MHz PentaFOB series Remotes with Frequency Hopping

FEATURES

 3-channel PentaFOB
 Transmission on 5 different frequencies
 Uses frequency hopping spread spectrum (FHSS)
 One of the most secure remote controls on the market
 Competitive pricing

APPLICATIONS

 Keyless access control for automatic gates and roller doors
 Warehouse automation i.e. Roller doors, Cooler room doors..... and anywhere else you need a wireless
signal to transmit a contact closure

DESCRIPTION

®
The PentaFOB uses frequency hopping spread spectrum (FHSS), making it impossible for the remote to be
interfered with or jammed. The keyring retainer is moulded as part of the chassis making for a super sturdy
keyring mount.
The PentaFOB® series is an extremely versatile remote control that can be customized through a range of
configurations and colours to suit your needs.

FREQUENCY HOPPING

®
The PentaFOB remotes use frequency hopping spread spectrum (FHSS). When a button is pressed, it
simultaneously transmits the code on 5 different frequencies, making it impossible for the remote to be
interfered with or jammed. This allows multiple transmitters to be used in close proximity with no interference
or jamming.

TECHNICAL DATA

Operating Voltage
Standby Current
Current Consumption
Battery life
Frequencies
Operating range
Operating Temperature Range -5 to 50°C
Decoding System
Dimensions
Weight
®
remote
CR2032 Battery
1.8uA
18mA (typical) when transmitting
1.5 years with average use
433.100 to 434.700MHz
up to 120 metres depending on building structure and receiver antenna
Encrypted 17 billion codes combinations
72 x 43 x 16 mm
40 grams
433MHz Keyring Remote with Frequency Hopping – PentaFOB
