Tools needed: Metric hex wrench set (lock tight is optional).
Parts Supplied:
Number
1
2
3
4
Assembly Instructions
Shop Press Guard
HW93625
Description/ Part Number
1.5" X 1.5" X 84" Grooved Vertical Frame Piece
1.5" X 1.5" X 37" Grooved Horizontal Frame Piece
1.5" X 1.5" X 36.5" Grooved Vertical Screen Frame
Piece
1.5" X 1.5" X 34" Grooved Horizontal Screen Frame
Piece
10939 N. Pomona Ave. Kansas City, MO 64153
customerservices@heinwerner-automotive.com
Quantity
1
2
2
2
SFA Companies
HW93425-M0_022013
Advertisement
Related Manuals for HEIN-WERNER AUTOMOTIVE HW93625
Summary of Contents for HEIN-WERNER AUTOMOTIVE HW93625
-
Page 1: Assembly Instructions
Assembly Instructions Shop Press Guard HW93625 Tools needed: Metric hex wrench set (lock tight is optional). Parts Supplied: Number Picture Description/ Part Number Quantity 1.5” X 1.5” X 84” Grooved Vertical Frame Piece 1.5” X 1.5” X 37” Grooved Horizontal Frame Piece 1.5”... - Page 2 Number Picture Description/ Part Number Quantity 15CB4804 15CB4801 15CP0101 13AC7302 15AC7105 15FA3501...
- Page 3 Number Picture Description/ Part Number Quantity 13CP0698 13FA3117 15CM0398 15FAC3888 13FA3331 13FA3324 13CP0706 13FA3700 13FA3113...
- Page 4 Number Picture Description/ Part Number Amount 1.5” X 1.5” X 84” Grooved Frame Vertical Frame Piece with Holes Screen 35” X 35” Steps For Assembly Step 1: Step 2: Slide part #10 (as seen) into slot A and position half way down Put the screen in the middle slot on one of the sides of part part #3.
- Page 5 Step 3: Step 6: Line up hole A with hole in part #10, make sure hole B is not Slide in one part C (that comes with handle) in part #4 (same over the hatching of the screen. Bolt part #15 into hole A and as in step 2).
- Page 6 Step 9: Step 11: Attach part #9 using steps 2 and 3 for part #4. Step 10: Line up holes that the F bolts came out of with hole AA on a part #3 and hole BB on a part #4. Using bolt F (that comes with part #7) bolt part #7 on frame.
- Page 7 Step 13: Step 15: 4.25 Repeat steps 10 through 12 for the other 3 corners. Step 14: Place the screen assembly between the frames that were laid out in step 14. Make sure that the screen assembly is approxi- mently 4.25 inches from the top of the frame. Step 16: 30.00 On right hand side of screen frame line up hole DD with holes of the...
- Page 8 Step 17 Step 21: INSIDE BOTTOM Slide part # 14 into inside bottom of part #1 (Part #14 may need to loosen bolt). Slide part #2 in between part #1 and other Slide two part #10’s in the top of the outer most slot on part outer frame piece, allowing for circular part of 14 to enter hole #1, make sure that the extruded part of #10 is facing the front GG.
