Operating Instructions & Parts Manual
Model Number
HW93300,(hand operated pump)
HW93301 (air operated pump)
HW93302,(electric pump)
HW93305,(double acting, hand operated pump)
HW93306,(double acting, electric pump)
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
HW93300-M0_032013
Model HW93300 shown
WARNING
!
To avoid crushing and projectile injuries:
• An ASME B15.1-2000 compliant guard
shall be installed on this device before use.
• Wear personal protective equipment when
operating this equipment.
Shop Press
Capacity
25 Ton
10939 N. Pomona Ave. Kansas City, MO 64153
customerservices@heinwerner-automotive.com
SFA Companies
Printed in U.S.A
Advertisement
Table of Contents
Related Manuals for HEIN-WERNER AUTOMOTIVE HW93301
Summary of Contents for HEIN-WERNER AUTOMOTIVE HW93301
- Page 1 Shop Press Operating Instructions & Parts Manual Model Number Capacity HW93300,(hand operated pump) HW93301 (air operated pump) HW93302,(electric pump) 25 Ton HW93305,(double acting, hand operated pump) HW93306,(double acting, electric pump) Model HW93300 shown This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 2: Safety And General Information
WARNING • Study, understand, and follow all instructions before operating the device. • Do not exceed rated capacity. • Prior to use, make sure press is securely anchored. • The press shall be installed and operated in accordance with federal (OSHA), state and local safety standards. •... -
Page 3: Specifications
Figure 1 - Typical Shop Press Components Arbor Plates Support Pin (not included Bed Frame with press) Upright Channel Lower Cross Member Base Air Pump (Model HW93301) SPECIFICATIONS Rated Press Bed Press Bed Min. Work Max. Work Press Pump Model/... -
Page 4: Operation
Air Pumps Oil Output Flow Rate Usable Oil Pressure Rating Input Air Pressure Weight /min) Air Pump Model Volume (in (psi) Range (psi) (lbs) No Load Load PA1500 91.5 10,000 110 - 175 18.1 Electric Pumps Pressure Rating Oil Output Flow Rate Electric Reservoir Motor... -
Page 5: Maintenance
To retract, simply open the release valve of pump. b) For Model HW93301 (air): Connect to suitable air supply, press on the foot pedal to extend the cylinder ram. To retract, simply press the release valve by stepping on the raised, stirrup shaped portion of the foot pedal. -
Page 6: Troubleshooting
TROUBLESHOOTING A system failure may or may not be the result of a pump malfunction. The following information is intended to be used as an aid in determining if a problem exists. Contact a Hein-Werner authorized service center for repair. Symptom Possible Causes Corrective Action... - Page 7 Pump Mounting Hardware Kit 300-002-017 Hardware Kit HW93300-M0 OIPM HW93300-L1 HW93305-L1 HW93301-L1 HW93302-L1 HW93306-L1 Label Kit * Qty 2 for HW93305 and HW93306 Double Acting Presses 17(b) P2301M Hand Pump for Model HW93305 17(a) P1000 Hand Pump for Model HW93300...
-
Page 8: Two Year Limited Warranty
TWO YEAR LIMITED WARRANTY For a period of two (2) years from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
