4.2 Tractor Requirements

WARNING
Tractor Owner/Operator Manual
Always refer to the tractor Operator's Manual
to ensure compatibility and maximum safety.
The tractor used to operate the bale unroller must have
the power to lift and pull the bale while traveling at a
ground speed between 2 and 5 MPH.
The power required to operate the bale unroller is
determined by the tractor PTO horsepower. Operating
the bale unroller with a tractor that does not have
adequate power may damage the tractor engine.
Model
9300BU
Always review the "controls" section of the tractor
Operator's Manual to be familiar with the location,
settings, and function of the tractor controls. Be
familiar with all controls before using this equipment.

4.2.1 Tractor Safety Devices

If transporting or operating the tractor and implement
near a public roadway, the tractor must be equipped
with proper warning lighting and a Slow Moving Vehicle
(SMV) emblem which are clearly visible from the rear of
the unit. Lights and a SMV emblem must be attached
directly to the implement if the visibility of the tractor
warning signals are obscured.
Never operate the tractor PTO with the PTO master
shield missing or in the raised position.
9300BU Bale Unroller
January 2016
Recommended
Min. HP
25 - 65
16

4.2.2 ROPS and Seat Belt

WARNING
Rollover Hazard
To avoid serious injury or death from
falling off tractor, equipment runover,
rollover, or crushing:
1) Use ROPS equipped tractor.
2) Keep ROPS locked in the UP position.
3) Only operate the equipment when seated in the
tractor seat.
4) Always fasten seat belt when operating the tractor
and bale unroller.
The tractor must be equipped with a Roll Over
Protective Structure (ROPS) (tractor cab or roll bar)
and seat belt to protect the operator from falling off the
tractor, especially during a roll-over where the driver
could be crushed and killed. Only operate the tractor
with the ROPS in the raised position and seat belt
fastened.

4.2.3 3-Point Hitch

The bale unroller is recommended for use on Category
II tractors with a 3 point hitch or a standard Category II
quick hitch.
It will also work on larger Category I tractors for
handling small size bales, if the Category I tractor is
properly equipped with front end weights.
Refer to the tractor Operator's Manual for the category
of the tractor being used. If the hitch does not conform
to ASABE CAT I/ll dimensions, the bale unroller may
not fi t or raise properly. Consult an authorized dealer
for possible modifi cation procedures to mount non-
conforming hitches. Depending on the hitch category,
certain size pins are used to attach the implement to
the tractor. CAT I hitches require 7/8" lower and 3/4"
upper diameter hitch pins. CAT Il hitches require 1-1/8"
lower and 1" upper diameter hitch pins.
