6.3

Moisture Sensitivity Level (MSL)

Module is qualified to Moisture Sensitivity Level (MSL) 3 in accordance with JEDEC J-STD-033.
If the prescribed time limit is exceeded, users should bake modules for 192 hours in drying
equipment (<5% RH) at 40+5/-0°C, or 72 hours at 85+5/-5°C. Note that plastic tray is not
heat-resistant, and only can be baked at 45° C.
Table 35: Moisture Sensitivity Level and Floor Life
Moisture Sensitivity Level
(MSL)
1
2
2a
3
4
5
5a
6
NOTE: IPC / JEDEC J-STD-033 standard must be followed for production and storage.
6.4

Stencil Foil Design Recommendation

The recommended thickness of stencil foil is more than 0.1mm.
SIM7600A-H_User Manual_V1.00
Floor Life (out of bag) at factory ambient≤30°C/60% RH or as
stated
Unlimited at 30 /85% RH
≦ ℃
1 year
4 weeks
168 hours
72 hours
48 hours
24 hours
Mandatory bake before use. After bake, it must be reflowed within the
time limit specified on the label.
