The operating temperature of Module is listed in the following table.
Table 31: Operating temperature
Parameter
Normal operation temperature
Extended operation temperature*
Storage temperature
*Note: Module is able to make and receive voice calls, data calls, SMS and make
WCDMA/HSPA+/LTE traffic in -40℃ ~ +85℃. The performance will be reduced slightly from
the 3GPP specifications if the temperature is outside the normal operating temperature range
and still within the extreme operating temperature range.
5.3

Operating Mode

5.3.1

Operating Mode Definition

The table belowsummarizes the various operating modes of Module series products.
Table 32: Operating mode Definitions
Mode
GSM/WCDMA / LTE
Sleep
GSM/WCDMA / LTE
Idle
GSM/WCDMA / LTE
Talk
GSM/WCDMA/LTE
Standby
GPRS/EDGE/WCDM
A / LTE transmission
Minimum functionality
mode
Flight mode
SIM7600A-H_User Manual_V1.00
Min.
-30
-40
-45
Function
In this case, the current consumption of module will be reduced to the
minimal level and the module can still receive paging message and
SMS.
Software is active. Module is registered to the network, and the
module is ready to communicate.
Connection between two subscribers is in progress. In this case, the
power consumption depends on network settings such as DTX off/on,
FR/EFR/HR, hopping sequences, antenna.
Module is ready for data transmission, but no data is currently sent or
received. In this case, power consumption depends on network
settings.
There is data transmission in progress. In this case, power
consumption is related to network settings (e.g. power control level);
uplink/downlink data rates, etc.
AT command "AT+CFUN=0" can be used to set the module to a
minimum functionality mode without removing the power supply. In
this mode, the RF part of the module will not work and the USIM
card will not be accessible, but the serial port and USB port are still
accessible. The power consumption in this mode is lower than normal
mode.
AT command "AT+CFUN=4" or pulling down the FLIGHTMODE
pin can be used to set the module to flight mode without removing the
Smart Machine Smart Decision
Typ. Max.
25 80
25 85
25 +90
45
Unit
℃
℃
℃
2017-11-24
