RF Specifications
4.1

WCDMA/LTE RF Specifications

Table 21: Conducted transmission power
Frequency
WCDMA B2
WCDMA B5
LTE-FDD B2
LTE-FDD B4
LTE-FDD B12
Table 22: Operating frequencies
Frequency
WCDMA B2
WCDMA B5
LTE-FDD B2
LTE-FDD B4
LTE-FDD B12
Table 23: Conducted receive sensitivity
Frequency
WCDMA B2
WCDMA B5
LTE
Table 24: Reference sensitivity (QPSK)
E-UTRA
band
1.4 MHz
2 -102.7
4 -104.7
12 -101.7
SIM7600A-H_User Manual_V1.00
Power
24dBm +1/-3dB
24dBm +1/-3dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
Receiving
1930~1990 MHz
869~894 MHz
1930 ~1990 MHz
2110~2155 MHz
729~746 MHz
Receive sensitivity(Typical)
< -110dBm
< -110dBm
See table 24
3GPP standard
3MHz 5MHz 10MHz
-99.7 -98 -95
-101.7 -100 -97
-98.7 -97 -94
Smart Machine Smart Decision
Min.
<-50dBm
<-50dBm
<-40dBm
<-40dBm
<-40dBm
Transmission
1850~1910 MHz
824~849 MHz
1850 ~1910 MHz
1710 ~1755 MHz
699 ~716 MHz
Receive sensitivity(MAX)
Test value 3GPP standard
10 MHz 15 MHz
-101 -93.2
-102 -95.2
-101.5
37
3GPP
3GPP
3GPP
Duplex
20 MHz
-92 FDD
-94 FDD
FDD
