ERONE 318W
SETW 318AM2
RADIOCOMANDI
Thank you for choosing a product Erone.You are recommended to
readcarefullythismanualbeforeinstallingtheproduct.
CONTENTS
1 - TRANSMITTER INTRODUCTION
1A-Generalinformation
1 B - Technical specifications
1 C - Main features
1A-Generalinformation
The radiocontrol ERONE 318W type SETW318AM2is an AM/ASK
modulation mini transmitter, operating at 318 MHz, which has
been designed for the automatic closing systems control, anti-
burglar systems and access control systems. The code sent by the
transmitter includes a 14 bit security code, which allows up to 2
securitycode combinations and 6 bit of facilitycodewhichallows
up to 2 different locations.
6
The receiver ERONE 318W type SELWR318 which operates with
this transmitter has a Wiegand 26 format output, suitable with
any type of access control system, equipped with this type of
protocol. The CR 2016 lithium batteries have a life of about 18
months. The product fully complies with the European Directives
99/5/CE, 89/336/CEE, 73/23/CEE and with the Part 15 of FCC
Regulations.
1B - Technical specifications
Operating frequency
318 MHz
Number of keys:
2
Power supply
6 Vdc
Battery :
2 x 3V lithium batteries CR2016
Battery life:
18
÷
24 months
Current consumption :
13 mA
Code combinations :
2
14
Different Facilities number
2
6
Modulation :
AM / ASK
Rated e.r.p. :
100 ÷ 150 µW
Range in free space:
100
÷
Operating temperature:
-20 ÷ + 55 °C
Overall dimensions:
61 x 36 x 16 mm
Weight:
20 gr.
Automatic deactivation time
3 sec.
1C - Main features
Red
Push-button A
LED
Battery
door
14
Key holder
Push-button B
ring
200 m
