Silent Alert MM4A-2212-EU-LEAD Quick Start Manual

Quick start guide Mini Monitor with lead
mobile phone detector
Mobile phone activation
Action on Hearing Loss
B9250 mobile phone sensor product
2.
Install a 9 volt PP3 alkaline or lithium battery
making sure to observe the correct polarity.
CCD4A-2220-EU
CARE CALL
MINI MAGNETIC
DOOR MONITOR
USE ALKALINE PP3
9 V BATTERY ONLY
Batch 06/01/14
PP3 Battery www.silent-alert.co.uk
Clofield Ltd. UK
Tel: 01246-260045
Keys 1-4 System
Channel
Key 5=10 Sec Delay
Key 6=20 Sec Delay
Keys 5+6=30 Sec Delay
Key 7 Leave ON
Key 8 Not Used
USE WITH MAGNET SUPPLIED
To repeat the battery check remove the battery, press the test
button then re-insert the battery to start the sequence again.
4.
Place the sensor onto your device's screen.
When installing the sensor make sure the cable
doesn't cause a trip hazard.
WARNING! Your device and its accessories are not toys. They may contain small parts. Keep them out of the reach of small children.
Jack plug
Phone sensor
When a battery is first fitted the
indicator light will flash red then
green a few times then light
solid green & pause briefly.
The light will then will flash
green several times to show the
battery voltage.
9 flashes = 9Volts in the battery.
If the light flashes red at this
point the battery is flat
and will need to be replaced.
WARNING
Any questions? Call us on 01246 450789
3.
The monitor is activated using a jelly bean switch.
Plug the switch plug into the socket on
The connection can be taped for added security
The monitor may transmit the first time the connection is
5.
When you receive a call the display will illuminate and
Peter Calling
01234 567 890
Decline
Answer
Silent
Alert
Screw cap
Status light
Test button
CCD4A-2220-EU
Configuration CARE CALL
MINI MAGNETIC
DOOR MONITOR
USE ALKALINE PP3
9 V BATTERY ONLY
switch Cover
Batch 06/01/14
www.silent-alert.co.uk
Clofield Ltd. UK
Tel: 01246-260045
Keys 1-4 System
PP3 battery
Key 5=10 Sec Delay
Key 6=20 Sec Delay
Keys 5+6=30 Sec Delay
contacts
Key 7 Leave ON
Key 8 Not Used
Screw cap
Pressure pad
socket
Configuration switches shown
with cover removed. Do not alter
these without referring to page 2
the monitor.
if required.
made, this is normal.
trigger the Mini Monitor
Silent Alert
TM
Fire Safe
Compatible
TM
