Room Temperature Sensor RTS-424 (Rev 4.2) Installation & Application Guide

Model Numbers

Product Number Product Description
RTS-424 Standard Model (with default button icons and no backlighting)
RTS-424B Standard Model (with default button icons, c/w backlighting)
Button icons:
Bottom 2 buttons are

Package Contents

•
RTS-424 Room Temperature Sensor
•
RTS-424 Installation Guide

Other Relevant Documents

•
RTS-424 Application Guide
•
RS-485 Network Installation Guide (DOC818-11)
•
Intellicon Zone Controller User Manual ( Overview of Intelli-Stat Sensor and Interface Pg IMX3-2)

Important Information

The RTS-424 does not use the 8 VDC power for Intelli-stats, the RTS-424 requires a 24 VAC or 24 VDC
power supply, which must be different from the power supply used for Intelli-Con or DCU panels.
This device will only communicate over the Intelli-stat network of V2 panels which have an Intelli-stat port.
The following controllers are compatible with RTS-424:
•
DCU-050 c/w DXC-053
•
ICP-015 Intelli-Con Turbo Panel
•
ICP-025 Intelli-Con Mini-Turbo Panel
•
ICP-04x Intelli-Con Micro Panel
•
IZD-204 Digital Zone Controller
•
IZD-206 Digital Zone Controller
•
IZA-218 Analog Zone Controller
•
IZC-230 VAV/VVT Controller
•
IZU-240 Programmable Zone Controller
•
Toshiba based Application Controllers loaded with V2 firmware
The RTS-424 is NOT upgradeable to a DNS-24.
The RTS-424 button arrangement for programming is slightly different than the button arrangement of the
Page 2 of 8
and (Setpoint Adjust), top 2 are O and I
Document Edition 1.1
