Display error list / list of actions

1
2
5
3
4
1 Error list
– The current error is marked with (*). If there is no (*), the
current error is undefined.
– Display list of measures by clicking an error.
 Error description
3 Flash code
4 One or several measures to rectify the error
5 Group error with "]" – meaning depending on test object.
Combi – Simultaneous occurrence of errors within
a data package.
Mover® – The same error occurred several times in sequence.
Save error list
The error list can be saved to communicate with Truma.
1
<File name>.tef – .tef. = expansion of the file name for the
binary error protocol.
Reset errors
The menu item "Reset errors" is only active if the error
list has been filed beforehand in the file system with
"Save error list".
1
14
1 Click the "File" menu
and select "Save at".
– Accept or change
<file name>.
– Click "Save".
1 Click the dialogue
"Tools" and select
"Reset errors".
The error memory in
the device is reset
(deleted).
End program
1
Unlock
Prerequisites for operation:
Device from index
Combi 4 (E) 4/1A
Combi 6 (E)
4/1
Combi D 6/07
Mover® –
Recognition of locked / unlocked control unit
A locked / unlocked control unit is marked by a symbol
and text.
1
2
So that the device can be unlocked, the previously specified
work steps need to be observed.
1
The unlock function does not delete the error memory.
Delete the entries in the error memory with "Reset errors".
1 Open the menu "File"
and leave the program
by pressing "End".
– Disconnect the diag-
nosis cable from the
test object.
– Switch device off.
6/1A 4/11 6/11
6/1 4/13 6/13
4/01
1 Symbol for a locked
control unit.
 Symbol for an unlocked
control unit.
3 Text
3
1 Click the menu "Tools"
and select "Unlock".
– A checklist with work
instructions is shown.
– Work through the
checklist and confirm.
– Click "Unlock".
