Ford F-150 RAPTOR 2018 Owner's Manual Supplement
  1. Manuals
  2. Brands
  3. Ford Manuals
  4. Trucks
  5. F-150 RAPTOR 2018
  6. Owner's manual supplement

Ford F-150 RAPTOR 2018 Owner's Manual Supplement

Hide thumbs
Table of Contents

Advertisement

Quick Links

October 2017
Second Printing
F-150 Supplement
Raptor
Litho in USA
JL3J 19A285 AA
owner.ford.com (U.S.)
ford.ca (Canada)
This Supplement is not intended to
replace your vehicle Owner's Manual
which contains more detailed
information concerning the features
of your vehicle, as well as important
safety warnings designed to help
reduce the risk of injury to you and
your passengers. Please read your
entire Owner's Manual carefully as
you begin learning about your new
vehicle and refer to the appropriate
sections when questions arise.
All information contained in this
supplement was accurate at the time
of publication. We reserve the right
to change features, operation
and/or functionality of any vehicle
specification at any time. Your Ford
dealer is the best source for the most
current information. For detailed
operating and safety information,
please consult your Owner's Manual.
2 0 1 8 F O R D F - 1 5 0 R A P T O R
S U P P L E M E N T
10/7PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-150 RAPTOR 2018 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ford F-150 RAPTOR 2018

Summary of Contents for Ford F-150 RAPTOR 2018

  • Page 1 We reserve the right to change features, operation and/or functionality of any vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
  • Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2017 All rights reserved. Part Number: 201709 20170926153004...

  • Page 4: Table Of Contents

    Table of Contents Introduction Wheels and Tires About This Supplement.........3 Wheels...............38 Special Notices..........3 Tire Care............38 SVT.................4 Capacities and Specific- Ford Performance..........4 ations At a Glance Engine Specifications........41 Motorcraft Parts..........41 Unique Features..........6 Capacities and Specifications....42 Information Displays Accessories General Information........8 Auxiliary Switches..........47 Information Messages........8...
  • Page 5 F-150 (TFC) Canada/United States of America, enUSA, Edition date: 201709, Second Printing...

  • Page 6: Introduction

    Thank you for choosing Ford Performance. to you on your vehicle. If you have owned or leased a Ford Performance vehicle before, welcome back. If this is your first Ford Performance SPECIAL NOTICES vehicle, welcome to the family.

  • Page 7: Svt

    Connector (DLC) that is used in conjunction with a diagnostic scan tool for The Special Vehicle Team (SVT) was vehicle diagnostics, repairs and established in 1991 to polish the Ford Oval reprogramming services. Installing an by creating low-volume, factory-produced aftermarket device that uses the DLC...
  • Page 8 Introduction vehicles, parts, accessories and across Ford s product portfolio. experiences for enthusiasts. This includes We are proud and passionate about what accelerating the development of advanced we do and we look forward to a long and aerodynamics, lightweighting, electronics, exciting relationship with you.

  • Page 9: At A Glance

    At a Glance UNIQUE FEATURES E251320 • Torque On Demand™ 2-speed transfer Powertrain case with 4 Hi-Loc. • 3.5L EcoBoost HO engine. • Modified rear differential capable of locking in 4A, 4H and 4L. • 10R80 10-speed automatic transmission. F-150 (TFC) Canada/United States of America, enUSA, Edition date: 201709, Second Printing...
  • Page 10 At a Glance Interior • 35 spline rear axle shafts for increased capability. • Unique terrain-mode and hill descent • 4.10 front and rear axle ratios. functionality plus six auxiliary switches. • Dual exhaust, 4.5 in (114.3 mm) exhaust • Off-road specific calibrations for tips.

  • Page 11: Information Displays

    Neutral Tow to your MyView. For complete menu structures, refer to your Owner's Manual. Your Ford Performance vehicle can be put in neutral tow through the information This icon gives you the ability to display. See Towing the Vehicle on Four switch a feature on or off.
  • Page 12 Information Displays Terrain Management System Message Action Selected 4x4 Mode Not Displays when the 4x4 system cannot be used in the current Available in Current terrain mode. Terrain Mode Locking Differential Not Displays when the locking differential cannot be used in the Available in Current current terrain mode.

  • Page 13: Transmission

    Transmission SelectShift will not automatically upshift, AUTOMATIC TRANSMISSION even if the engine is approaching the RPM limit. It must be shifted manually by WARNINGS pressing the + button or paddle. Always fully apply the parking brake. Note: Engine damage may occur if you Make sure you shift into park (P) for maintain excessive engine revving without vehicles with an automatic...
  • Page 14 Transmission Steering Wheel Upshift to the recommended shift speeds according to the following chart: E243113 Upshifts When Accelerating (Recommended for Best Fuel Economy) Shift from: 1 – 2 15 mph (24 km/h) 2 – 3 20 mph (32 km/h) 3 – 4 27 mph (43 km/h) 4 –...

  • Page 15: Four-Wheel Drive

    Four-Wheel Drive 4X4 HIGH USING FOUR-WHEEL DRIVE Continuously illuminates when Note: For important information regarding 4H is selected. the safe operation of this type of vehicle, E181779 see General Information in the Wheels and 4X4 LOW Tires chapter. Note: Do not use 4H or 4L mode on dry, Continuously illuminates when hard surfaced roads.
  • Page 16 Four-Wheel Drive Note: 4H may engage or disengage automatically based on terrain mode selection. See Principle of Operation (page 21). 4L (4X4 LOW) Provides mechanically locked four-wheel drive power to both the front and rear wheels with additional gearing for increased torque multiplication.
  • Page 17 Four-Wheel Drive Bring your vehicle to a speed of 3 mph Truck and utility vehicles can differ from (5 km/h) or less. some other vehicles. Your vehicle may be higher to allow it to travel over rough 2. Place the transmission in neutral (N). terrain without getting hung up or 3.
  • Page 18 Four-Wheel Drive The transfer case supplies power to all four It may be less risky to strike small objects, wheels. On four-wheel drive vehicles, the such as freeway reflectors, with minor transfer case allows you to select different damage to your vehicle rather than 4WD modes when necessary.
  • Page 19 Four-Wheel Drive Avoid driving at excessive speeds, this Driving on Hilly or Sloping Terrain causes vehicle momentum to work against Although natural obstacles may make it you and your vehicle could become stuck necessary to travel diagonally up or down to the point that assistance may be a hill or steep incline, you should always required from another vehicle.
  • Page 20 Four-Wheel Drive Descend a hill in the same gear you would Avoid sudden braking. Although a use to climb up the hill to avoid excessive four-wheel drive vehicle may accelerate brake application and brake overheating. better than a two-wheel drive vehicle in Do not descend in neutral.
  • Page 21 Four-Wheel Drive WARNINGS Always fully apply the parking brake. Make sure you shift into park (P) for vehicles with an automatic transmission. Switch the ignition off and remove the key whenever you leave your vehicle. On some four-wheel drive vehicles, when the transfer case is in the neutral (N) position, the engine and transmission disconnect from the rest of the driveline.

  • Page 22: Rear Axle

    Rear Axle on the fly within the operating speed range. ELECTRONIC LOCKING The electronic differential will DIFFERENTIAL automatically disengage when the vehicle speed exceeds a set value and it will Note: The electronic locking differential is automatically reengage when the vehicle for off-road use only and is not for use on speed goes below a set value (see table dry pavement.
  • Page 23 CHECK LOCKING Doing so will produce excessive noise, DIFFERENTIAL in the information vibration and increase tire wear. display. See your authorized Ford Note: If the electronic locking differential dealer for assistance. has difficulty disengaging, release the accelerator pedal and turn the steering wheel in the opposite direction while rolling.

  • Page 24: Terrain Control

    Terrain Control (If Equipped) PRINCIPLE OF OPERATION The Terrain Management System delivers a driving experience through a suite of sophisticated electronic vehicle systems. These systems optimize steering, handling and powertrain response. This provides a single location to control multiple systems performance settings.
  • Page 25 Terrain Control (If Equipped) Off-Road Modes Rock Crawl Mode - For optimum rock-climbing ability. Mud/Sand Mode - For E225315 Rock mode prompts you to put navigating tight trails and over your vehicle in 4x4 Low and automatically E225313 obstacles. Mud/Sand mode engages the electronic locking differential.
  • Page 26 Terrain Control (If Equipped) Terrain Mode Configurations On-Road Modes Off-Road Modes Normal Sport Weather Mud/Sand Baja Rock Crawl Engine/ Normal Sport Weather Mud/Sand Baja Rock Crawl Trans Controls Advan- Normal Normal Weather Mud/Sand Baja Rock Crawl ceTrac Controls Steering Normal Sport Normal Comfort...
  • Page 27 Terrain Control (If Equipped) Transfer Case Availability Drive selec- Normal Sport Weather Mud/Sand Baja mode Rock Crawl tion / mode mode mode mode mode Terrain mode Default Default Not Avail- Not Avail- Available Not Avail- mode mode able able able unless key cycle 4x4 Auto...

  • Page 28: Driving Aids

    Driving Aids COLLISION WARNING SYSTEM Principle Of Operation (If Equipped) WARNINGS This system is an extra driving aid. It does not replace your attention and judgment, or the need to apply the brakes. This system does NOT automatically brake your vehicle. If you fail E156131 to press the brake pedal when necessary, When your vehicle rapidly approaches...
  • Page 29 Driving Aids Note: It is recommended that you turn the Blocked Sensors collision warning system off if a snow plow or similar object is installed in such a way that it may block the radar sensor. Your vehicle will remember the selected setting across key cycles.
  • Page 30 Driving Aids System Limitations WARNING The collision warning system s brake support only reduces collision speed if you first apply your brakes. You must brake as you would in any typical braking situation. Due to the nature of radar technology, there may be certain instances where vehicles do not provide a collision warning.

  • Page 31: Towing

    Towing The standard integrated hitch has two RECOMMENDED TOWING ratings depending on mode of operation: WEIGHTS • Weight-carrying mode requires a draw bar and hitch ball. The draw bar WARNINGS supports all the vertical tongue load of Do not exceed the lowest rating the trailer.

  • Page 32: Towing The Vehicle On Four Wheels

    Towing Weight-distributing Hitch When the trailer is level or slightly nose down toward the vehicle: WARNING • Lock the bar tension adjuster in place. Do not adjust the spring bars so that • Check that the trailer tongue securely your vehicle's rear bumper is higher attaches and locks onto the hitch.
  • Page 33 This is normal. damage to your transmission. 9. Leave the transmission in neutral (N) Your Ford Performance vehicle can be put and turn the ignition as far as it will go in neutral tow (Recreational Towing Mode) toward the off position (it will not turn...
  • Page 34 Towing Note: Failing to put the transfer case in its If the transfer case does not neutral position will damage vehicle successfully shift out of neutral, set the components. parking brake until you can have your vehicle serviced. Note: You can check four-wheel-down towing status at any time by opening the Resolving the SHIFT DELAY PULL driver's door or turning the ignition to the...

  • Page 35: Driving Hints

    Ford joins which may indicate a change in the U.S. Forest Service and Bureau of Land available traction, and adjust the Management in encouraging you to help vehicle speed and route accordingly.
  • Page 36 Even if your local law down the slope. Place the vehicle in does not prohibit alcohol use while low range and slowly back down in driving off-road, Ford strongly reverse. recommends against drinking if you • When descending a steep slope, select plan to off-road.
  • Page 37 18 to 32 in (450 4 mph (7 km/h) mm to 810 mm) Ford Performance has engineered your vehicle for off-road use beyond what is Reverse – up to 30 Less than 6 mph normal for a F-150. However, it can incur...
  • Page 38 Driving Hints Some points to consider: • As speed increases, it is wise to look farther ahead of the vehicle so that • Build up speed slowly. Initially, drive at there is time to react to oncoming a pace which allows ample time to fully obstacles.
  • Page 39 Driving Hints After Off-Road Driving It is important to complete a full vehicle inspection after off-road driving. Some items to check include: • Make sure that tires are inflated to proper tire pressure as indicated on the tire placard. • Check the wheels and undercarriage for built up mud or debris which can cause vehicle vibration.

  • Page 40: Vehicle Care

    Vehicle Care CLEANING THE EXTERIOR Note: Do not use front bumper openings as a step. This could cause damage to your vehicle. Do not drive your vehicle through an automated, commercial car wash due to the vehicle s tire width and track. Wash your vehicle by hand, or by using a touchless commercial wash with no mechanical tracks on the floor.

  • Page 41: Wheels And Tires

    Note: If you have reduced your tire minimize risk of de-beading the tire. See pressure for off-road use, the tire your local Ford Performance Parts Dealer pressure monitoring system for more information. (TPMS) warning light then...
  • Page 42 Ford pressure and reducing speeds. Performance vehicle. These tires • In the event that you encounter...

  • Page 43: Ations

    Wheels and Tires E142548 Note: Your vehicle requires tire rotations every scheduled oil change. If you notice that the tires wear unevenly, have them checked. Note: Uneven tread depth between the front and rear tires may lead to degradation in 4WD engagement and disengagement performance, additional noise from the 4WD system or possible...

  • Page 44: Engine Specifications

    Capacities and Specifications ENGINE SPECIFICATIONS Measurement Specification Cubic inches Required fuel Minimum 87 octane Firing order 1-4-2-5-3-6 Ignition system Coil on plug Spark plug gap .030-.033 in. (0.75 - 0.85 mm) Compression ratio 10.0:1 Drivebelt Routing E167467 MOTORCRAFT PARTS Component Motorcraft Part number Air filter element.

  • Page 45: Capacities And Specifications

    Capacities and Specifications We recommend Motorcraft replacement of other parts. parts available at your Ford dealer or at If a Motorcraft oil filter is not available, use fordparts.com for scheduled maintenance. an oil filter that meets industry These parts meet or exceed Ford Motor...
  • Page 46 Capacities and Specifications Specifications Materials Name Specification Recommended motor oil (U.S.): WSS-M2C946-A Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor XO-5W30-QSP Recommended Motor oil (Canada): WSS-M2C946-A Motorcraft® SAE 5W-30 Super Premium Motor Oil CXO-5W30-LSP12 Recommended motor oil (Mexico): WSS-M2C946-A Motorcraft® SAE 5W-30 Synthetic Motor Oil MXO-5W30-QSP Optional motor oil (U.S.
  • Page 47 Capacities and Specifications Name Specification Motorcraft® MERCON ULV Automatic Transmission Fluid MERCON ULV XT-12-ULV Transfer case fluid (Torque On Demand™) (U.S. and WSS-M2C938-A Mexico): MERCON® LV Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVC Transfer case fluid (Torque On Demand™) (Canada): WSS-M2C938-A Motorcraft®...
  • Page 48 API certification mark. Note: Ford recommends using DOT 4 Low Viscosity (LV) High Performance Brake Fluid or equivalent meeting WSS-M6C65-A2. Use of any fluid other than the recommended...
  • Page 49 Capacities and Specifications Alternative Engine Oil for Note: Automatic transmissions that require Extremely Cold Climates MERCON® LV transmission fluid should only use MERCON® LV transmission fluid. To improve engine cold start performance, The use of any other fluid may cause we recommend that you use the following transmission damage.

  • Page 50: Accessories

    Accessories AUXILIARY SWITCHES The auxiliary switchboard on the overhead console makes aftermarket customization easier, with six prewired switches attached to the power distribution box for electrical accessories. E220728 E229061 These switches are labeled AUX 1, AUX There will also be one Aux Switch pass 2, AUX 3, AUX 4, AUX 5 and AUX 6.
  • Page 51 Accessories The relays are coded as follows: Switch Circuit number Wire color Fuse AUX 1 CBB47A Green/Blue AUX 2 CBB48A Gray/Yellow AUX 3 CBB94 Violet/Orange AUX 4 CBB96 Brown/Blue AUX 5 CBB98A Gray/Orange AUX 6 CBBA0B Yellow/Violet F-150 (TFC) Canada/United States of America, enUSA, Edition date: 201709, Second Printing...

  • Page 52: Warranty Terms And Conditions

    Maintenance information. Refer to the The F-150 Raptor carries the same New vehicle s Workshop Manual for removal Vehicle Limited Warranty as other Ford and installation procedures. Replace with F-150 models. This information is covered genuine Ford and Motorcraft service parts in its entirety in your warranty information.
  • Page 53 F-150 (TFC) Canada/United States of America, enUSA, Edition date: 201709, Second Printing...
  • Page 54 Index Ford Performance..........4 Four-Wheel Drive..........12 See: Four-Wheel Drive.........12 About This Supplement.........3 Gearbox Accessories............47 See: Transmission..........10 At a Glance............6 Automatic Transmission......10 Understanding your SelectShift™ Information Displays........8 Automatic Transmission.......10 Auxiliary Switches..........47 General Information..........8 Information Messages........8 Terrain Management System......9 Introduction............3 Base Warranty..........49 Message Center Capacities and Specifications....42...
  • Page 55 Index Technical Specifications See: Capacities and Specifications....41 Terrain Control..........21 Principle of Operation..........21 Tire Care............38 Spare Tire and Wheel........40 Tire Rotation............39 Tires See: Wheels and Tires........38 Towing the Vehicle on Four Wheels..29 Emergency Towing..........29 Recreational Towing...........30 Towing..............28 Transmission............10 Unique Features..........6 Chassis................7 Exterior................7 Interior.................7 Powertrain..............6...
