- Page 1 Installa on Instruc ons Angle Corner Please read these Instruc ons carefully May 2018...
- Page 2 Tools Required Components A –Return Wall Receiver x 2 Drill Caulking Gun B - Door Assembly Spirit level Masking tape C - Corner Return x 2 Tape Measure Pencil D - Cover Trim x 2 (on Selected Models) Screw Driver (No.1 Sq drive) Cleaning Cloth ...
- Page 3 Installa on Note: Your shower Door can be installed to open from the le or right hand side by rota ng the door 180 degrees, and the Return Panels can be fi ed on either side. You must decide which way the door is to open before star ng the installa on.
- Page 4 Wall Receivers 3) Pre drill three equally spaced clearance holes 4) Secure the Wall Receivers to the (i.e. top, bo om and centre) in the Door & walls using the No.6 x 38mm Return Wall Receivers using a 4.5mm drill stainless steel screws bit.
- Page 5 Fit the Return Sill to the lower edge of the 8) Place 25-50mm Wood packers on the tray (not supplied) Return Panel. Carefully wipe away any excess silicone that may ooze out Slide the return Panel down onto the Posi on the Return Panel into the Return Wall packers Receiver.
- Page 6 Li the Door up and fit it into the Return Panels taking care to hold it above the front lip of the tray (You will note that as you slide the door onto the Returns , the Return Panels will self align to the inside of the upstand on the tray) Once the Door and Returns are fully engaged let the Door slide gently down inside the upstand of the tray.
- Page 7 Secure the Door Set (All Screw fixings are made from the Inside) Using a 3.0mm drill bit, drill through the Wall Receiver sec ons and into the Return frames. (Use the “V” groove line as a guide). Secure the Door set together using the No.6x10 Screws. Cover the screw heads with the Cover caps Repeat for the Corner posts into the Door frame Adjust the Door...
- Page 8 Drip Seals Notch under Door Magnet profile The Drip seal is supplied in a 1m length, this will need to be 23) Fit the Drip Seals to the glass door cut to the desired lengths for each side of the pivot . The opening side Drip seal will also need to be notched to fit under the door magnet profile.
