- Page 1 Installa on Instruc ons Alcove Please read these Instruc ons carefully May 2018...
- Page 2 Tools Required Components A - Door Assembly Drill Caulking Gun B - Door Wall Receiver Spirit level Masking tape C- Cover Trim x 2 (On Selected Models) Tape Measure Pencil Screw Driver (No.1 Sq drive) Cleaning Cloth ...
- Page 3 Installa on Note: Your shower Door can be installed to open from the le or right hand side by rota ng the door 180 degrees, and the Return Panel can be fi ed on either side. You must decide which way the door is to open be- fore star ng the installa on.
- Page 4 Door Side the remaining Door Wall Receiver onto the Door Assembly. Ensure the Door is facing the correct way with the door opening outwards. Do not remove the door se ng block, this will assist in suppor ng the door during installa on and se ng the correct clear- ance from the sill.
- Page 5 Plumb the Door and remaining Wall Receiver. Through the oversize holes in the Door jamb drill through the Wall Receiver frame and into the wall stud using a 3.0 mm drill bit the oversize holes in the door Jamb using the Secure the Wall Receiver to the wall using 10) Cap 9mm plas c plugs...
- Page 6 in place using the 6 gauge x 10mm 14) Secure Cover all Screw heads with the Screw Caps screws. Adjust the Door Slide the outside Clamp Block Covers off the Pivot Clamp. Using a flat blade screwdriver sufficiently loos- en the two screws, adjust the door by sliding le or right in the pivot Once the door adjustment is complete ensure the screws are re ghtened and reinstall the Clamp Block Covers.
- Page 7 Sealing the Shower The Door can now be sealed in place using For White Showers only - take the Cleaning silicone sealant. Ensure all surfaces are first Towele e and wipe the surfaces of the cleaned with dry clean cloth. Seal between Powder coated profiles where Silicone will the tray upstand and the door set along the be applied Allow to dry (1-2 minutes)
