Pilatus PC-6 Turbo Porter
Building Manual
09-2011
03-2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pilatus PC-6 Turbo Porter and is the answer not in the manual?

Questions and answers

Related Manuals for MR Aerodesign Pilatus PC-6 Turbo Porter

Summary of Contents for MR Aerodesign Pilatus PC-6 Turbo Porter

  • Page 1 Pilatus PC-6 Turbo Porter Building Manual 09-2011 03-2018...
  • Page 5 Pilatus PC-6 Turbo Porter Wood listing Part number Description Length DA-SH-1 Balsa 1/16" x 3" 7 9/16 DA-SH-1 Balsa 1/16" x 3" 7 9/16 DB-SH-1 Balsa 1/16" x 3" 4x36" DB-SH-1 Balsa 1/16" x 3" E-SH-1 Balsa 1/16" x 3"...
  • Page 6 FU-ST-06 Balsa 1/4" x 1/4" 6 7/16 FU-ST-07 Balsa 1/4" x 1/4" 29 1/16 FU-ST-08 Balsa 1/4" x 1/4" 17x36" FU-ST-09 Balsa 1/4" x 1/4" 29 1/8 14x48" FU-ST-10 Balsa 1/4" x 1/4" 29 3/16 FU-ST-11 Balsa 1/4" x 1/4" 17 15/16 FU-ST-12 Balsa 1/4"...
  • Page 7 Pilatus PC‐6 Turbo Porter Laser cutted parts listing Part number Part number Description Description Balsa 3/32" Ply 1/8" FUA3 Balsa 3/32" Ply 1/8" FUA4 Balsa 3/32" Ply 1/8" FUA5 Balsa 3/32" Ply 1/8" FUA6 Balsa 3/32" FU10L Ply 1/8" SSW1 Balsa 3/32" FU10R Ply 1/8" Balsa 3/32" FU11L Ply 1/8" Balsa 3/32" FU11R Ply 1/8" Balsa 3/32" FU12 Ply 1/8" Balsa 3/32" FU13 Ply 1/8" Balsa 3/32" FU14 Ply 1/8" Balsa 3/32"...
  • Page 8 Pilatus PC-6 Turbo Porter Horizontal Stab. & Elevator Parts listing Parts listing Part Number Description Part Number Description S-LE-1 Balsa 3/32" x 3" DUB-716 Control Horn S-LE-2 Balsa 1/4" x 1" E-LE-1 Balsa 1/8" x 1/8" S-MS-1 Balsa 1/4" x 1/4"...
  • Page 9 Pilatus PC-6 Turbo Porter Horizontal Stab. & Elevator 3/16 po [ 4.8 mm] Step 2 S-TE-1 Balsa 1/4" x 1" Balsa 1/8" Balsa 1/4" Balsa 1/8" S-TE-1 Balsa 1/4" x 1" S-MS-1 Balsa 1/4" x 1/4" S-LE-1 Balsa 3/32" x 3"...
  • Page 10 Pilatus PC-6 Turbo Porter Horizontal Stab. & Elevator Step 4 S-SH-1 Balsa 3/32" x 4" S-SH-1 Balsa 3/32" x 4" S-SH-1 Balsa 3/32" x 4" S-SH-1 S-LE-2 Balsa 3/32" x 4" Balsa 1/4" x 1" Step 5 S-LE-2 Balsa 1/4" x 1"...

  • Page 11: Table Of Contents

    Pilatus PC-6 Turbo Porter Horizontal Stab. & Elevator Step 1 E-SH-2 Balsa 1/16" x 3" E-LE-1 Balsa 1/8" x 1/8" E-TE-1 Balsa 1/4" Balsa 1/4" x 1/2" Laserboard 1/64" Balsa 1/8" Step 2 Balsa 1/4" Balsa 1/8" Balsa 1/8" Ply 1/8"...
  • Page 12 Pilatus PC-6 Turbo Porter Horizontal Stab. & Elevator Step 4 E-SH-1 E-SH-1 Balsa 1/16" x 3" Balsa 1/16" x 3" E-LE-2 Balsa 1/4" x 3/4" DUB-716 Control Horn Step 5 Pilatus PC-6 Turbo Porter Martin Rousseau MR Aerodesign 03-2018...
  • Page 13 Pilatus PC-6 Turbo Porter Vert. Stab. & Rudder List of material Part number Material DUB557 3/32" E/Z Adjust horn bracket R-BT-1 Brass tube 7/32" x 1/4" R-BT-2 Steel rod 3/32" R-BT-3 Brass tube 1/4" x 9/32" Ply 1/8" Balsa 1/8"...

  • Page 14: Balsa

    Pilatus PC-6 Turbo Porter Vert. Stab. & Rudder Step 1 Ply 1/16" Balsa 1/8" Ply 1/8" Balsa 1/8" 2 9/32 in [58 mm] 1/4" x 1/4" wood Balsa 1/8" Balsa 1/8" Ply 1/8" Balsa 1/8" V-MS-1 Balsa 1/8" x 1/4"...

  • Page 15: Balsa

    Pilatus PC-6 Turbo Porter Vert. Stab. & Rudder R1-A Ply 1/8" Ply 1/8" Step 1 R1-B Balsa 1/8" Ply 1/8" Ply 1/8" Balsa 1/8" R-MS-1 Balsa 1/8" x 1/4" Balsa 1/8" R-SH-1 Balsa 1/16" x 4" R-TE-1 Balsa 1/4" x 1/2"...

  • Page 16: Step

    Pilatus PC-6 Turbo Porter Vert. Stab. & Rudder SH-N4-016 Socket Head Screw 4-40 x 1" Step 4 DUB557 Weld with tin 3/32" E/Z Adjust horn bracket or glue with CA Ply 1/8" Balsa 1/8" R-BT-2 Steel rod 3/32" Ply 1/8"...

  • Page 17: S-Le

    Pilatus PC-6 Turbo Porter Aileron & Flap Aileron listing Parts listing (For 1 aileron) Part number Description Balsa 3/32" Ply 1/8" Ply 1/64" Ply 1/64" Ply 1/8" A-LE-1 Balsa 1/4" x 1" A-LE-2 Balsa 1/4" x 1" A-MS-1 Balsa 1/8" x 1/4"...

  • Page 18: S-Le

    Pilatus PC-6 Turbo Porter Aileron Step 1 27 1/16 in [687 mm] 3 7/8 in Use the plan for the location [99 mm] of the notch. A-SH-2 Balsa 1/16" x 4" chelle 1 / 4 Step 2 ( 1 Left req.) (1 Right req.)

  • Page 19: Step

    Pilatus PC-6 Turbo Porter Aileron Step 4 DUB861 Swivel Ball link 4-40 SH-N4-012 NN-4-SS Socket Head Screw 4-40 x 3/4" #4-40 Nylock Nut (SS) Step 5 A-SH-1 Balsa 1/16" x 4" Step 6 A-LE-2 Balsa 1/4" x 1" A-LE-1 Balsa 1/4" x 1"...

  • Page 20: Balsa 1/16" X

    Pilatus PC-6 Turbo Porter Flap Step 1 27 1/4 in [692 mm] 3 7/8 in Use the plan for the location [99 mm] of the notch. FL-SH-2 Balsa 1/16" x 4" chelle 1 : 4 Step 2 (1 Left req.) (1 Left req.)

  • Page 21: Step

    Pilatus PC-6 Turbo Porter Flap Step 4 DUB861 Swivel Ball link 4-40 NN-4-SS SH-N4-012 #4-40 Nylock Nut (SS) Socket Head Screw 4-40 x 3/4" Step 5 FL-SH-1 Balsa 1/16" x 4" FL-LE-2 Step 6 Balsa 1/4" x 1" FL-LE-1 Balsa 1/4" x 1"...

  • Page 22: Balsa 1/8" X

    Pilatus PC-6 Turbo Porter Wing Part list (For 1 wing) Part number Description Length Balsa 3/32" Ply 1/8" Ply 1/64" Ply 1/64" Ply 1/8" A-LE-1 Balsa 1/4" x 1" 14 1/32 in A-LE-2 Balsa 1/4" x 1" 12 3/4 in A-MS-1 Balsa 1/8"...
  • Page 23 Pilatus PC-6 Turbo Porter Wing Ply 1/64" Step 1 Balsa 3/32" Balsa 3/32" DUB861 Swivel Ball link 4-40 1 req. (Left Wing) 1 req. (Right Wing) Balsa 1/4" W-DW-1 Ply 1/64" Wood dowel 1/4" Ply 1/64" Step 2 Balsa 3/32"...

  • Page 24: Balsa 1/4" X

    Pilatus PC-6 Turbo Porter Wing Step 4 Balsa 3/32" Balsa 3/32" 1/4 in Ply 1/64" 6 9/32 in 3/4 in [159.9 mm] 2 1/4 in [57.1 mm] Balsa 1/8" W-TU-1 Phenolic tube 1" x 1 1/8" (cut to 13") Ply 1/8"...

  • Page 25: Balsa 1/16" X

    Pilatus PC-6 Turbo Porter Wing W-SH-7 Balsa 1/16" x 3" x 48" Step 6 Ply 1/4" W-TR-1 DETAIL A Balsa triangle 1/4" SCALE 1 /3 Step 7 Trim to fit WSW3 Balsa 3/32" WSW4 Balsa 3/32" WSW3 Balsa 3/32" WSW2 Ply 1/8"...
  • Page 26 Pilatus PC-6 Turbo Porter Wing Step 8 Balsa 1/8" DUB861 Balsa 3/32" Balsa 1/8" Swivel Ball link 4-40 WB-BL-1 Balsa 1/4" x 1/2" Ply 1/64" See detail A Balsa 1/8" Balsa 1/8" WB-BL-1 Balsa 1/4" x 1/2" Balsa 1/8" DETAIL A...
  • Page 27 Pilatus PC-6 Turbo Porter Wing Step 10 W-SH-1 W-SH-2 Balsa 3/32" x 4" x 48" Balsa 3/32" x 4" x 48" W-SH-3 Balsa 3/32" x 4" x 48" W-LE-2 Balsa 1/4" x 1" Flap SH-N4-016 Socket Head Screw 4-40 x 1"...
  • Page 28 Pilatus PC-6 Turbo Porter Fuselage Fuselage Part list Fuselage Part list Part number Material Length Part number Material Length Blind nut 6-32 FU5B Ply 1/8" DUB202 Steel strap FU5C Balsa 1/8" F-WS-1 Aluminium 1/16" FU5D Balsa 1/8" FU-BB-01 Balsa 1/4" x 1 1/2"...
  • Page 29 Pilatus PC-6 Turbo Porter Fuselage FU5B 4 req. Ply 1/8" Ply 1/8" 2 req. Preparation of parts Ply 1/8" FU5B Ply 1/8" Ply 1/8" 1 req. Ply 1/8" Ply 1/8" 4 req. FUD5 FUD3 Ply 1/8" Ply 1/8" Ply 1/8"...
  • Page 30 Pilatus PC-6 Turbo Porter Fuselage Step 1 FUE2 FUE3 Ply 1/8" Ply 1/8" Ply 1/8" FUD5 FUD8 Ply 1/8" Ply 1/8" FUD4 Ply 1/8" FUD1 FUD3 FU13 Ply 1/8" Ply 1/8" Ply 1/8" FU10L FU15 Ply 1/8" Ply 1/8" Step 2 FU14 Ply 1/8"...
  • Page 31 Pilatus PC-6 Turbo Porter Fuselage FU-ST-12 Balsa 1/4" x 1/4" FU-ST-13 Balsa 1/4" x 1/4" FU-ST-14 Balsa 1/4" x 1/4" Step 4 FU-ST-09 Balsa 1/4" x 1/4" FU-ST-07 FU-ST-10 Balsa 1/4" x 1/4" Balsa 1/4" x 1/4" FU-ST-11 Balsa 1/4" x 1/4"...
  • Page 32 Pilatus PC-6 Turbo Porter Fuselage FU3A Ply 1/8" Ply 1/8" SH-N4-020 Socket Head Screw 4-40 x 1 1/4" Step 7 NN-4-SS FUVC #4-40 Nylock Nut (SS) Ply 1/4" DUB202 Steel strap FU7A Ply 1/8" Ply 1/8" FU7B Ply 1/8" Ply 1/8"...
  • Page 33 Pilatus PC-6 Turbo Porter FU-TPH Fuselage Phenolique tube 1" x 1 1/8" FU-ST-08 Balsa 1/4" x 1/4" FU-HW-1 Hardwood 1/4" x 1/4" FU-ST-01 Balsa 1/4" x 1/4" FU-ST-02 Balsa 1/4" x 1/4" FU-ST-03 Balsa 1/4" x 1/4" Step 10 FU-ST-14 Balsa 1/4"...
  • Page 34 Pilatus PC-6 Turbo Porter Fuselage Step 12 Servo Servo SS2-07 Servo Screw #2x7/16" Step 13 FUVB Plywood 1/4" FUVA Plywood 1/4" Step 15 FU-SH-06 Balsa 3/32" x 4" Step 14 FU-SH-04 Balsa 3/32" x 4" FU-SH-02 Balsa 3/32" x 4"...
  • Page 35 Pilatus PC-6 Turbo Porter Fuselage Step 16 4 23/32 in [120.1 mm] SS2-07 1/8 in [3.2 mm] Servo Screw #2x7/16" F-WS-1 Aluminium 1/16" F-WS-1 Aluminium 1/16" DETAIL A FU-BB-03 Balsa 1/4" x 1 1/2" FU-BB-02 Balsa 1/4" x 1 1/2"...
  • Page 36 Pilatus PC-6 Turbo Porter Fuselage Step 18 ***Glue the vertical and horizontal stabilisator. ***Install the tail wheel. ***Make the dorsal fin. Pilatus PC-6 Turbo Porter Martin Rousseau MR Aerodesign 09-2011...
  • Page 37 Pilatus PC-6 Turbo Porter Fuselage Step 19 -Install the landing gear Pilatus PC-6 Turbo Porter Martin Rousseau MR Aerodesign 09-2011...
  • Page 38 Pilatus PC-6 Turbo Porter Fuselage DUB336 4-40 Threaded coupler 2 7/32 in [56.6 mm] TYP. DUB145 DUB302 DUB302 WS-5 4-40 Steel rod 4-40 Rod end 4-40 Rod end Ply 1/8" KAS1105 3/4 Streamline aluminium 27 7/16 in [696.7 mm] 23 31/32 in [608.6 mm]...
