Cedar Barrel Sauna Assembly Instructions
Please read and understand the complete instructions prior to assembly and use of your sauna. Customer agrees not to hold
Dundalk LeisureCraft Inc. and any of its authorized dealers liable for improper installation, maintenance and repair of this product.
2 People (recommended)
•
Rubber Mallet
•
Carpenter's Hammer
•
6' Step Ladder
•
Cordless Drill (we supply the bit)
•
Carpenter's Level
•
¾" Wrench
•
Tape Measure
•
View the assembly process on
(see last page)
Advertisement
Related Manuals for SaunaFit Cedar Barrel
Summary of Contents for SaunaFit Cedar Barrel
- Page 1 Cedar Barrel Sauna Assembly Instructions Please read and understand the complete instructions prior to assembly and use of your sauna. Customer agrees not to hold Dundalk LeisureCraft Inc. and any of its authorized dealers liable for improper installation, maintenance and repair of this product.
- Page 2 Preparing the base. A full gravel pad as shown here, or individual gravel pads for each cradle (see picture, front page): Clear loose vegetation and soil, level the ground with a slight slope for drainage, and fill the area with 2-4”...
- Page 3 Fill the cradles with enough staves to hold the middle section with the door, and the corresponding back middle section. Make sure there are no gaps between the edges of the staves. (tap together with mallet) A half-inch hole was bored for drainage just inside the walls on the lower special stave.
- Page 4 Get the middle front and back wall segments plum using a carpenter’s level, or a plumb bob. Put the special top stave in place to help stabilize the wall sections.
- Page 5 Fasten the half-moon side wall segments to the middle wall segments with supplied 2½” screws. The tops of the various wall sections are marked with A, B, C, or D at the top to ensure that they are properly matched. Here they attach the front-left section to the front-middle section matching markings “B”...
- Page 6 Here the installer is using one of the supplied 2½” finishing nails to hold a stave onto the bottom part of the barrel. You may not need to use nails, as sometimes the staves stay on without nails. If you do find that you need to use them, only use nails on every second stave, and only if necessary.
- Page 7 Finish installing the staves on the top half. Again, make sure there are no gaps between the staves by tapping them firmly into place with a rubber mallet, and make sure they line up with the pencil-marked circle. Assemble two of the bands so they can be slipped easily on over the ends of the barrel.
- Page 8 Here the band is being placed with the tightening hardware on the bottom of the side that is least visible. IMPORTANT: It is normal for the barrel sauna to fit like this when the outer bands are on, (with a “hump” where the last stave is inserted.) Using your rubber mallet, adjust the staves so that they form nice circle,...
- Page 9 By adjusting the staves this way (bumping them up or down with a rubber mallet, as necessary) they should settle into a circular shape as pictured below. Your barrel should look somewhat like this just before tightening; as near a circle shape as can be achieved by adjusting the staves with a mallet, but with a gap showing at the top.
- Page 10 Measure 2” from the edge of the band to the end of the staves all around before tightening Rotate the bands so that the tightening hardware is at the desired location. Usually this is the least visible area of the barrel. That could be bottom centre if you don’t mind crawling down under to tighten them.
- Page 11 Assemble the outside benches for saunas with the porch option using supplied 1½” screws into and predrilled holes. Attach the legs… Then the braces (two 1½” inch screws)… Start the long screws (2½”) into the end brackets to make installation easier…...
- Page 12 … and install with 2½” screws. A carpenter’s level or square can be useful. Fasten handles at the desired height (1½” screws) … then the towel bar (1½” screws).
- Page 13 IMPORTANT: Operate the heater for an hour with the sauna door fully open to burn off any residual coating from the manufacturing process before using. Congratulations, you have successfully assembled your Cedar Barrel Sauna!
-
Page 14: Warranty
WARRANTY Our Products are warranted to be free of defects in materials and workmanship under normal use and service, for a period of three years (3 years) from date of purchase. With the warranty you will get a NO HASSLE next business day (depending on shipping service) replacement for all requested parts.
