Cedar POD Sauna Assembly Instructions
Required:
•
•
•
•
•
•
•
Please read and understand the complete instructions prior to assembly and use of your sauna. Customer agrees
not to hold Dundalk LeisureCraft Inc. and any of its authorized dealers liable for improper installation, maintenance
2 People (recommended)
Rubber Mallet
Carpenter's Hammer
6' Step Ladder
Cordless Drill (we supply the bit)
Carpenter's Level
Tape Measure
and repair of this product.
Advertisement
Related Manuals for SaunaFit Cedar POD
Summary of Contents for SaunaFit Cedar POD
- Page 1 Cedar POD Sauna Assembly Instructions Required: • 2 People (recommended) • Rubber Mallet • Carpenter’s Hammer • 6’ Step Ladder • Cordless Drill (we supply the bit) • Carpenter’s Level • Tape Measure Please read and understand the complete instructions prior to assembly and use of your sauna. Customer agrees not to hold Dundalk LeisureCraft Inc.
- Page 2 Preparing the base. Crushed limestone gravel: Clear loose vegetation and soil, level the ground, lay down weed barrier cloth if desired, and fill the area with 2-4” of crushed limestone gravel. Level and tamp. Patio stones on top are an option but not necessary.
- Page 3 Locate and position the back bottom wall assembly (picture left) flush with the back edge of the floor. Centre it side to side on the back edge of the floor and fasten it with 2½” deck screws approximately every 16”. Now locate the bottom board assembly of the front wall.
- Page 4 Use a wall board as a brace to steady the wall segments, as shown, to hold the wall segments in place until the roof is in place. Install the pre-hung door assembly by sliding it firmly into place. Place and attach the other front wall section. Install the middle section of the back wall.
- Page 5 Brace the middle back wall section with another stave on each side. Centre the top section of the back wall and fasten at the bottom corners with 2½” deck screws. Repeat for the top section of the front wall. When the front and back walls are secured, fasten the two halves of the roof top board using 2½”...
- Page 6 Centre the top piece on top of the walls and fasten it using two 1½” deck screws on each end. Install the wall boards from the top down, tapping them into place with a rubber mallet. Secure the wall boards in place using 2½” deck screws where they join the front and rear walls.
- Page 7 Continue installing the wall boards until you reach the bottom of each side. Note that the bottom boards have a flat bottom. Install it as you would the rest. Install the front and back trim boards as shown using supplied 1½” deck screws. Place the screws approximately every third wall board.
- Page 8 Peel the protective plastic off the top side black adhesive strip, then apply the next piece on top. When you have applied three strips on each side, place the final strip across the peak as shown. Trim the ends precisely at the joint of roof board and trim with a utility blade.
- Page 9 Benches: Space two bench supports next to the side wall where the bench will go. Place the bench on top, and adjust the positon of the supports so that they are directly under the underside cross members, flush with the front trim, and in contact with the wall.
- Page 10 Heater: (see manufacturer’s instructions) Sauna Craft: Place one of the head rests on the floor to hold the heater in place while you mark the positions of the wall bracket, as shown. Use the screws supplied with the heater to fasten the wall brackets, and hang the heater on them.
- Page 11 And last but not least, install the door handle outside, as shown … … and towel bar cross-ways on the inside of the door. The robe/towel peg board can go on either side of the door over a window. Congratulations, you have successfully assembled your Cedar Pod Sauna!
-
Page 12: How To Take A Sauna
HOW TO TAKE A SAUNA Pre-heat your sauna to the desired temperature (usually between 80-100°C) While it’s warming up, take a nice hot shower. Enter the pre-heated sauna, relax and allow your body to perspire in the soft dry heat. Do not throw water on the rocks during the first part of the session.
