Summary of Contents for bioBidet BB-1700
- Page 1 Lifestyle Upgrade Thank you for purchasing Bio Bidet Advanced Toilet Seats. Intended for household use only. 171102_BB-1700,2000 USER's MANUAL.indd 2 2017-11-03 오전 11:27:58...
-
Page 2: Table Of Contents
Contents IMPORTANT SAFEGUARDS / GENERAL CAUTIONS CAUTIONS BEFORE INSTALLATION CARTON CONTENTS / IDENTIFICATION OPERATION (BASIC) OPERATION (DETAILS) INSTALLATION SEPARATION OF THE UNIT FROM THE TOILET BOWL MAINTENANCE WATER DRAINING TROUBLE SHOOTING SPECIFICATIONS WARRANTY INFORMATION TO THE USER Installation Manual and Operating Instructions 171102_BB-1700,2000 USER's MANUAL.indd 3 2017-11-03 오전... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE The following terms are used in this manual to indicate hazards of varying degrees of severity. Indicates an imminently hazardous situation which, if not avoided, DANGER will result in death or serious injury. Indicates potentially hazardous situation which, if not avoided, WARNING could result in death or serious injury. - Page 4 Do not plug in the power cord before connecting the water supply hose. Prohibited This product must be grounded. An approved Ground Fault Circuit Interrupt must be used. Grounding Do not splash water on this product. Please provide adequate ventilation to avoid high levels of humidity which can damage the electronic components.
-
Page 5: Cautions Before Installation
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS CAUTION Never operate this product if it is not Do not obstruct or put anything into the dry air working properly, if it has been dropped or damaged, or dropped into outlet. Do not apply water. - Page 6 This Product must be on a separate circuit. No other appliance should share the circuit with this product. WARNING Sharing a circuit could cause the branch circuit fuse to blow or the circuit breaker to trip. Continuous usage under these conditions could result in fire or property damage.
-
Page 7: Carton Contents / Identification
MAIN UNIT BB-1700 Turbo Wash Nozzle Posterior Wash Nozzle Caution Label Feminine Wash Nozzle Operation LED Window Deodorizer Control Panel for BB-1700 Dryer Vent Drain / Quick Release Drain button Digital Occupied Sensor Heated Seat ACCESSORIES For plumbing For product fixation... - Page 8 BB-1700 Control Panel Stop all operation. Posterior wash. Feminine wash. Turbo wash. Dry washed area. Adjust the water pressure and Adjust the oscillation function and warm air dryer temperature. nozzle position (5 levels). Adjust the water temperature (4 levels). Adjust the seat temperature (4 levels).
- Page 9 Identification MAIN UNIT BB-2000 Turbo Wash Nozzle Posterior Wash Nozzle Caution Label Feminine Wash Nozzle Operation LED Window Deodorizer Simple Operation Panel For BB-2000 Dryer Vent Drain button Drain / Quick Release Digital Occupied Sensor Heated Seat ACCESSORIES For plumbing For product fixation For remote control Installation...
- Page 10 Stop all operation. BB-2000 Remote Control Posterior wash. Feminine wash. Dry washed area. VORTEX wash. When selected during wash function nozzle oscillates automatically for a wider wash. If move button is selected when user is not sitting on the seat, it operates nozzle shower function. When selected during wash function, it start massage wash.
-
Page 11: Operation (Basic)
Operation (Basic) CAUTION Please press the "off"or "low"button to reduce the seat temperature after using. Special precautions should be taken for children, those who cannot adjust the temperature, and those who have sensitive skin. CAUTION Check for any water leaks. ᆞPlease turn on the water supply valve and check connected spots(1~5) for the leakage. - Page 12 ᆞWhen the digital sensor on the seat is activated, the operation LED window on the main unit will light "Occupied sensor"and simultaneously, the deodorizer fan will start to work. (BB-1700 / BB-2000 Models) ᆞSee page 14 for details about changing the seat or water temperature.
-
Page 13: Operation (Details)
※This product memorizes the air temperature of prior use. WATER PRESSURE ADJUSTMENT ᆞAfter sitting down on the this product, the LED lamp( ) for water BB-1700 BB-2000 pressure on the Power Control will light at third or middle level( ᆞPress high(... - Page 14 DEODORIZER Deodorizer ON/Off (initial setting is Off) - Press button for( ) 3 seconds (press the button again for 3 seconds, the function is canceled.) - After setting Deodorizer function, it is automatically activated when sensing the human body. "Deodorizer"button "Deodorizer"button - Select: Single Chime Press 3 seconds...
- Page 15 Operation (Details) MASSAGE (Rhythm Wash) ᆞ When using the Posterior Wash or Feminine Wash functions, pressing the "MASSAGE"( button will provide a pulsation spray. ᆞYou may change the pressure of the spray by pressing the "High"( ) button or "Low"( ) buttons.
- Page 16 POWER SAVER - When using bidet in saver mode, it is turned to automatic saver. BB-1700 - When you rise from the seat, it goes into saver mode. - Seat temperature is maintained 32℃. In energy saver mode, the seat heating...
-
Page 17: Installation
Installation CAUTION BEFORE INSTALLATION ᆞDo not plug in before installation. ᆞI f you need an electric power system or extension, please consult a qualified electrician. ᆞPlease contact our service center(847-458-2334) when you want to reinstall the bidet product(move or replacement). STEPS Turn Off Water. - Page 18 Installation Catch Plate. Bolt and Nut Assembly. Place the plate and guides over each mounting hole. Slide cone packing and washers onto the bolts Insert the mounting bolts through the plate and then fasten to securely mount bidet seat to toilet. mounting holes.
- Page 19 Installation Wireless remote mounting guide. (BB-2000) Install wireless remote with adhesive tape ᆞRemove adhesive from back of bracket and place bracket where desired. Adhesive Wall tape Inserting batteries ᆞInsert supplied batteries (1.5V AAA) and close battery cover. (Please check the polarity, before insert the batteries.) Nozzle Change Nozzle Seperation...
- Page 20 Separation Of Unit From The Toilet Bowl Disconnect the power plug. Close water supply shut-off valve. Drain water from bidet seat using drainage as illustrated. Remove bidet seat from toilet as illustrated. Do not turn unit upside down. Installation Manual and Operating Instructions 171102_BB-1700,2000 USER's MANUAL.indd 21 2017-11-03 오전...
-
Page 21: Maintenance
If a filter is used, it must be replaced every 3 months. ᆞThis product is designed and intended for use exclusively with BioBidet Carbon & Iodine water filters. The purchase or use of any other water filter is not the responsibility of BBC Innovation. -
Page 22: Water Draining
Water Draining DRAINING THE WARM WATER TANK IN THE UNIT If you do not intend to use this product for 14 days or longer, drain the water from this product' warm water tank. 1) Disconnect the power plug. 2) Close the water shut off valve. 3) Press the drain lever until the water is completely drained from water tank. -
Page 23: Trouble Shooting
10 Trouble Shooting Trouble Cause Remedy 1. The water tank is not filled. 1. Wait about one minute. 2. The shut off valve is closed. 2. Press the desired washing button once again. 3. Freezing inside the main unit or the 3. -
Page 24: Specifications
11 Specifications Specification BB-1700 BB-2000 Power Rating America or Canada: 120Vac, 60Hz, 1400W Type Direct Inlet flow type Water inlet type Water inlet pressure 0.04 ~ 0.74MPa(0.4 ~ 7.5 kgf/㎠) Power cord 1.2m (4 feet): AMERICA Posterior Wash Max. 0.7ℓ/min ( Max. 0.185 GPM ) Feminine Wash Max. -
Page 25: Warranty
12 Warranty Three (3) Year Full Coverage Warranty BBC Innovation warranty its product to be free from manufacturing defects under normal use and service for a period of three (3) years from original date of purchase. This warranty is extended only to the ORIGINAL PURCHASER. BBC Innovation’s obligations under this warranty are limited to repair or replacement, at BBC Innovation's option, of products or parts found to be defective, provided that such products were properly installed and used in accordance with instructions. -
Page 26: Information To The User
Such modifications could void the user's authority to operate the equipment. For Service & Technical Support, call or write to: BBC Innovation Corporation 7900 South Illinois Rte 31 Crystal Lake, IL 60014 U.S.A Tel: 847.458.2334 Fax: 847.854.1296 Support@biobidet.com Installation Manual and Operating Instructions 171102_BB-1700,2000 USER's MANUAL.indd 27 2017-11-03 오전 11:28:14...
