  • Page 1 DIGIWAY PTY LTD INSTRUCTION MANUAL P750 Sliding Gate Motor P550 Sliding Gate Motor Version -V2.X...
  • Page 2: Important Safety Warning

    DIGIWAY PTY LTD IMPORTANT SAFETY WARNING ATTENTION To prevent electrical shock, disconnect from power source before installing or service ATTENTION Electricity and power motors associated accessories could be fatal or at least cause seriously injury. All main voltage wiring must be installed by a licensed electrician.
  • Page 3: General Layout

    DIGIWAY PTY LTD GENERAL LAYOUT Fig -1 1) Manual Release bolts 2) Gear box 3) Motor 4) Circuit breaker 5) Terminals 6) Inverter 7) Perspex 8) EMC filter 8) Main control board 10) Transformer 11 Loop detector (option) 12 Din rail...
  • Page 4: Technical Specifications

    CONTROL INPUIT AND BUTTON 1. General Descriptions The P550 and P750 sliding gate motors was designed for heavy duty industry track gate or cantilever gate. Heavy duty three phase industry motor driven by VSD (variable speed drive), gate can run at different speeds.
  • Page 5 DIGIWAY PTY LTD CONTROL INPUIT AND BUTTON Open (OPN) input & OPN push button The OPN inputs are Push Button OPN and Terminal OPN input. Push OPN button or Activating (connect OPN terminal to the COM (+12V)) the OPN input will start the gate to open. When gate opened, if OPN is still activating, the gate will stay open.
  • Page 6 DIGIWAY PTY LTD CONTROL BOARD SETTING until gate is fully opened. If the PE is clear, the gate will open another 2 seconds, then gate will close again after PE close delay time. DIP5 OFF no this function. DIP5 is prior to DIP6.
  • Page 7 DIGIWAY PTY LTD CONTROL BOARD SETTING Sync delay time (Motor2 delay time, reserved late use) After controller get into special time setting mode, Push and hold on OPN for the sync delay time setting. Now the red and green LED flash fast alternatively, when reached required time, simply release OPN button.
  • Page 8: Wiring Diagram

    DIGIWAY PTY LTD WIRING DIAGRAM 7. Wiring diagram Fig-3...
  • Page 9: Manual Release

    DIGIWAY PTY LTD MANUAL RELEASE 8. Manual release P550 and P750 have different manual release mechanisms please read the instructions carefully. 8.1 P550 manual release A: What to do during a power failure: The gate can be manually pushed open and close if there is no power. To do this, you need to release the release bolt.
  • Page 10: Troubleshooting Guide

    DIGIWAY PTY LTD 8.2 P750 manual release A: What to do during a power failure: The gate can be manually pushed open and close if there is no power. To do this, you need to release the release bolt. (1) Open the front door and turn the switch(circuit breaker) OFF(even though there is no power) (2) Fit spanner (provided) onto the manual release bolt nicely.
  • Page 11 2) power off and disengage the motor and Status LEDs flash push and pull the gate manually Gate opened or 1) mechanical release bolts not 1) Power off and tight the bolts(P750 only) closed position not tight (P750 only) and power again. Please follow the manual right release procedure.

This manual is also suitable for:

P550
