- Page 1 DIGIWAY PTY LTD INSTRUCTION MANUAL P750 Sliding Gate Motor P550 Sliding Gate Motor Version –V4.3...
-
Page 2: Table Of Contents
DIGIWAY PTY LTD IMPORTANT SAFETY WARNING ATTENTION To prevent electrical shock, disconnect from power source before installing or service ATTENTION Electricity and power motors associated accessories could be fatal or at least cause seriously injury. All main voltage wiring must be installed by a licensed electrician. -
Page 3: General Layout
DIGIWAY PTY LTD GENERAL LAYOUT Fig -1 1) Manual Release bolts 2) Motor 3) Circuit breaker 4) Mounting Plate 5) Terminals 6) Control board 7) Inverter (VSD) 8) Fuse 9) EMC filter 10) Gearbox... -
Page 4: Specifications
CONTROL INPUIT AND BUTTON 1. General Descriptions The P550, P550-2 and P750 sliding gate motors was designed for heavy duty industry track gate or cantilever gate. Heavy duty three phase industry motor driven by VSD (variable speed drive), gate can run at different speeds. -
Page 5: Dip Switch Functions
DIGIWAY PTY LTD CONTROL INPUIT AND BUTTON Open (OPN) input & OPN push button The OPN inputs are Push Button OPN and Terminal OPN input. Push OPN button or Activating (connect OPN terminal to the COM (+12V)) the OPN input will start the gate to open. When gate opened, if OPN is still activating, the gate will stay open. -
Page 6: Control Board Set Up
DIGIWAY PTY LTD CONTROL BOARD SETTING PE trig close (DIP5) ON=PE CLS OFF=NO PE CLS DIP5 ON selects PE beam trig auto close mode. In this mode, if P.E beams trigged and clear the gate will auto close after gate opened. -
Page 7: Factory Default Setting
DIGIWAY PTY LTD CONTROL BOARD SETTING Lock pulse time set Push and hold on OSC for the lock pulse time setting. Now the red and green LED flash fast alternatively, and when gate reached the required time, simply release OSC button. Set DIP1 OFF. -
Page 8: Inverter Setting
DIGIWAY PTY LTD INVERTER SETTING 6. Inverter settings When the gate stops, the inverter’s display is opening high-speed frequency and flash. This frequency can be changed by up and down arrows on the inverter. The following form is the inverter’s standard setting for the automatic gate application. - Page 9 DIGIWAY PTY LTD SCHEMATIC DIAGRAM 8. Schematic diagram...
-
Page 10: Manual Release
DIGIWAY PTY LTD MANUAL RELEASE 9. Manual release A: What to do during a power failure: The gate can be manually pushed open and close if there is no power. To do this, you need to release the release bolt. -
Page 11: Trouble Shooting Guide
DIGIWAY PTY LTD TROUBLE SHOOTING GUIDE 10. Trouble Shooting Guide 10.1 Display information on main control board – see Fig-2 (1) Gate status LED Gate Status(Position) \ LEDs Status LED-Green (6) Status LED-Red (7) Gate in closed position Slow Flash... -
Page 12: Condition Of Sales
DIGIWAY PTY LTD Status LEDs flash push and pull the gate manually Gate opened or 1) mechanical release bolts not 1) Power off and tight the bolts and power closed position not tight again. Please follow the manual release right procedure. - Page 13 DIGIWAY PTY LTD 5. Returns Returns only accepted within 14 days of invoice. Credits only paid after inspection of goods. All returns subject to 30% re-stocking fee on product. Damaged goods are subject to further charges to the value of the damage.
