Page 7: About This Guide
About this guide Welcome to the installation and specification guidelines for your Threat Protection System (TPS) device. This section covers the following topics: • Target audience on page 1 • Related documentation on page 1 • Conventions on page 1 Product support •... -
Page 8: Product Support
Convention Element • GUI elements that are clicked or selected, such as menu and list items, buttons, and check boxes. Example: Click OK to accept. Italics font Text emphasis, important terms, variables, and publication titles Monospace font • File and directory names •... - Page 9 tippingpoint.support@trendmicro.com Phone support North America: +1 866 681 8324 International: See https://tmc.tippingpoint.com Threat Protection System Hardware Specification and Installation Guide...
-
Page 10: Overview
Overview The TippingPoint Threat Protection System (TPS) is a high-performance, enterprise-class solution that protects your network by scanning, detecting, and responding to network traffic according to the filters, action sets, and global settings maintained on each device by a client. The TPS offers higher throughput and improved technology that is optimized for high resiliency, high availability, and network segment protection from both external and internal attacks. - Page 11 The 440T device has the following hardware features: Feature 440T device Copper ports 1GbE SFP ports None 10GbE SFP+ ports None Power supply One 350W (built-in) System memory 16GB External CFast card 1 (8GB) Replaceable fans High Availability (HA) Zero Power High Availability (ZPHA) Built-in ZPHA on the 8 copper ports In addition, the device includes: •...
-
Page 12: 2200T Device
• Device management through the Local Security Manager (LSM) or centralized management through the Security Management System (SMS). 2200T device Figure 2. 2200T device The 2200T device has the following hardware features: Feature 2200T device Copper ports 1GbE SFP ports 10GbE SFP+ ports Power supply Two 750W (removeable) - Page 13 Feature 2200T device High Availability (HA) Zero Power High Availability (ZPHA)* Built-in ZPHA for copper segments External ZPHA port for SFP and SFP+ segments *For information on installing and operating a ZPHA module, refer to TippingPoint Modular Fiber/Copper ZPHA Installation Guide available on the TMC (http://tmc.tippingpoint.com). In addition, the device includes: •...
-
Page 14: Tippingpoint 440T Hardware Description
TippingPoint 440T hardware description This information describes the components, chassis, requirements, and installation specifics of the TippingPoint 440T device. The following topics are discussed: • Device overview on page 8 • Model requirements on page 12 • Technical specifications on page 12 •... -
Page 15: Chassis Back Panel
4. Serial console port/Management port 5. Alert indicator 6. System status indicator 7. Power indicator Chassis back panel The following illustration shows a rear-panel view of a 440T device. Figure 4. 440T device back panel 1. Fans (3) 2. AC power supply 3. -
Page 16: Power Switch And Power Indicator
Power switch and power indicator The power switch is located on the right side of the back panel. The power indicator on the front panel indicates the current power status of the device. No light — Device is powered off. •... -
Page 17: Ports
Ports The device is equipped with eight copper ports. In addition, the device includes the console and management ports shown in the following figure: Figure 5. Management and Console ports 1. 1 RJ-45 serial console port 2. 1GbE copper management port 3. -
Page 18: Model Requirements
LED Type Color Description No traffic is passing. Model requirements The following topics describe the power and cabling requirements for the 440T device. Power requirements • on page 12 • Cabling requirements on page 12 Power requirements The 440T device requires one input of Alternating Current (AC) that must meet the following requirements: •... -
Page 19: Installing The Device
Specification Description Service Provider Temperature: 32 – 104° F (0 – 40° C) — Operating operating Temperature: -4 – 158° F (-20 – 70° C) — Storage requirements Altitude: No degradation up to 10,000 feet (3048 m) Humidity: 5% to 95% (non-condensing) External interfaces •... -
Page 20: Tippingpoint 2200T Hardware Description
TippingPoint 2200T hardware description This information describes the components, chassis, requirements, and installation specifics of the TippingPoint 2200T device. The following topics are discussed: • 2200T device overview on page 14 • Model requirements on page 19 • Technical specifications on page 19 •... -
Page 21: 2200T Chassis Back Panel
1. 10GbE SFP+ ports 2. 1GbE SFP ports 3. 1GbE copper ports 4. External CFast card 5. Dedicated HA port 6. ZPHA port 7. Console/Management port 8. Power button 9. Alert indicator 10. System status indicator 2200T chassis back panel The following illustration shows the rear-panel view of a 2200T device. -
Page 22: 2200T Chassis Features
1. Fans (3) 2. Power supplies (2) 2200T chassis features The chassis features include the following elements: • Power button on page 16 • System status indicator on page 17 • Alert indicator on page 17 • Fans and power supplies on page 17 External storage card •... -
Page 23: System Status Indicator
System status indicator The System Status indicator is located on the right side of the front panel and indicates the current operating status of the appliance. Flashing Green — Appliance is booting and is not yet ready to inspect traffic. •... - Page 24 1. 1 RJ-45 serial console port 2. 1GbE copper management port 3. Link LED 4. Activity LED The management port LEDs indicate link and activity state, as described in the following table. LED Type Color Description Link Green Link is active at 1000Mbps. Link is inactive, or is active at 10Mbps or 100Mbps.
-
Page 25: Model Requirements
Model requirements The following topics describe specific requirements for the 2200T device. Power requirements • on page 19 • Cabling requirements on page 19 Power requirements The 2200T device requires one input of Alternating Current (AC) or Direct Current (DC) that must meet the following requirements: •... -
Page 26: Hardware Installation And Configuration
Specification Description The appliance’s maximum power consumption is 493 W. Service Provider Temperature: 32 – 104° F (0 – 40° C) — Operating operating Temperature: -4 – 158° F (-20 to 70° C) — Storage requirements Altitude: No degradation up to 10,000 feet (3048 m) Humidity: 5% to 95% (non-condensing) External interfaces •... -
Page 27: Installing The Tps Device
Installing the TPS device After you have completed preparation procedures and unpacked the TPS device, you are ready to install and configure the components. Have the CLI Reference available for configuration information reference. After installation of the hardware components, complete the OBE Setup Wizard requirements as part of the installation and configuration procedures. -
Page 28: Attach The Device To The Rack
Attach the device to the rack The TPS 440T device ships with a four-post rack-mount kit to mount the device to a rack. You can use this kit to install the device in a two-post or four-post rack. The TPS 2200T device ships with a slide rail kit to mount this device to a four-post rack and mounting ears for two-post racks. - Page 29 1. Align the two front rack-mounting brackets (shown in Figure 9 on page 23) with the 440T chassis holes according to your front mount or mid-mount requirements. 2. Secure the brackets to the chassis using the flat-head screws (six on each side) that came with the kit. Figure 9.
-
Page 30: Four-Post Rack Mount
Four-post rack mount Describes how to mount a 1U TPS device in a four-post rack. 1. After attaching the front rack-mounting brackets to the device as described in Two-post rack mount page 22, attach the two slide-bracket screws (provided in the kit) on each side of the chassis. 2. -
Page 31: Rack-Mounting The Tps 2200T Device
Rack-mounting the TPS 2200T device The TPS 2200T devices are 2U devices that you can install using a front mount or mid-mount in a two-post rack, or front and rear mount in a four-post rack. Two-post rack mount for 2U chassis Describes how to mount a 2U TPS device in a two-post rack. - Page 32 3. Secure the rack-mounting ears into the holes of the front rack post with screws (two on each side, not included). Figure 14 on page 26 as a guide for how the front rack-mounting brackets are attached to the appliance and to the rack in a front mount. Use Figure 15 on page 26 as a guide for how the front rack-mounting brackets are attached to the appliance and to the rack in a mid-mount.
-
Page 33: Four-Post Rack Mount For 2U Chassis
Four-post rack mount for 2U chassis Describes how to mount a 2U TPS device in a four-post rack. The 2200T models ship with a slide rail kit to mount the appliance to a four-post rack. Slide rail kits are also available for order from TippingPoint. -
Page 34: Connect The Power Supply
Connect the power supply Describes how to get power to your device. 1. After you have bolted the device to the rack, attach the power supply AC connections. 2. To turn power on for the 440T device, flip the power switch on the back panel of the device. 3. -
Page 35: Check Leds
All ports on the TPS device are dynamic and do not require fixed cable assignments. When making your network cable connections, keep track of which ports you select for which purpose. 1. Attach one or more network cables for the internal network. Make note of which front panel ports you use. -
Page 36: Connector And Cable Pinout Specifications
Connector and cable pinout specifications This information provides connector and pinout information for the TPS device and contains the following topics: • RJ-45 (COM) console on page 30 • RJ-45 Ethernet connectors on page 31 • Pluggable transceivers on page 31 RJ-45 (COM) console Describes the RJ-45 (COM) console specifications. -
Page 37: Rj-45 Ethernet Connectors
Pin number Signal name Clear to Send (CTS) RJ-45 Ethernet connectors Provides pinout information for when your RJ-45 device is operating in 10Mbps/100Mbps mode. Pin number Signal name Transmit positive (Tx+) Transmit negative (Tx-) Receive positive (Rx+) Ground (GND) Ground (GND) Receive negative (Rx-) Ground (GND) Ground (GND) - Page 38 • 10G SFP+ LC LR Note: Only optical transceiver modules (including SFP and SFP+) available from TippingPoint have been validated to achieve optimal performance with TippingPoint products. Other vendor devices are not supported. Using other vendor devices could be detrimental to proper operation of the TippingPoint system.
-
Page 39: Power Supply And Fan Modules
Power supply and fan modules This topic provides information for using the power supply modules and fans. The following subjects are discussed. • The 2200T AC power supply on page 33 • The 2200T DC power supply on page 34 •... -
Page 40: Connect The Ac Power Supply
3. Status LED 4. AC male power input The Status LED is green when the module is powered and running normally. Connect the AC power supply Describes how to connect the power supply to your device. When the AC power supply has been securely placed in the device, use the following procedure to connect power to the AC power supply: 1. - Page 41 When the DC power supply has been securely placed in the device, use the following procedure to connect power to the DC power supply. 1. Locate the ground screw on the back of the chassis. Refer to the following figure for the location. Figure 19.
-
Page 42: Tps Fans
TPS fans The 440T device includes five cooling fans (two of them are internal). The fans are not redundant or hot- pluggable. If a failure to a fan module occurs, you must replace the entire device. The 2200T device includes three cooling fans. The fans for the 2200T device are redundant but not hot- pluggable. - Page 43 After you have identified the faulty fan assembly, follow this procedure to replace the fan: 1. Power down the system. 2. Remove the top two attachment screws and lift the fan unit up slightly and partially pull it from its slot. 3.
-
Page 44: Installing The Power Cord Retention Bracket
Installing the power cord retention bracket The power cord retention bracket lets you manage the placement of power cords for minimal obtrusiveness. The following subjects are discussed: • Power cord retention bracket on page 38 • Installing and using the bracket on page 38 •... -
Page 45: Installing The Bracket
Follow the procedures in this section to install and use the power cord retention bracket and the cable management bracket. Installing the bracket Use the following procedure to install the power cord retention bracket: 1. Orient the bracket against the back surface of the chassis. 2. -
Page 46: Using The External Cfast Storage Card
Using the external CFast storage card This information describes the external storage card and provides the following topics: • About the external CFast storage card on page 40 • CFast card commands on page 40 About the external CFast storage card The TPS device comes with a pre-formatted external CFast storage card. - Page 47 Command Description Note: Only cards that are mounted and formatted manually by the user will be mounted automatically by the device when it boots. However, after the initial install, any card still present in the device during subsequent installs will also be mounted automatically.
- Page 48 Command Description master-key set Encrypts the external CFast card and the system keystore using the system master-key. You are prompted to enter a master- key that is between 9 and 32 characters in length, contains a combination of numbers and uppercase and lowercase letters, and that has at least one special character (for example, !@#).
