F&eIT Series AC-DC Power Supply Unit
POW-AD22GY or POW-AD13GY
Congratulations on your recent purchase of a AC-DC Power Supply Unit.
Copyright
-
Copyright 2001 CONTEC CO., LTD. ALL RIGHTS RESERVED. No part of this document may be
copied or reproduced in any form or by any means without prior written consent of
CONTEC CO., LTD.
-
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in
this document. The information in this document is subject to change without notice.
-
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
-
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for any results of using the product.
-
F&eIT is a registered trademark of CONTEC CO., LTD. Other company and product names
mentioned herein are generally trademarks or registered trademarks of their respective owners.
Trademarks
-
All company and product names that are referred to in this manual are generally trademarks or
registered trade.
Handling Precautions
CAUTION
-
This power supply is dedicated to the F&eIT. Do not use for the other devices.
-
Do not use or store the equipment in a hot or cold place, or in a place that is subject to severe
temperature changes. (Operating temperature range: 0 - 50°C)
-
Do not use or store the equipment in a place subject to direct sunlight or near a heating device, such
as a stove.
-
Do not use or store the equipment in a dusty or humid place.
(Operating humidity range: 10 - 90%RH, No condensation)
-
As this product contains precision electronic components, do not use or store in environments
subject to shock or vibration.
-
Do not use or store the product near equipment generating a strong magnetic field or radio waves.
-
If you notice any strange odor or overheating, please unplug the power cord immediately.
-
In the event of an abnormal condition or malfunction, please consult the dealer from whom the
equipment was purchased.
1
User's Manual
CONTEC CO.,LTD.
POW-AD22GY, POW-AD13GY
Advertisement
Table of Contents
Related Manuals for Contec POW-AD22GY
Summary of Contents for Contec POW-AD22GY
-
Page 1: Handling Precautions
All relevant issues have been considered in the preparation of this document. Should you notice an omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD. Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may appear in this document or for any results of using the product. -
Page 2: Product Configuration
DC Power Supply output connector plug...2 About the POW-AD22GY or POW-AD13GY The POW-AD22GY or POW-AD13GY is a compact power supply unit designed to supply DC power to the F&eIT series of products. This AC-DC power supply unit is carrying out the standard equipment of the DIN rail attachment mechanism to the main part like other products of this series, and can install it simply and smartly. -
Page 3: Compliance Requirements
The low voltage directives require that devices operating from power supplies in the range 50 - 1000 VAC or 75 - 1500 VAC observe necessary safety precautions. The following describes the main points to note so that installations using the POW-AD22GY can comply with the low voltage directives. -
Page 4: Led Indicator
POW-AD22GY, POW-AD13GY User’s Manual Nomenclature Connector Name Function 2-piece power input connector (detachable). input A dedicated plug as a standard item. port Screw-in type cable connection. 2-piece power output connector (detachable) output A dedicated plug as a standard item port... -
Page 5: System Reference
POW-AD22GY, POW-AD13GY User’s Manual System Reference Specifications2 Item Specifications POW-AD22GY POW-AD13GY Input Voltage AC85 - 264V AC85 - 132V Current ACIN 100V:0.3A(Typ. Io=100%) ACIN 100V:0.4A(Typ. Io=100%) ACIN 200V:0.2A(Typ. Io=100%) Frequency 47 - 440Hz Rush current ACIN 100V:15A(Typ. Io=100%) ACIN 100V:25A(Typ. Io=100%) ACIN 200V:30A(Typ. -
Page 6: Installation Environment Requirements
POW-AD22GY, POW-AD13GY User’s Manual Installation Environment Requirements Parameter Requirement description Ambient temperature 0 - 50ºC Ambient Humidity 10 - 90%RH (No condensation) Floating dust particles Not to be excessive Corrosive gases None Noise Line-noise AC line/2kV, Signal line/1kV (IEC1000-4-4Level 3, EN61000-4-4Level 3) -
Page 7: Installation Method
POW-AD22GY, POW-AD13GY User’s Manual Installation Method Mounting the AC-DC Power Supply Unit on the DIN Rail Mounting procedure Removal procedure (1) Pushing the fixing hook with a flat-blade (1) Lower the fixing hook for the unit to unlock screwdriver renders it into a lock-enabled condition. -
Page 8: Connection Method
CAUTION Because the AC-DC power supply unit generates heat, a minimum spacing of 2.0 cm should be provided between the POW-AD22GY or POW-AD13GY and any adjoining units, and care should be taken so that the ventilation holes are not covered.
