INSTALLATION, OPERATION and MAINTENANCE
MANUAL for Cres Cor AquaTemp
CO151FWUA12DE
CO151FWUA12DX
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
CONVECTION OVENS
CO151FPWUA12DE
CO151FPWUA12DX
Convection
Humidity Oven
Rev. 4 (6/15)
HUMIDITY
™
CO151HWUA6DE
CO151XWUA5DE
CO151HWUA6DX
CO151XWUA5DX
FL-2373
Page 1 of 14
Advertisement
Table of Contents
Related Manuals for Cres Cor CO151FWUA12DE2081
Summary of Contents for Cres Cor CO151FWUA12DE2081
- Page 1 Rev. 4 (6/15) 5925 Heisley Road • Mentor, OH 44060-1833 INSTALLATION, OPERATION and MAINTENANCE MANUAL for Cres Cor AquaTemp HUMIDITY ™ CONVECTION OVENS CO151FWUA12DE CO151FPWUA12DE CO151HWUA6DE CO151FWUA12DX CO151FPWUA12DX CO151XWUA5DE CO151HWUA6DX CO151XWUA5DX Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
- Page 2 DO NOT OPEN WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
-
Page 3: Installation Instructions
AUTO FILL: If water level is low and water supply is not It will reduce scaling. connected, an error code will display after a time limit . Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... -
Page 4: Operating Instructions
4 . The control automatically switches to allow you to set been holding . HOLD temp . (Continue to step 1 below) . Holding: (To use as holding cabinet only, skip steps 1-4 above and Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... - Page 5 . - “HOLD”: Shows home screen, set point, count up 2 . Push the knob to set the temperature . time, actual oven temperature . Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
- Page 6 “RECF” allows you set how often (in minutes) a datapoint will be recorded . “RECD” allows you to set how long (in days) you would like the data to be stored in memory . Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
-
Page 7: Setting The Humidity
The DISPLAY BUTTON momentarily shows the approximate relative humidity in the oven . When water level is low, %RH is not correct, so no value is displayed and the water heater does not heat . Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... -
Page 8: Maintenance Instructions
Stainless Steel. directions. (Stainless Steel) HARD WATER SPOTS & 1. Swab or wipe with cloth. Vinegar SCALE 2. Rinse and dry. * Mild detergents include soaps and non-abrasive cleaners Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... - Page 9 Refer to our Service Agency list, FL-1400 (found in the back of this manual), of authorized service centers . Instructions for replacing parts are included in replacement parts list . Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
-
Page 10: Error Codes
2. AquaTemp control 2. Replace ERROR CODES: CODE DISPLAYED CAUSE SOLUTION no p No meat probe Plug in probe Err0 Temp probe bad Replace Err1 Water fill time out Connect water supply Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... -
Page 11: Replacement Parts
0569-306-K 0569-306-K 0569-310 Casters w/Brake 0569-306-BK 0569-306-BK 0569-306-BK 0569-306-BK 0569-310-B Posts 0696-250 0696-250 0696-250 0696-250 0696-252 Air Tunnel 0546-146-C 0546-146-C 0546-146-C 0546-161 0546-162 Pan, Drip 1017-058 1017-058 1017-058 1017-058 1017-098 Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... - Page 12 4700W, 1PH 4700W, 3PH Power Cord 0810-124 0810-132 0810-163 0810-164 Heater Kit, 208V 0811-306 0811-306 0811-311 0811-311 Heater Kit, 240V 0811-305 0811-305 0811-312 0811-312 Strain Relief 0818-061 0818-050 0818-102 0818-050 Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
-
Page 13: Wiring Diagram
Convection FL-2373 Humidity Oven Page 13 of 14 Rev. 4 (6/15) 5925 Heisley Road • Mentor, OH 44060-1833 WIRING DIAGRAM OVENS CO151FW SERIES 208/240V 1 Ph Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com... - Page 14 Convection FL-2373 Humidity Oven Page 14 of 14 Rev. 4 (6/15) 5925 Heisley Road • Mentor, OH 44060-1833 WIRING DIAGRAM OVENS CO151FW SERIES 208/240V 3 Ph Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
