Summary of Contents for elero AstroTec-915ac
- Page 1 AstroTec-915 elero USA 10827 Alder Circle USA-Dallas Texas 75238 info@eleroUSA.com Operating instructions elero GmbH Please keep these instructions in a safe place. Antriebstechnik Linsenhofer Str. 59–63 D-72660 Beuren info@elero.de www.elero.com 309104 01 Nr. 18 100.5601/0606...
-
Page 2: Table Of Contents
Contents Contents Safety instructions ........USA- 3 Programme (Setting control commands and idle periods) Instruction to the user . -
Page 3: Safety Instructions
Warning! and if not installed and used in accordance with the instructions, • Use unmodified elero original parts only. may cause harmful interference to radio communications. • Keep persons away from the systems guide However, there is no guarantee that interference will not occur in track. -
Page 4: Explanation Of Displays And Buttons
Explanation of displays and buttons General information/Designated use Explanation of displays and buttons General information The AstroTec-915, delivered from the factory with current date and time settings (GMT), automatically controls the drive at the astro Manual/automatic times (sunrise and sundown). sliding switch UP button The AstroTec-915 can be operated manually at any time. -
Page 5: Initial Operation
Installation Initial operation/Factory settings Wall bracket installation Initial operation To activate the AstroTec-915 timer, touch any button on the device. Note: Radio sets transmitting at the same frequency can lead to To select the language required use the +/- buttons and confirm interference in the reception. -
Page 6: Light Sensors
Light sensors/Explanation of functions Explanation of functions Light sensors +/- buttons The following operations are possible using the + and - buttons: Note: If you wish to connect a light sensor to the AstroTec 868, the instructions provided with the light sensor must be followed. •... -
Page 7: Programme
Explanation of functions Explanation of functions Programme ASTRO The AstroTec-915 automatically controls your roller shutters or PROGRAMME blinds at the pre-set sunrise and sunset times. These times are The PROGRAMME menu allows you to set various switching times: used as guidelines. 1. -
Page 8: Switching Time, Offset
Explanation of functions Explanation of functions WEEK SWITCHING TIME Using the WEEK menu, you can set the same switching times from Automatic switching times for roller shutters and blinds to be Monday – Sunday (1-7). raised and lowered. BLOCK OFFSET Using the BLOCK menu, you can set two blocks. -
Page 9: Intermediate Position, Ventilation/Reverse
Explanation of functions Explanation of functions SETTING INTERMEDIATE POSITION The intermediate position is a position of the roller shutter/blind The SETTING menu gives you the following options: between the upper and lower limits that can be freely selected. • HOLIDAY This position can also be reached from the upper position after •... -
Page 10: Longitude/Latitude/Time Zone
Explanation of functions Explanation of functions Language (ENGLISH GB) FUNCTION You can select your national language. This mode is intended for qualified electricians only! (Will only appear when the operating device is disconnected) ASTRO SHIFT The FUNCTION menu gives you the option of setting the following With the astro shift setting, the astro time v and astro time b can functions: be shifted independently of one another (max. -
Page 11: Programming Radio Channel Settings
Programming additional transmitters/ Programming radio channel settings Deleting transmitters Programming radio channel settings Programming additional transmitters To programme additional transmitters in one receiver, please proceed Programming transmitter/channel as follows: Prerequisite: The drive must be installed. 1. Press the UP, DOWN and programming button P on a transmitter that has already been programmed in the receiver until the LED 1. -
Page 12: Programming
Programming Programming Main menu (Overview of the menu) PROGRAMME PROG1/ASTRO WEEK (Astro function for week + idle period v b) Operating mode PROG1/ASTRO BLOCK (Astro function for block 1/2 + idle period v b) MENU PROG1/ASTRO INDIVIDUAL (Astro function for individual + idle period v b) +/–... -
Page 13: Prog 1 Astro Evening
Programming Programming ASTRO WEEK 4. Confirm by pressing OK. ASTRO EVENING appears. Press +/- for the WEEK menu level (1-7). All further entries 5. Confirm by pressing OK. now refer to every day of the week. 6. Now select the PROG1 ASTRO function you require using +/- : Confirm by pressing OK. - Page 14 Programming Programming PROGRAMME INDIVIDUAL INDIVIDUAL Press +/- for the INDIVIDUAL menu level (1,2,3,4,5,6,7). PROG1/INDIVIDUAL WEEK (Individual switching time v b for week) All further entries now refer to every individual day of the week. PROG1/INDIVIDUAL BLOCK (Individual switching time v b for block 1/2) Confirm by pressing OK.
-
Page 15: Prog 2 Offset
Programming Programming 8. Now select the PROG2 INDIVIDUAL function you require using PROGRAMME the +/- buttons: PROG 2/OFFSET (e.g. shutters are lowered to ventilation position in INDIVIDUAL BLOCK the evening) Press +/- for the BLOCK menu level (BLOCK 1 (1-5), BLOCK 2 (6,7)). -
Page 16: Setting
Programming Programming SETTING SETTING HOLIDAY, LIGHT SENSOR (Holiday OFF/ON, sun/twilight setting) INTERMEDIATE POSITION, VENTILATION/REVERSE, PROG1 END LIMIT (Time/ position programming) LIGHT SENSOR SETTING HOLIDAY PROG 1 CONNECTED ? INTERMEDIATE VENTILATION next page previous page POSITITION (REVERSE) END LIMIT next page +/–... -
Page 17: English Gb, Astro Shift
Programming Programming SETTING SETTING PROG 2 END LIMIT (Time/ position programming) ENGLISH GB/ ASTRO SHIFT v b (Language, astro shift) PROG 2 next page previous page END LIMIT ASTRO TEST MODE previous page ENGLISH GB +/– ON/OFF SHIFT v +/– +/–... - Page 18 Programming Programming 7. You can set the required astro shift b (max. +/- 120 mins.) using Note: These dialog windows (LONGITUDE, LATITUDE, TIME ZONE) the +/- button. are only displayed when the EXPERT MODE in the function menu is ON. 8.
-
Page 19: Function
Technical data/Battery replacement/ Programming Cleaning FUNCTION (only when the operating device is disconnected, only for Technical data qualified electricians) Nominal voltage 3 V DC ROLLER SHUTTER/BLIND, DRIVE CONTROLLER/ GROUP CONTROLLER, RUNNING TIME Battery type 2 x LR 03 (AAA) (Selection of shutter/blind, selection of the drive controller/ group System of protection IP 20 controller, running time of the roller shutter/blind) -
Page 20: Troubleshooting
3. Switch holiday General declaration of conformity: switched on. function off. The company elero GmbH hereby declares that the AstroTec-915 4. Astro shift is set. 4. Adjust astro shift. is in conformity with the basic requirements and other relevant provisions of the Directive 1999/5/EC.
