Jindara Tilga Freestanding Operation & Installation Instructions

Advertisement

Quick Links

Tilga Freestanding
1. Subject to clauses 2 & 3 of this warranty, A.F. Gason Pty Ltd ACN 004 667 556 warrants the following components of its heaters against defects in workmanship
and/or materials for the following periods from the date of purchase:
a) the rebox for ten years;
b) the paint nish for a period of 12 months if the purchaser has followed the instructions provided by Gason in the operation and Installation Instructions manual; and
c) all other components for 12 months except the glass, re brick lining or ba e plate if, in the opinion of Gason, these items have been damaged by impact.
2. This extended warranty does not apply;
a) if the heater is purchased from a person who has not been authorised by Gason to sell its products;
b) if, in the opinion of Gason, the heater or any other component has been subject to abuse, misuse, alteration, modi cation or has not been installed, operated or maintained in
accordance with the instructions provided by Gason; or,
c) to owners other than the original purchaser.
3. If you believe that the heater you purchased contains a manufacturing defect and you wish to make a claim under this warranty, please contact an authorised Gason service
centre to arrange for an assessment.
4. If, after assessing the heater, Gason determines that the heater contains a manufacturing fault, Gason may at its discretion:
a) replace the heater;
b) repair or replace speci c components of the heater; or
c) provide a full refund.
5. Parts replaced under warranty are warranted for the balance of their original warranty period.
6. If, at the discretion of Gason, the heater or any part needs to be replaced, serviced or repaired at an authorised Gason service centre, then the person claiming under this
warranty must pay all costs associated with:
a) returning the heater; and
b) the delivery or collection of any new or repaired heater.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
Any bene ts you receive under these warranties are in addition to other rights and remedies that you may have as a consumer under law in relation to the heater to which
these warranties relate.
These warranties are given by:
AF Gason Pty Ltd
Blake Street
Ararat VIC 3377
Please contact us if you have any queries on:
Phone: 03 53522151
or email us via the "Contact Us" section of our website: www.gason.com.au
A.F. Gason Pty Ltd reserves the right to modify or alter speci cations, material, etc. in the interest of product improvement.
WARRANTY
16
Operation & Installation Instructions
Rev B
Please keep these instructions for future reference.
Tilga Freestanding
232342

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tilga Freestanding and is the answer not in the manual?

Questions and answers

Summary of Contents for Jindara Tilga Freestanding

  • Page 1 Tilga Freestanding WARRANTY 1. Subject to clauses 2 & 3 of this warranty, A.F. Gason Pty Ltd ACN 004 667 556 warrants the following components of its heaters against defects in workmanship and/or materials for the following periods from the date of purchase: a) the rebox for ten years;...
  • Page 2: Troubleshooting

    Tilga Freestanding Tilga Freestanding Troubleshooting Basic Dimensions (Continued) Read and follow these instructions carefully before installing and WARNING using this appliance Removing heater from pallet: To aid heater installation, remove door, top plate, ba e system and cast iron • Remove x2 Tek screws from rear of pedestal base.
  • Page 3: Installation

    Flue requirements 10% moisture As per the dimensions in Figure 1 & 2 the Jindara Tilga can be installed with a Perforated 6” Default Flue Kit including a 88% thermal e ciency 900mm180 degree ue shield, or Figure 3 & 4 a Solid 6” Default Flue Kit.
  • Page 4 Squeeze locator tabs together on the rear of the thermostat switch and push through outside of pedestal. edge of the appliance side panel. Disconnect the wiring from the power lead and remove the fan. Convey the same to the authorised Jindara Dealer from whom you purchased your unit for service.
  • Page 5 Tilga Freestanding Tilga Freestanding Installation Basic Spare Parts (Continued) Parallel Installation - Solid Outer Flue Kit Figure 3 - 6” Active Flue with an 8” Solid painted outer ue casing. In this appliacation the 180 degree x 900mm ue shield supplied with the heater is not required due to the additional heat retention at the ceiling level inside the solid casing.
  • Page 6 Insulated Ba e System, AF Gason Pty. Ltd. reserve the right to disallow any warranty or claims in relation to the abovementioned. The Jindara Tilga’s ba e system comprises of three components: • 8mm Steel Plate • 13mm DuraBlanket 12mm Silicaboard •...
  • Page 7 The ue pipe shall extend not less than 4.6m above the top of the oor protector. Note: Installation must be ue brush from your local Jindara Dealer and proceed up onto the roof. Remove the cowl. Slowly push the brush down carried out by a licensed installer in accordance with AS/NZS 2918:2001.
  • Page 8 (Continued) Fan operation Your Jindara Tilga is equipped with a temperature-sensitive thermostat switch located within the heaters pedestal beneath DO NOT ATTEMPT TO OPERATE THIS APPLIANCE WITHOUT READING AND the rebox, which when selected will turn the fan on and o depending on the temperature of the rebox.
