- Page 1 Document No. Issue No. Author ACTIVE October 24, 2018 651247100A 800-523-6049 www.blondertongue.com Blonder Tongue is ISO 9001:2015 Certified ©2018 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
-
Page 2: Product Introduction
• Distributes DC power to the various sections and modules via (2) fully-redundant, hot-swappable power supplies The NeXgen Platform is designed to be installed in a standard 19" rack. Up to 12 Modules, along with the required Master Controller and Power Supply Modules, can be installed into a single NXG Platform Mainframe. - Page 3 Step 1: Setting up the Mainframe Adequate ventilation is very important in NeXgen chassis installations. The NeXgen chassis Airflow is from front to back. Some air movement is advisable in enclosed rack cabinets. Excessive heat will shorten the life of components and individual module(s).
- Page 4 The system will not work if the MC module is installed into any other slot. Install the appropriate input and output modules for your NeXgen application in any of the 12 slots. When possible space the input and output modules apart to maximize airflow.
- Page 5 NeXgen platform. Enter the username “Admin” and “pass” as the password and click [LOG IN]. Step 5: Basic Configuration Once you are logged into the NeXgen, you will be presented with the “System Status” page (“Status” tab):...
-
Page 6: Troubleshooting
Step 6: Module Configuration After the hardware installation of any additional modules, go through the control panel and set up each module slot to configure your NeXgen application. Please refer to the user manuals of each module for in-depth configuration. Module Slot Tabs are accessed here. - Page 7 NeXgen Platform Base Quick Guide NOTES...
- Page 8 A Return Material Authorization (RMA) Number is required on all products returned to Blonder Tongue, regardless if the product is being returned for repair or credit. Before returning product, please contact the Blonder Tongue Service Department at 1-800-523-6049, Ext. 4256 or visit our website: www.blondertongue.com...
