- Page 1 User Manual Solar Charger Controller SC-20/40 MPPT Version: 1.1...
-
Page 2: Table Of Contents
Table Of Contents 1.Safety instrucitons and waiver of liability ....................1 1.1 Safety Instructions ............................. 1 1.2 Liability Exclusion ............................1 2. Pruduct Overview ............................2 2.1 Outstandong Features 2.2 MPPT ................................. 2 2.3 Four Charging Stage .......................... -
Page 3: Safety Instrucitons And Waiver Of Liability
Dear Clients, Thanks for selecting OPTI-Solar SC MPPT series charger controller. Please take the time to read this user manual, this will help you to make full use of many advantages the controller can provide your solar system. This manual gives important recommendations for installing and using and so on. Read it carefully in your own interest and pay attention to the safety recommendations in it please. -
Page 4: Pruduct Overview
Magic series solar controller is based on an advanced maximum power point tracking (MPPT) technology developed, dedicated to the solar system, the controller conversion efficiency up to 97%. 2.1 It comes with a number of outstanding features, such as: Innovative Max Power Point Tracking(MPPT) technology, tracking efficiency >99.9% ... - Page 5 High Voltage Strings and Grid-Tie Modules Another benefit of MPPT technology is the ability to charge batteries with solar arrays of higher nominal voltages. For example, a 12 Volt battery bank may be charged with a 12-, 24-, 36-, or 48-Volt nominal off-grid solar array. Grid-tie solar modules may also be used as long as the solar array open circuit voltage (Voc) rating will not exceed the maximum input voltage rating at worst-case (coldest) module temperature.
-
Page 6: Four Charging Stage
2.3 MPPT—Four Charging Stage Magic series controller has a 4-stage battery charging algorithm for rapid, efficient, and safe battery charging. MPPT Charge In this stage, the battery voltage has not yet reached boost voltage and 100% of available solar power is used to recharge the battery. -
Page 7: Dimensions
3.1 The dimensions of SC-20MPPT... -
Page 8: The Dimensions Of Sc-40Mppt
3.2 The dimensions of SC-40MPPT... -
Page 9: Structure & Accessory
4.1 Structure & Characteristics of SC-20MPPT ①Heat Sink —dissipate controller heat ②Plastic Case —Internal protection ③LCD —Display settings and operating status, system parameters ④Key: MENU, OK Set and view the operating parameters ⑤RJ11 interface —Connecting monitoring devices ⑥Temperature Sensor Port. —Collect temperature information Temperature compensation. -
Page 10: Structure & Characteristics Of Sc-40Mppt
4.2 Structure & Characteristics of SC-40MPPT ①Heat Sink —dissipate controller heat ②Plastic Case —Internal protection ③LCD —Display settings and operating status, system parameters ④Key: MENU, OK Set and view the operating parameters ⑤RJ11 interface —Connecting monitoring devices ⑥Temperature Sensor Port. —Collect temperature information Temperature compensation. -
Page 11: Installation
5.Installation CAUTION: Please read all instructions and precautions in the manual before installing! It is recommended to remove the acrylic protective film covering the LCD screen before installation. 5.1 Installation Notes (1)The solar charge controller may only be used in PV systems in accordance with this user manual and the specifications of other modules manufacturers. -
Page 12: Wiring Specifications
5.3 Wiring Specifications Wiring and installation methods must comply with national and local electrical specifications. The wiring specifications of the solar, battery and loads must be selected according to rated currents, and see the following table for wiring specifications: Model Rated Rated Solar wire... -
Page 13: Grounding
WARNING: Risk of electric shock! Exercise caution when handing solar wiring. The solar PV array can produce open-circuit voltages in excess of 100V when in sunlight. Pay more attention to it. WARNING: Risk of explosion! Once the battery's positive and negative terminals or leads that connect to the two terminals get short-circuited, a fire or explosion will occur. -
Page 14: Operarion
6.Operation 6.1 LCD Display 6.1.1 Status Description PV array charge ampere hours and load ampere hours are off after power failure. -
Page 15: The Interface Automatically Cycles
6.1.2 The interface automatically Cycles 6.1.3 Press OK to browse the interface... -
Page 16: Fault Indication
6.1.4 Fault indication 6.2 Key function 6.3 USB interface MT-EU series have two USB interfaces, maximum output of single USB is 5V 1.5A, maximum output of two USB is 5V 2A, for charging mobile phones and other smart devices. The USB stops output only when the controller is in low voltage protection. -
Page 17: Parameters Setting
6.4 Parameters setting Test Function(Street lamp mode) When the controller is working in the street lamp mode, press the MENU key for 3 seconds to turn on the load. Press the MENU key again or the load turns off automatically after 1 minute. If the controller is operating in 24H output mode, the test function does not work. -
Page 18: Protections, Troubleshooting And Maintenance
User-defined mode When the controller is set to user-defined mode, the load is turned on by default. Short press the MENU key, the load will be turned off, press the MENU key again, the load will be turned on. Note: 1.If the controller turns off the load due to low voltage protection, overcurrent protection, short-circuit protection or over temperature protection, the load will turn on automatically when the controller recoverys from protection state,. -
Page 19: Troubleshooting
7.2 Troubleshooting 7.3 Maintenance The following inspections and maintenance tasks are recommended at least two times per year for best performance. Make sure no block on air-flow around the controller. Clear up any dirt and fragments on radiator. █ Check all the naked wires to make sure insulation is not damaged. Repair or replace some wires if necessary. █... -
Page 20: Technical Data
8. Technical Data 8.1 Technical data of SC-20MPPT Item SC-20MPPT Max Charging Current System Voltage 12V/24V automatical recognization MPPT Charging Voltage < 14.5/29.0V@25'C 14.5/29.0V @25℃ Boost Voltage 14.8/29.6V @25℃（Liquid, AGM) Equalization Voltage 13.7/27.4V @25℃ Float Voltage Battery Parameters Low Volt. Disconnect 10.8-11.8V/21.6-23.6V, S0C1-5(default: 11.2/22.4V) 11.6-12.8V/23.2-25.6V (default: 12.0／24.0V﹜... -
Page 21: Technical Data Of Sc-40Mppt
8.3 Technical data of SC-40MPPT Item SC-40MPPT Max Charging Current System Voltage 24V/48V automatical recognization MPPT Charging Voltage <29.0/58.0V@25'C 29.0/58.0V @25℃ Boost Voltage 29.6/59.2V @25℃（Liquid, AGM) Equalization Voltage 27.4/54.8V @25℃ Float Voltage Battery Parameters Low Volt. Disconnect 21.6-23.6V/43.2-47.2V, S0C1-5(default: 22.4/44.8V) 23.2-25.6V/46.4-51.2V (default: 24.0／48.0V﹜...
