- Page 1 ELECTROMAGNETIC FLOW METER Authorization n. 1035 “FULL BORE” SENSORS MODEL MS2410 INSTALLATION MANUAL...
-
Page 2: Table Of Contents
INDEX INTRODUCTION ___________________________________________ 3 START UP AND MAINTENANCE OF THE INSTRUMENTS _____________ 3 SAFETY _________________________________________________ 4 GENERAL INFORMATION ON THE SENSORS INSTALLATION _________ 5 ELECTRICAL CONNECTIONS OF SENSOR TO CONVERTER ___________ 6 GROUNDING INSTRUCTIONS ________________________________ 6 OVERALL DIMENSIONS _____________________________________ 7 THREADED CONNECTIONS __________________________________ 7 CLAMP CONNECTIONS ______________________________________ 8 INSPECTION SCREWS ______________________________________ 9... -
Page 3: Introduction
INTRODUCTION This manual is integral part of the product. Read carefully the instructions contained since it contains important indications for the safety of use and of maintenance. The technical information and the relative products of this manual could be modified without any previous notice. The flow meter must be used for the use it has been built for. -
Page 4: Safety
SAFETY Before using the instrument, always make a sure connection to the ground Avoid any attempt to repair the instrument. If the instrument is not functioning properly, please call the nearest assistance service Pay maximum attention during the operations ATTENTION !!! DANGER !!! Pag. -
Page 5: General Information On The Sensors Installation
GENERAL INFORMATION ON THE SENSORS INSTALLATION The manufacturer recommend to clean the instruments before use Flow direction Before install the sensor locate the direction of the liquid in the piping The sign of the flow rate is positive, when the flow direction is from – to + as printed on the tag plate. -
Page 6: Electrical Connections Of Sensor To Converter
ELECTRICAL CONNECTIONS OF SENSOR TO CONVERTER (CONNECTIONS TO CONVERTER: SEE PROPER MANUAL) GROUNDING INSTRUCTIONS For correct operation of the meter is NECESSARY that the sensor and the liquid are equipotential, so ALWAYS connect the sensor and converter to ground: Pag. 6 ESENS_FULLBORE_R01_MS2410_IS... -
Page 7: Overall Dimensions
OVERALL DIMENSIONS THREADED CONNECTIONS FITTINGS FITTINGS DIN 11851 DIMENSIONS mm (inches) (1/8") (1/4) (3/8) (1/2") (3/4") (1") (1"1/4) (1"1/2) (2") (2"1/2) (3") (4”) (3.03) (3.03) (3.03) (3.03) (3.03) (3.94) (3.94) (3.94) (3.94) (3.94) (3.94) (3.94) (5.04) (5.04) (5.04) (5.04) (5.04) (7.09) (7.09) (7.09) -
Page 8: Clamp Connections
CLAMP CONNECTIONS I ( Ø INTERNAL FITTING ) FITTINGS FITTINGS CLAMP ISO 2852 DIMENSIONS mm (inches) (1/8") (1/4) (3/8) (1/2") (3/4") (1") (1"1/2) (2") (2"1/2) (3") (4") (3.03) (3.03) (3.03) (3.03) (3.03) (3.94) (3.94) (3.94) (3.94) (3.94) (3.94) (5.04) (5.04) (5.04) (5.04) (5.04) -
Page 9: Inspection Screws
INSPECTION SCREWS Verify periodically the sensor’s seals integrity: with piping full of liquid, unscrew the Inspection screws (see drawing aside) and verify the total absence of liquid from inspection hole! After the above operation, REMEMBER to close again the holes. In case of leakage contact immediately our Customer Service. - Page 10 At the end of its lifetime, this product shall be disposed of in full compliance with the environmental regulations of the state in which it is located. Pag. 10 ESENS_FULLBORE_R01_MS2410_IS...
