The CATALOG Menu
Using the CATALOG menu, you can select functions and
variables that are available for what you are doing in the
currently selected mode. To display the CATALOG menu,
press N 0.
• Press u or d to move the cursor ( ) and press e
to select.
• Press l or r to scroll up or down.
• Press @ u or @ d to jump to the fi rst or last item.
Note: You cannot bring up the CATALOG menu when entering
values or items in STAT, MATRIX, LIST, or EQUATION
modes, or into solver functions or simulation calculations.
Multi-line Playback Function
This calculator is equipped with a function to recall previous
equations and answers in NORMAL or CPLX modes. A
maximum of 340 characters can be stored in memory. When
the memory is full, stored equations will be deleted to make
room, starting with the oldest.
Pressing u will display the previous equation. Further
pressing u will display preceding equations (after returning
to the previous equation, press d to view equations in
order). In addition, @ u can be used to jump to the
oldest equation, and @ d to jump to the newest one.
• To edit an equation after recalling it, press l or r.
• The multi-line memory will be cleared by the following
operations:
@ Z , mode change, RESET, N-base conversion,
angular unit conversion, editor change (@ J 2
0 or @ J 2 1), and memory clear (@
P 1 0).
• Equations that have one result require an additional eleven
characters' worth of memory to store in order to hold the result.
• In addition to the amount of memory needed to store an
equation, the WriteView editor will require a certain amount
for the sake of display.
• Equations also include calculation ending instructions, such
as " ".
Priority Levels in Calculation
This calculator performs operations according to the following
priority:
m
① Fractions (1 4, etc.) ② , Engineering prefi xes
③ Functions preceded by their argument (
x x r ⑤ Implied multiplication of a memory value (2Y, etc.)
y
④ ,
⑥ Functions followed by their argument (sin, cos, ( ), etc.)
⑦ Implied multiplication of a function (2sin 30, A
nPr, cv ⑨ , ⑩ , ⑪ AND ⑫ OR, XOR, XNOR ⑬ ,
M, ▶DEG, ▶RAD, ▶GRAD, DATA,
M , M ,
⇒
other calculation ending instructions
• If parentheses are used, parenthesized calculations have
precedence over any other calculations.

SCIENTIFIC CALCULATIONS

• Press b 0 to select NORMAL mode.
• In each example, press j to clear the display fi rst. Unless
otherwise specifi ed, calculation examples are performed in
the WriteView editor (@ J 2 0) with the default
display settings (@ P 0).
Arithmetic Operations
• The closing parenthesis ) just before = or m
may be omitted.
Constant Calculations
• In constant calculations, the addend becomes a constant.
Subtraction and division are performed in the same manner.
For multiplication, the multiplicand becomes a constant.
• In constant calculations, constants will be displayed as K.
• Constant calculations can be perfomed in NORMAL or STAT
modes.
Functions
• Refer to the calculation examples for each function.
• In the Line editor, the following symbols are used:
: to indicate an expression's power. (m, @ ",
•
@ Y)
• : to separate integers, numerators, and denominators.
(W, @ k)
• When using @ O or @ W in the Line editor,
values are entered in the following way:
• logn (base, value)
• abs value
Integral/Differential Functions
Integral and differential calculations can be performed in
NORMAL mode.
Note: Since integral and differential calculations are performed
based on the following equations, correct results may
not be obtained, in certain rare cases, when performing
special calculations that contain discontinuous points.
Integral calculation (Simpson's rule):
1
S h{ f (a) 4{
3
2{ (a 2h)
f
3
Differential calculation:
Performing integral calculations
1. Press F.
2. Specify the following parameters: range of integral (initial
a)
value ( , end value (
of subintervals (
You do not need to specify the number of subintervals. If the
number of subintervals is not specifi ed, the default value of
n
= 100 will be used.
3. Press =.
Notes:
• Parameters are entered in the following way:
WriteView editor:
b
function[, subintervals]
a
Line editor:
a
(function,
• Integral calculations, depending on the integrands and
subintervals included, require longer calculation time. During
calculation, the BUSY symbol will be displayed. To cancel
calculation, press j.
Note that there will be greater integral errors when there are
large fl uctuations in the
integral values during
minute shifting of the
integral range and for
periodic functions, etc.,
where positive and
negative integral values
x x
1 , 2 , n!, etc.)
exist depending on the
interval.
For the former case, divide integral intervals as small as
1
, etc.) ⑧ nCr,
4
possible. For the latter case, separate the positive and negative
values. Following these tips will allow you to obtain results from
xy
r
, , and
calculations with greater accuracy and will also shorten the
calculation time.
Performing differential calculations
1. Press @ G.
2. Specify the following parameters: function with variable
x
value of , and minute interval (
You do not need to specify the minute interval. If the minute
interval is not specifi ed, it will automatically be set to 10
x
(while 0), or |
3. Press =.
Note: Parameters are entered in the following way:
4
WriteView editor:
d (function)
–
dx
Line editor:
5
d / dx (function, value of
Function
The function returns the cumulative sum of a given expression
from an initial value to an end value in NORMAL mode.
Performing
1. Press @ I.
6
2. Specify the following parameters: initial value, end value,
function with variable
You do not need to specify the increment. If the increment is
not specifi ed, the default value of
3. Press =.
Note: Parameters are entered in the following way:
WriteView editor:
end value
( function[, increment])
x
initial value
Line editor:
(function, initial value, end value[, increment])
( )
h
f (a h) f (a 3h) f (a (N 1)h)}
(a 4h) (a (N 2)h)} (b)}
f f f
N
a x b
dx dx
f(x ) f(x )
2 2
f´(x) —
dx
b x
)), function with variable , and number
n
).
dx
b
, [, subintervals])
y
x
0
a
x
a
b
x x
0 1
x
x
1
2
x
3
x
d ).
x x
| 10 5 (while 0).
|
x x
value of [, minute interval]
x
[, minute interval])
calculations
x n
, and increment ( ).
n
= 1 will be used.
7 Random Function
The random function has four settings. (This function cannot be
selected while using the N-base function.) To generate further
random numbers in succession, press e. Press j to exit.
Random numbers
A pseudo-random number, with three signifi cant digits from 0 up
to 0.999, can be generated by pressing @ w 0 e.
Note: In the WriteView editor, if the result is not 0 it can be
b a shown as a fraction or decimal using U.
N
Random dice
2n
To simulate a die-rolling, a random integer between 1 and 6 can
be generated by pressing @ w 1 e.
Random coin
To simulate a coin fl ip, 0 (heads) or 1 (tails) can be randomly
generated by pressing @ w 2 e.
Random integer
An integer between 0 and 99 can be generated randomly by
pressing @ w 3 e.
Angular Unit Conversions
Each time @ ] is pressed, the angular unit changes in
sequence.

Memory Calculations

Mode ANS
NORMAL ○
STAT ○
○
CPLX
○
MATRIX
LIST ○
○: Available × : Unavailable
Temporary memories (A–F, X and Y)
Press x and a variable key to store a value in memory.
Press t and a variable key to recall the value from that memory.
To place a variable in an equation, press ; and a variable key.
Independent memory (M)
In addition to all the features of temporary memories, a value can
y
be added to or subtracted from an existing memory value.
x
2
b Press j x M to clear the independent memory (M).
x
x
3
Last answer memory (ANS)
The calculation result obtained by pressing = or any other
calculation ending instruction is automatically stored in the last
answer memory.
When the calculation result is in matrix or list form, the full matrix
or list is not stored into ANS memory. Only the value of the
element covered by the cursor is stored.
Notes:
x
, • Calculation results from the functions indicated below are
automatically stored in the X or Y memories replacing any
existing values.
xy
r
5
• , : X memory (
x
• Two ´ values from a quadratic regression calculation in
STAT mode: X memory (1:), Y memory (2:)
• Use of t or ; will recall the value stored in memory
using up to 14 digits.
Formula memories (F1–F4)
You can store expressions in formula memories (F1–F4). Storing
a new expression in a memory space will automatically replace
any content that may already exist there.
Notes:
8
• Expressions that are stored from the WriteView editor cannot
be recalled from within the Line editor, and vice versa.
• You can only recall expressions stored from the Line editor
when entering values or items in STAT, MATRIX, LIST, or
EQUATION modes, or into solver functions or simulation
calculations.
• Any recalled expressions will overwrite any expressions that
are currently being entered.
• You cannot store formulas in formula memories when entering
values or items in STAT, MATRIX, LIST, or EQUATION modes,
or into solver functions or simulation calculations.
9
10
M, F1–F4 A–F, X, Y D1–D4
○ ○ ○
○ ○ ○
○ × ○
○ ○ ○
○ ○ ○
r x y
or ), Y memory ( or )
