Page 2: Table Of Contents
PRINT OUT AND KEEP USER MANUAL IN A SAFE PLACE FOR EASE OF REFERENCE. TABLE OF CONTENTS Safety ......1 (Warnings & Cautions) Package Contents........2 Unpacking & Setup........3 Features & Benefits........5 Using EtOH PRO Extract Mode........8 Purge Mode........11 Altitude Tuning.........12 Care Instructions........13 Technical Specifications......14 Warranty............15 Contact Information.........17 Resources............18... -
Page 3: Safety (Warnings & Cautions)
• There is no automatic shut-off for the EtOH PRO, you must turn off power when not in operation. • EtOH PRO will vibrate during operation. Objects will slide off and the unit could shift position Place on a flat, no- slip surface where the unit can not slide. - Page 4 You must determine the hazards and handling requirements of the particular oils you extract. ExtractCraft makes no claims, representations, or warranties about botanical oils, their uses, or their suitability for extraction. This is simply a device for extracting botanical oils.
-
Page 5: Package Contents
PACKAGE CONTENTS 1 – EtOH PRO Base Unit 1 – Power Cord 1 – Kettle Lid Holster 1 – Kettle 1 – Reclaim Jar holster 1 – Reclaim Jar 1 – Spit Jar... - Page 6 4) Remove the square box containing the kettle, remove kettle from box and set aside. 5) The only thing remaining in the box should be the EtOH PRO base platform with the kettle and reclaim jar lids attached by vacuum hoses. The base is heavy, and the attached parts are cumbersome to move so the help of a second person is advised.
-
Page 7: Features & Benefits
FEATURES & BENEFITS OF THE EtOH PRO • Non-stick chamber • Closed ethanol recovery appliance • Glass lid for easy viewing • 4L capacity / 1 lb dry material • Post processing capabilities • 3 Hour processing time • High quality design & materials •... - Page 8 LID HOLSTER KETTLE CONNECTION AND PLUGS On the back of EtOH PRO there is a sturdy holster to The power connection was designed to secure effortlessly hold the lid when it’s not in action. This reduces the and for easy disconnect when it’s time to collect your overall operational footprint and makes handling the beautifully crafted oil from the kettle.
- Page 9 EtOH PRO and the vacuum line onto the empty spit jar port. The aux pump power switch should be left in the ON position and EtOH PRO will turn the pump on and off as vacuum is required. Using an aux pump will reduce pump down times and overall pump activity.
-
Page 10: Using Etoh Pro Extract Mode
• Push the green illuminated 'START/STOP' button one time to start processing. IMPORTANT: HOT START CONSIDERATIONS When restarting EtOH PRO while the unit and contents are still warm there is a good chance for “bumping” to occur. This means that as the contents come under vacuum and have heat reintroduced there will be a big burp of liquid that will splatter aggressively. - Page 11 It’s best to avoid any foam being sucked into the vacuum port in order to keep the reclaim clean, but small amounts will not harm the EtOH Pro or the process. If it is substantial then the settings, temp and/or altitude, must be adjusted.
- Page 12 • Once the vast majority of ethanol is evaporated off there may be a minor temp overshoot, but it should be quite small. Minor overshoots should not harm the EtOH PRO, impair the process, or pose a safety hazard.
-
Page 13: Purge Mode
ExtractCraft makes no recommendations, representations or warranties regarding which specific containers or mats are appropriate for use for this purpose. User assumes all responsibility for choosing and using a container or mat and for following all safety instructions for the container or mat chosen for such a purpose. -
Page 14: Altitude Tuning
8,000 feet – push 8 times 5. After you have entered your elevation EtOH Pro will pause for 10-seconds and the green illuminated button will flash the same number of times it was pushed to confirm the setting, once for every 1,000 feet. -
Page 15: Care Instructions
There are few parts on the EtOH PRO to clean. The base of the unit should never be submerged in water or any other liquid. Simply wipe the surface with a damp towel or use alcohol some alcohol for sticky residue. -
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS ELECTRICAL 100-130 VAC, 50-60 HZ 650W@120 VAC, 5.5 AMPS THERMAL Processing temperature range: 96F-110F Purging temperature range: 80F-120F Maximum ambient temperature for processing: 80F *Processing and purging temp ranges may vary due to differences in ambient atmospheric conditions and elevation considerations **At the end of the process if the kettle is run dry or mostly dry for any amount of time you may expect a minor temperature range deviation. -
Page 17: Warranty
Amazon and Ebay. Amazon and Ebay online purchases from sellers not included in the "AUTHORIZED SELLERS" list below will not be covered by the ExtractCraft warranty and will not be eligible to be serviced by ExtractCraft. ExtractCraft reserves the right to update and amend the Authorized Sellers list without notice. - Page 18 HOW DO YOU OBTAIN WARRANTY SERVICE? To obtain warranty service, you must email our Customer Service Department at info@extractcraft.com during the Warranty Period to obtain a Defective Merchandise Authorization (”DMA”) number. No warranty service will be provided without a DMA number.
-
Page 19: Contact Information
CONTACT INFORMATION Address: ExtractCraft, LLC 105 S. Sunset St., Ste M Longmont, CO 80501 Email: info@extractcraft.com Phone: (720) 307-8628...
