- Page 1 Vacuum Purge Lid for EtOH Pro User Guide DOC 74-00011 Rev A...
- Page 2 Do not rotate/twist Gauge Assembly coming up from lid. The Gauge Assembly is able to rotate slightly, but excessive rotation could lead to leaks over time. - Designed to fit the EtOH Pro Kettle. - Uses the EtOH Pro’s Purge Mode.
- Page 3 Vacuum Purge Lid Components Vacuum Gauge Pressure Equalization Seal Ø63mm Vacuum Gauge (Glycerine Filled) (Rubber Plug) Vent Valve Vacuum Valve Vacuum Valve Vent Valve “Open” “Open” “Closed” “Closed” 5/16” ID Tube 5-20µ Filter Barbed Fitting DOC 74-00011 Rev A...
- Page 4 Oil should be on a non-stick silicone mat placed at bottom of the Kettle. Plug the kettle into the EtOH Pro, verify the machine is turned on via the switch in the rear and that the dial is set to Purge Mode.
- Page 5 Troubleshooting Incorrect Gauge Reading At default, the needle on vacuum gauge should read 0. If it is not, equalize the pressure by lifting the rubber plug to vent the gauge. Equalizing the pressure in the gauge can be done at any time. Venting the gauge plug is useful to verify the gauge is reading correctly.
