BIRD SITE ANALYZER SA-1700EX Operating Instructions Manual

Cable and antenna tester for wireless systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

SITE ANALYZER™
CABLE AND ANTENNA TESTER
FOR WIRELESS SYSTEMS
OPERATING INSTRUCTIONS
FOR MODELS
SA-1700EX, SA-1700EXP
SA-2500EX, SA-6000EX
©Copyright 2006 by Bird Electronic Corporation
Instruction Book Part Number 920-7002A600S Rev. E
Site Analyzer is a trademark of Bird Electronic Corporation
Microsoft® and Windows® are registered trademarks
of the Microsoft Corporation
