The KNX IP Interface 731 supports up to 5 simultaneous con-
nections. For each connection a separate individual address is
used.
The first additional individual address is assigned by the ETS. By
clicking on the 'Settings' at the selected connection "Local Set-
tings" this dialogue box with a corresponding input field appears:
The further additional addresses can be assigned directly on the
device. This is done by pressing the programming button
least one second. Then, the programming LED flashes
the addresses are assigned as follows:
Connection 2 gets the next higher address than connection 1,
connection 3 gets the next higher address than connection 2,
etc.
Example:
Device address 1.1.255
Connection 1 1.1.250
Connection 2 1.1.251
Connection 3 1.1.252
Connection 4 1.1.253
Connection 5 1.1.254
The additional individual addresses have to be valid within the
sub line of the KNX IP Interface and not be used by another
device. By factory default only the additional individual address
of the first connection is active (which is preassigned to
15.15.250). To use more connections simultaneously, additional
address assignment must be performed as described above.
©2016 WEINZIERL ENGINEERING GmbH
❸
❷
and
(address within ETS topology)
(address within local settings)
(assigned by programming button)
(assigned by programming button)
(assigned by programming button)
(assigned by programming button)

The device may be built into distribution
boards (230/400V).

The device must be mounted and commis-
sioned by an authorized electrician.

The prevailing safety rules must be heeded.

The device must not be opened.

For planning and construction of electric in-
stallations, the relevant guidelines, regulations
and standards of the respective country are to
be considered.
at
WARNING
Weinzierl Engineering GmbH
D-84508 Burgkirchen / Alz
http://www.weinzierl.de
info@weinzierl.de
Germany
2016/09/21
