Page 1: Loop Antenna
INSTRUCTION MANUAL LOOP ANTENNA MODEL SHL-30 20 Hz – 30 MHz... - Page 2 INSTRUCTION MANUAL THIS INSTRUCTION MANUAL AND ITS ASSOCIATED INFORMATION PROPRIETARY. UNAUTHORIZED REPRODUCTION IS FORBIDDEN. 1995 ELECTRO-METRICS CORP. LOP ANTENNA 20 Hz – 30 MHz ELECTRO-METRICS MODEL ALP-70 SERIAL NO: N/A ELECTRO-METRICS CORPORATION 231 Enterprise Road, Johnstown, New York 12095...
-
Page 3: Warranty
WARRANTY This Model ALP-70 Loop Antenna is warranted for a period of 12 months (USA only) from date of shipment against defective materials and workmanship. This warranty is limited to the repair of or replacement of defective parts and is void if unauthorized repair or modification is attempted. - Page 4 ELECTRO-METRICS ALP-70 DESCRIPTION AND USE ELECTRO-METRICS ALP-70 LOOP ANTENNA 1.0 Description The ALP-70 Loop Antenna is designed to obtain magnetic field measurements from 10 kHz to 30 MHz. The antenna is suited for use in compliance testing to MIL-STD-461A/B/C, CISPR standards, plus other government and federal standards.
- Page 5 ELECTRO-METRICS ALP-70 2.0 Specifications 2.1 Electrical Frequency Range (calibrated): 10 kHz-30 MHz. Refer to Figure 1 for the Antenna Factor Chart) Impedance: Calibrated for use into 50. Signal Output Connector: BNC, female. Signal Injection Connector: BNC, female. 2.2 Mechanical Outside Diameter: 635 mm (25").
- Page 6 ELECTRO-METRICS ALP-70 FIGURE 1 ALP-70 ANTENNA FACTOR CHART PAGE 3A (ALP70-3)
