WARNING:
To reduce the risk of injury, the user must read and understand the owner's manual
before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Part No. SP6961
GlobalTestSupply
www.
OWNER'S MANUAL
12 U.S. GALLON/45 LITER
PROFESSIONAL WET/DRY VAC
1250RV0
.com
Printed in Mexico
sales@GlobalTestSupply.com
Advertisement
Table of Contents
Related Manuals for RIDGID 1250RV0
Summary of Contents for RIDGID 1250RV0
- Page 1 1250RV0 WARNING: To reduce the risk of injury, the user must read and understand the owner’s manual before using this product. Thank you for buying a RIDGID product. SAVE THIS MANUAL FOR FUTURE REFERENCE Part No. SP6961 Printed in Mexico GlobalTestSupply www.
-
Page 2: Table Of Contents
Table of Contents Section Page Blowing Feature ....13 Accessory and Hose Storage ..14 Accessory Storage ... . . 14 Hose Storage . - Page 3 • To reduce the risk of personal injury or WARNING: To reduce the risk of damage to Vac, use only Ridgid electric shock - do not expose to recommended accessories. rain - store indoors.
- Page 4 Introduction This Wet/Dry Vac is intended for house- Read this owner’s manual to familiarize hold use. It may be used for vacuuming yourself with the product features and to wet or dry media and may be used as a understand the specific usage of your blower.
- Page 5 Unpacking and Checking Carton Contents (Continued) Bag of Loose Parts - Containing the Following: Description 2” Casters........4 Screws, Type AB #10 x 3/4..4 Vacuum Assembly Installing Casters 1. Remove lid from the drum/caddy by Lid Latch Hook unlatching the two latches at the top of the Vac.
- Page 6 Vacuum Assembly (Continued) Installing Accessory Holder 1. Attach the flexible end of the Flexible accessory holder at the top of the Vac drum. The non-elastic end should be located at the bottom of the Vac drum. Accessory Holder 2. Install accessory holder as shown with the 4 screws included.
- Page 7 Vac Drum Removal/Installation Removal 1. Remove the drum from the power SLIDE base caddy by first sliding the drum TO UNLOCK lock from the right to the left. This lock is located on the front of the unit just above the power switch, Drum between the lower portion of the drum Lock...
- Page 8 Vac Drum Removal/Installation (Continued) Installation 1. Position the lid on the drum/caddy Lid Latch Hook assembly as shown. 2. Rotate both latches up onto the lid latch hooks 3. Press the latches down and inward until latches are flush with the drum. Latch (2) ROTATE LATCHES...
- Page 9 Vac Drum Removal/Installation (Continued) 5. Lower the front of the drum onto the power base caddy and slide drum lock lever left to right to locked position to SLIDE secure. TO LOCK Note: This will allow the drum and power base to create and maintain the proper seal once the drum lock on the front has been moved to the locked position.
- Page 10 Operation WARNING: To reduce the risk of fire, explosion, or damage to Vac: • Do not leave Vac running while unattended - you may fail to notice important signs indicating abnormal operation such as loss of suction, debris/liquid exiting the exhaust, or abnormal motor noises.
- Page 11 Operation (Continued) To reduce the risk of electric shock, this After you plug the ALCI plug into the Vac has an ALCI (Appliance Leakage outlet, turn the Wet/Dry Vac on by Current Interrupter) device with a pushing the foot pedal down, located at polarized plug (one blade is wider than the front bottom of drum/caddy base.
- Page 12 Operation (Continued) Vacuuming Liquids Emptying the Drum 1. When picking up small amounts of WARNING: To reduce the risk of liquid (2-4 inches of liquid in the back injury or falls, do not lift a Vac bottom of the drum) the filter may be heavy with liquid or debris.
-
Page 13: Blowing Feature
Operation (Continued) Blowing Feature CAUTION: Wear a dust mask if Your Vac features a blowing port (located blowing creates dust which might at the back of the Vac). It can blow be inhaled. sawdust and other debris. Follow the steps below to use your Vac as a blower. CAUTION: To reduce the risk of 1. -
Page 14: Accessory And Hose Storage
Accessory and Hose Storage Hose Storage Accessory Storage The hose may be stored by wrapping it Your accessories may be stored in the around the top of the Vac. accessory holder located on the rear of the drum, or in the foot storage on the power Tug-A-Long base caddy. -
Page 15: Maintenance
RIDGID’s Qwik Lock™ Fine Dust Filter. Replacement Qwik Lock™ Filter Cage Filters are available where you purchased your Vac. Ask for the RIDGID Qwik Lock™ Fine Dust Filter VF5000. Bottom Motor NOTE: The filter is made of high quality... - Page 16 3. Empty drum after 20 minutes. Rinse maintenance, repairs, or adjustments with water until bleach smell is gone. should be performed by Authorized Allow drum to dry completely before Service Centers, always using RIDGID sealing the motor on the drum. replacement parts. GlobalTestSupply www.
-
Page 17: Repair Parts
Repair Parts 12 Gallon Professional Wet/Dry Vac Model Number 1250RV0 Always order by Part Number - Not by Key Number WARNING SERVICING OF DOUBLE-INSULATED WET/DRY VAC In a double-insulated Wet/Dry Vac, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding be added. - Page 18 Repair Parts (Continued) 12 Gallon Professional Wet/Dry Vac Model Number 1250RV0 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 19: Wet/Dry Vacs
• No other express warranty applies This FULL LIFETIME WARRANTY is the sole and exclusive warranty for RIDGID ® Wet/Dry Vacs. No employee, agent, dealer, or other person is authorized to alter this warranty or make any other warranty on behalf of Ridge Tool Company.
