Honeywell T7350 Quick Start Manual

Commercial programmable thermostat , pda configuration
Hide thumbs Also See for T7350:

Advertisement

Quick Links

Download this manual See also: Product Data, User Manual
PDA Configuration
SETUP
1. Connect PDA to 50000083-001 Thermostat
Interface Module (TIM) using PDA serial cable.
2. Ensure the PDA serial cable and the PDA
remain connected.
3. Connect T7350 to TIM using RJ-45 cable.
Novice Navigation
The standard (novice) mode guides the user through
the essential configuration screens. Next and Back
buttons guide the user from screen to screen.
NOTE: The current desired T7350 configuration
determines the context of screen displays.
See Fig. 1 through 5 for sample screens.

QUICK START GUIDE

T7350
63-2606

Advertisement

loading

Related Manuals for Honeywell T7350

Summary of Contents for Honeywell T7350

  • Page 1: Quick Start Guide

    Interface Module (TIM) using PDA serial cable. 2. Ensure the PDA serial cable and the PDA remain connected. 3. Connect T7350 to TIM using RJ-45 cable. Novice Navigation The standard (novice) mode guides the user through the essential configuration screens. Next and Back buttons guide the user from screen to screen.
  • Page 2 Req’d Description Override Manually override digital and analog outputs. Enable/Disable output delays. Set Clock Set T7350 real time clock date/time. Temp SetPts Upload current setpoints. Modify values and download to the T7350. Upload Config X Upload configuration and display results.
  • Page 3 Table 2. Novice Navigation Screens. Function Description Summary Basic data with access to functions such as Save and DownL(oa)d. Inputs Configure T7350 sensor inputs. Cooling Configure cooling parameters. Heating Configure heating parameters. Outputs Configure T7350 outputs. Configure fan control. Wkly Schedule Select, create, save, name weekly schedule.
  • Page 4 Fig. 3. Cooling and Heating. Fig. 4. Outputs and Fan. Fig. 5. Weekly Schedule and Setpoints. 63-2606...

  • Page 5: Advanced Navigation

    Advanced Navigation Advanced navigation is designed for expert level users. It allows direct access to any thermostat configuration screen: 1. Tap either the title tab or the silk screen menu icon (see Fig. 6). 2. The tool replaces the title tab with the Advanced Navigation menu (see Fig.
  • Page 6 Table 3. Advanced Functions. Menu Function Description File Create named T7350 configuration. Open Select and display existing T7350 configuration. Save Save current configuration with existing name. Save As Save current configuration with new name. Delete Delete an existing configuration. Download...
  • Page 7 Configure cooling mode parameters. Heating Configure heating mode parameters. Configure fan options. SetPoints Configure and download temperature setpoints. Display Configure T7350 display and user interface parameters. Dehumidification Configure dehumidification high limits. EnergyMgmt Configure energy management parameters, including: power restoration sequential start delay and demand limit control bump.

  • Page 8: Frequently Asked Questions

    Table 3. Advanced Functions. (Continued) Menu Function Description Sched Wkly Sched Select, create, save, or download a weekly schedule. Recovery Configure startup recovery parameters. Holiday Select, create, save, or download a holiday group. DayLightSav Configure Daylight Saving start and end date/time. User Pref Set preferences, including: units (°C/°F), OS alert message (on/...
  • Page 9 How do I connect the PDA Configuration Tool to the T7350 Thermostat? Use the Honeywell TIM (part no.: 50000083-001) to facilitate the connection between the PDA serial cable DB9 (not included) and the T7350 RJ Jack. How do I copy/modify an existing configuration file? Use the following procedure: 1.
  • Page 10 ® — Regular use of the HotSync function to back up data to a PC saves T7350 configurations. In the case of a battery failure, the Palm™ Desktop application automatically restores the saved configurations at the next HotSync event from the StatDbFile-HIRW.PDB file.
  • Page 11 63-2606...
