KidKraft 14321A Assembly Instructions

Please retain this information for future reference
HARDWARE Parts List:
A. Hex Bolt x 12 pcs
(2 in / 50 mm)
B. Flat Screw x 4 pcs
(1 in / 25 mm)
C. Flat Screw x 4 pcs
(5/8 in / 15 mm)
D. Screw x 4 pcs
(5/16 in / 8 mm)
E. Cap Nut x 4 pcs
F. Latch x 2 pcs
G. Fabric Strip x 1 pc
H. Screw x 1 pc
Step 1
(5/8 in / 15 mm)
I. Plastic anchor x 1 pc
J. Wood Screw x 1 pc
(1 9/16 in / 40 mm)
Wrench x 1 pc
Allen Wrench x 1 pc
The following tool
(not included) is
required for assembly:
Phillips ® screwdriver
CAUTION: Adult Assembly Required. Hardware
contains small screws with sharp points. Keep
unassembled parts out of reach of small children.
Medium Locker
Assembly Instructions
Step 2
F
F
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried out,
the product could cease to function properly
Step 3
Hole
predrilled
in product.
H
H
G
Item# 14321A-14324A
To order replacement parts, please visit www.kidkraft.com
11
x 2 x 2
WARNING: CHOKING HAZARD
Customer Service
Small parts and sharp points, not
1-800-933-0771
suitable for children under 3 years.
www.kidkraft.com
x 4
1
