KidKraft 17959 Assembly Instructions Manual

© 2010 KidKraft, LP
Please retain this information
for future reference
HARDWARE
A. Cross Dowel
Bolt x 14 pcs
2 1/4 in / 55mm
B. Cross Dowel
Nut x 14 pcs
C. Screw x 4 pcs
1 1/4 in / 32mm
Allen Wrench x 1 pc
The following tools
(not included) is
required for
assembly:
®
Phillips screwdriver
CAUTION:
ADULT ASSEMBLY REQUIRED. Hardware contains
small screws with sharp points. Keep unassembled
parts out of the reach of small children.
WARNING:
CHOKING HAZARD. Small parts and sharp points, not suitable for children under 3 years.
Lights & Sound
Spiral Quarry Train Set
& Table in Espresso
Assembly Instructions
PARTS LIST
2
4
Red
5
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried
out, the product could cease to function properly.
1
x 2
x 2
x 2
x 2
7
Item #17959
To order replacement parts,
please visit www.kidkraft.com
3
x 4
6
8
9
Blue
x 2
Customer Service
1-800-933-0771
www.kidkraft.com
