- Page 1 INSTRUCTION MANUAL Hybrid – BOOST Charge Controller with Wireless Connection www.silentwindgenerator.com...
- Page 3 Before using this gadget please carefully read this manual. General Information The Silentwind-Charge controller HYBRID BOOST is a combined wind and solar charge regulator with an inbuilt micro-controller. The HYBRID BOOST was espe- cially developed for the Silentwind Generator and enables you additionally to install solar panels up to a wattage of 300 Watt peak or to a max.
-
Page 4: Table Of Contents
Mounting the charge controller Cable size selection Installation and connection of the charge controller External Stop Switch Connecting solar panels Programming charge controller Programming instruction 10.1. SilentWind Controller APP installation and operation 10.2. Settings 10.2.1 Settings parameters 10.2.2 Charging – Absorption mode 10.2.3 Break adjustment 10.2.4... -
Page 5: Wiring Diagram
1. Wiring diagram Wind Charge Solar Generator controller Panels Wind Charge Automatic Generator controller Light Batteries Inverter End user... -
Page 6: Technical Data
2. Technical data Hybrid-charge controller type HYBRID BOOST Battery system voltage (automatically detected) 12 / 24 / 48 Volt Max. power input of the wind generator 600 W Max. current input of the wind generator 40A / 30A / 15A 300Wp Max. -
Page 7: Components Of The Charge Controller
3. Components of the charge controller 3.1. Bottom panel On the down side of the charge controller there are screw terminals to connect the battery, the wind generator, the solar panels and DC consumers. The connections for the remote brake are also below. 3.2. -
Page 8: Mounting The Charge Controller
As you can see from the wiring diagram in paragraph 1 a 3-pole cable with suitable cross section must be wired from the Silentwind-Generator to the charge control- ler. The charge power gets from the charge controller to the batteries through two... -
Page 9: Installation And Connection Of The Charge Controller
Please take note: After the connection of the battery you can connect the Silentwind Generator, the solar panel and if required a load output with maximum 10A. On the 3-phase output wires of the Silentwind you need not to pay attention to polarity. -
Page 10: External Stop Switch
5). You can choose the type of stop switch suitable to your instrument panel. 8. Connecting solar panels The charge controller Hybrid BOOST is a hybrid controller both for wind and solar energy. Solar panels with a max power of 300 Wp ( 20 A for 12V / 10 A for 24V and 5 A for 48V) can be connected, See technical details page 4. -
Page 11: Programming Charge Controller
If the charge end voltage or maximum charge current is reached, the Silentwind Generator will stop for approx. 5 minutes. The break mode of the charge regulator generates internal rising temperatures that are thermically detected. -
Page 12: Programming Instruction
This means that the Silentwind Generator can also be operated with a larger battery capacity. If a large battery capacity is discharged, a higher charge current will flow in high wind speeds. As you can set the maximum charge current you can prevent overheating of the charge controller. -
Page 13: Settings Parameters
10.2.3 Break adjustment You can set the current when you want to stop Silentwind Generator. This prevents overheating, especially with big battery banks and high loading currents. This function can also be used to reduce the RPM of the Silentwind Generator. -
Page 14: Boost Function
Click on save data to save the settings. Safety advice Please never disconnect the battery wires while the Silentwind Generator is charging. This will immediately destroy the charge controller. If you want to measure the current flowing, an amp-meter must be installed in the positive battery wire. Mind the polarity of... -
Page 15: Troubleshooting
If the Silentwind Generator generates too little power – The wind speed is too low, see the performance diagrams shown in the manual of the Silentwind. The wind speed measured on top of the mast is higher than at the position of the wind generator! –... - Page 16 Rulis Eléctrica, Lda. Loteamento Industrial de Linhares, Lote 19 PT-4805-486 Santo Estevão de Briteiros Guimarães, Portugal VAT/Contribuinte / EORI-N. PT 502 995 530 Tel. +351 253 572763 | +351 967 907 933 Fax +351 253 572764 info@silentwindgenerator.com www.silentwindgenerator.com...
