Read and understand all instruction, warning, and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
3
1
A
A
Blade Control Handle
B
D
C
Star Knobs
B
Hold blade control handle against upper handle.
Lift handle to extended position.
Recoil
Slowly slip recoil starter into rope guide.
Tighten star knobs.
Tighten rope guide wing knob.
Starter
Hardware Pack
Wing Nuts (2)
Carriage Bolts (2)
2
4
Place ends of lower handle onto handle brackets.
Insert carriage bolts and tighten with wing nuts.
Use cable ties to secure cable(s) to lower handle.
Refer to Operator's Manual for instructions on attaching the grass catcher.
Call 1-888-TO-HELP-U
Need Help?
(1-888-864-3578)
© 2006 12AE449
778-11360
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
