Page 1
MCB-200 MULTIFUNCTION DIGITAL TIME RELAY With 1 CO contact Operating Manual Dudullu OSB; 1. Cadde; No: 23 34776 Umraniye - ISTANBUL / TURKEY : +90 216 313 01 10 Fax : +90 216 314 16 15 www.entes.com.tr A6698 / Rev.2...
Page 2
1. INTRODUCTION Stop Start MCB-200 is a multifunction digital timer with 1 CO contact. It offers wide time adjustment range between 0.2-9999 seconds and 0.1-9999 minutes. MCB-200 has 15 different functions with wide adjustable time ranges. The main application area is the industrial and automation control systems.
Page 3
ESC button exits from a menu. 1.2.3 Output MCB-200 has one changeover relay output. According to VDE 0110 and IEC 60947-1 standards; switching capacity of relay output is 8A, 2000VA, 250 V. and maximum electrical life time is 1x 10^6.
Page 4
1.2.4 Inputs 2. OPERATING INSTRUCTIONS 1.2.4.1 Start Input and Stop Input: When the device is taken out of the box, an installation menu will be displayed. Language and function These inputs are voltage-free dry inputs. settings are done in this menu as seen in the figure below. Afterwards, device returnss to main menu and Start Input: For some of the functions, output depends on the state of the start input or input pulses starts operating.
Page 5
Basic settings map is shown below. There are two main submenus as function selection and display 1. On Delay / Start by external trigger leading edge settings. This funcition is controlled by start input. Time counting starts with the leading edge of the start pulse; at the end of time td...
Page 6
2. On Delay / Start by external edge re-trigger 3. Off Delay / Start by external trigger trailing edge This funcition is controlled by start input. Time counting starts with the leading edge of the start pulse; This function is controlled by start input. Output Relay is activated when start pulse is applied and remain at the end of time td...
Page 7
4. Symmetric Flasher / Start by external trigger leading edge / Relay ON start 5. Symmetric Flasher / Start by external trigger leading edge / Relay OFF start This function is controlled by start input. With the leading edge, output relay is activated and remain Function is similar to the ON Start version (function 4) with the exception that the output relay start on during ton.
Page 8
6. Asymmetric Flasher / Start by external trigger leading edge / Relay ON start 7. Asymmetric Flasher / Start by external trigger leading edge / Relay ON start This function is controlled by start input. With the leading edge, output relay is activated and remain Function is similar to the ON Start version (function 6) with the exception that the output relay start as on during ton.
Page 9
8. Symmetric Flasher / Start by external edge - retrigger / Relay ON start 9. Symmetric Flasher / Start by external edge - retrigger / Relay OFF start This function is controlled by start input. With the leading edge, output relay is activated and remain Function is similar to the ON Start version (function 8) with the exception that the output relay start on during ton.
Page 10
10. Asymmetric Flasher / Start by external edge - retrigger / Relay ON start 11. Asymmetric Flasher / Start by external edge - retrigger / Relay OFF start Function is similar to the Symmetric version (function 8) with the exception that ton and toff Function is similar to the Symmetric version (function 9) with the exception that ton...
Page 11
12. Adjustable ON Delay by external trigger leading edge 13.Adjustable and Resettable ON Delay Pulse by external trigger leading edge This function is controlled by start input. The cycle starts with adjustable toff delay time after a pulse This function is controlled by start input. The cycle starts with adjustable toff delay time. At the end of delay time, output relay is activated and remain activated during ton.
Page 12
14. Adjustable OFF Delay Pulse by External Trigger Leading Edge 15. Adjustable OFF Delay Pulse by External Trigger Leading Edge Re-trigger This function is controlled by start input. With the leading edge of the external trigger, output relay is This funcition is controlled by start input. The cycle starts with adjustable td delay time and output activated and remain on during td.
Page 13
2.2 Settings 2.2.1 Function Selection: Function sub-menu is reached by pressing SET button in Settings menu. The functions that the device offers can be browsed with UP or DOWN buttons. The user selects the desired function enters its adjustment menu by pressing SET button.
2.2.2 Time Setting : FUNCTION SETTINGS After selecting the function, user sets t value/values according to the application need. ON Delay : Time range for t is between 0.1 seconds-9999 seconds and 0.1 minutes-9999 minutes. Setting starts from left digit towards right digit. User uses UP button to increase value of the digit and DOWN button to decrease.
Page 16
One Shot : 2.2.3 Display Settings : In this submenu; user can set password, contrast, backlight, language and return to factory settings. In password submenu, user can activate or deactivate the password. To change password, user enters current password first, then new password twice.
3 MAIN DISPLAY Connection Diagram : Dimensions : This is an example to explain main screen use. - Top line displays the function. In this case; Onstrt (ON start), Strt- Input (Start Input) and Edge Trigger is selected. - First line displays the set time value; min. icon indicates the time scale.
Page 18
Technical Features Cable Selection 2,5mm^2 stranded 4,0mm2 solid Input Circuits Weight 0.25 kg 2 pcs. Lithium Battery Battery Installation Ray Montaj 10 years or 1 million relay operations Battery Life Enclosure and Terminal Protection Class IP40 / IP20 2 dry contacts (Start, Stop) Input Contacts Operating Temperature +5...+50 °C...
